1997 RENAULT KANGOO light

JSA051.0
INJECTION
Fault finding - Checking conformity
17
D7F 710
engine -
35 tracks
NOTES
Order of
operationsFunction to be
checkedAction Bargraph Display and notes
7Manifold pressure# 01
no consumers X is variable and is
approximately
270 ≤ X ≤ 430 mb
(this pressure varies with
altitude)
8 Richness regulation Stable engine
speed of 2500
rpm then idle
speed
# 05
# 35X varies in the range from 50 to
900 mV approximately
X is close to 128 and varies
slightly
with a maximum of 255
and minimum of 0
9Adaptive idle speed
correction# 21- 4.3 % < X < 3.9 %
(average value after erasing
the memory: 0)
10 Canister bleed# 23Canister bleed is prevented.
The solenoid valve remains
closed. X = 0.7 %
11 PAS pressostat# 06X = 800 rpm
Engine warm, at idle speed, after fan assembly has operated at least once
6
6
11
13
17-141

Connect the bornier in place of the computer and check the insulation and continuity of the line.
Computer 43 6 Instrument panel
Repair.
JSA052.0
INJECTION
Fault finding - Interpretation of XR25 bargraphs17
D7F 710
engine -
55 tracks
Erase the computer memory using G0**.
Try to start the engine. Switch the ignition on, then deal with the other faults.
Remember to carry out a status and parameter check.AFTER REPAIR
Bargraph 12 LH side illuminatedFiche n° 27 side 1/2
FAULT WARNING LIGHT CIRCUIT
XR25 aid:CO, CC- or CC+ line 43 of the computer

12
NoneNOTES
Check the condition of the warning light and its feed.
Repair if necessary.
17-169

JSA052.0
INJECTION
Fault finding - Status and parameter checks
17
D7F 710
engine -
55 tracks
Engine stopped, ignition on.NOTES
Order of
operationsFunction to be
checkedAction Bargraph Display and notes Fault finding
6Throttle
position
potentiometer
.No load
# 17
Accelerator
pedal
slightly
depressed
Full load
# 1710 < X < 50
185 < X < 245
DIAG 2
7Pressure sensor
# 01X = Atmospheric
pressureDIAG 9
8Coolant
temperature
sensor# 02X = Engine temperature
± 5 °CDIAG 3
9Air
temperature
sensor# 03X = Temperature under
bonnet ± 5 °CDIAG 4
10 Fan assemblyG17*The fan must operateDIAG 17
11 Fault warning
lightSwitch
ignition onThe fault warning light
must illuminate then
extinguishDIAG 19
2
2
2
17-176

Connect the bornier in place of the computer and check the insulation and continuity of the line:
Computer 43 6 Instrument panel
Repair.
JSA052.0
INJECTION
Fault finding - Status and parameter interpretation17
D7F 710
engine -
55 tracks
AFTER REPAIRStart the status and parameter check again from the beginning.
DIAG 19FAULT WARNING LIGHT CIRCUITFiche n° 27
XR25 aid:None
No fault bargraphs should be illuminated.
NOTES
Check the condition of the warning light and its feed.
Repair if necessary.
17-200

JSA051.0
INJECTION
Fault finding - Checking conformity
17
D7F 710
engine -
55 tracks
Engine cold, ignition on.NOTES
Order of
operationsFunction to be
checkedAction Bargraph Display and notes
6 Throttle position
potentiometerNo load
# 17
Accelerator
pedal slightly
depressed
Full load
# 17 10 < X < 50
185 < X < 245
7Absolute pressure
sensor# 01 X = Local atmospheric
pressure
8Coolant temperature
sensor# 02 X = Ambient temperature
± 5 °C
9Air temperature
sensor# 03 X = Ambient temperature
± 5 °C
10Idle speed regulation
stepping motor# 12The value read is variable
depending on the coolant
temperature : : 11 % ≤ X ≤
100 %
11Engine speed
# 06 X = 0 rpm
12Canister bleed
# 23 X = 0.7 %
2
2
2
17-210

JSA051.0
INJECTION
Fault finding - Checking conformity
17
D7F 710
engine -
55 tracks
NOTES
Order of
operationsFunction to be
checkedAction Bargraph Display and notes
7 Manifold pressure# 01
no consumers X is variable and is
approximately
270 ≤ X ≤ 430 mb
(this pressure varies with
altitude)
8 Richness regulation Stable engine
speed of 2500
rpm then idle
speed
# 05
# 35X varies in the range from 50 to
900 mV approximately
X is close to 128 and varies
slightly
with a maximum of 255
and minimum of 0
9Adaptive idle speed
correction# 21- 4.3 % < X < 3.9 %
(average value after erasing
the memory : 0)
10 Canister bleed# 23Canister bleed is prevented.
The solenoid valve remains
closed. X = 0.7 %
11 PAS pressostat# 06X = 800 rpm
Engine warm, at idle speed, after fan assembly has operated at least once (air
conditioning not selected)
6
6
11
13
17-215

B76531.0
ELECTRONICALLY CONTROLLED HYDRAULIC SYSTEMS
Fault finding - Introduction38
ABS BOSCH
5.3
CONDITIONS FOR APPLICATION FOR THE TESTS DEFINED IN THIS FAULT FINDING
The tests described in this fault finding are only to be applied when the wording of the fault corresponds
exactly to the display on the XR25 kit.
If a fault is dealt with because there is a flashing bargraph, the conditions for confirming the existence of an
actual fault (and the need to apply the fault finding ) can be found in the "Notes" or at the beginning of the
bargraph interpretation.
If a bargraph is only interpreted when it is permanently illuminated, the application of the recommended
tests in the fault finding when the bargraph is flashing will not allow you to determine the origin of the
memorisation of this fault. In this case, only a test of the wiring and the connections of the component in
question must be carried out (the fault is simply memorised as it was not present at the time of testing).
NOTE : The ignition must have been switched off before the XR25 kit is used.
INDISPENSABLE TOOLING REQUIRED FOR OPERATIONS ON THE ABS SYSTEM
- XR25 kit.
- XR25 cassette n° 16 minimum.
Reminders :When there is intermittent fault memorisation, the ABS warning light will illuminate the next
time the vehicle is used until the car reaches 7.5mph (12 km/h). When the fault is memorised, a
counter relating to the fault is set at 40 . This value is reduced by one each time the ignition is
turned on if the fault is not present when the vehicle exceeds 7.5mph (12 km/h). When the
reading on the counter is equal to 1, it remains at 1 and the fault is not erased.
38-1

B76531.0
ELECTRONICALLY CONTROLLED HYDRAULIC SYSTEMS
Fault finding - Interpretation of XR25 bargraphs
38
ABS BOSCH
5.3
Erase computer memory(GO**).
Carry out a road test followed by a check with the XR25 kit.AFTER REPAIR
Bargraph 12 left hand side illuminated or flashing
Brake light circuit

12Fiche n° 53
Press the brake pedal while observing right and left bargraph 13.
Are the positions "pedal released" and "pedal depressed" registered?
None.
NOTES
YESCheck the two brake light bulbs and the earth of the rear light units (no
earthing of track 14 across the bulbs when pedal is not depressed ).
NOApply the fault finding described in the interpretation of bargraph 13 right
and left hand side for "Bargraph 13 left hand side extinguished, brake pedal
depressed".
38-15
