1997 Mercury Sable Engine

exterior accessories, such as antennas, before
entering a car wash.
²After washing, apply the brakes several times to
dry them.
Waxing your vehicle
The best way to determine when the paintwork
needs waxing is by noting when water stops beading
on the surface. This could be every three or four
months, depending on operating conditions.
Use only carnauba or synthetic-based waxes.
Remove any bugs and tar before waxing vehicle. Use
cleaning fluid or alcohol with a clean cloth to
remove. Use tar remover to remove any tar spots.
Repairing paint chips
Minor scratches or paint damage from road debris
may be repaired with touch-up paint, paint repair
foil or aerosol paint spray from the Ford accessory
line. Observe the application instructions on the
products.
Remove particles such as bird droppings, tree sap,
insect remains, tar spots, road salt and industrial
fallout immediately.
Cleaning the wheels
Wash the wheels with
the same detergent you
use to clean the body
of your vehicle. Do not
use acid-based wheel cleaners, steel wool, fuel or
strong detergents. Never use abrasives that will
damage the finish of special wheel surfaces. Use a
tar remover to remove grease and tar.
Cleaning the engine
Engines are more efficient when they are clean
because grease and dirt buildup act as insulators and
keep the engine warmer than normal. Follow these
guidelines to clean your engine:
com_waxing_vehicle.01
com_repairing_chips
com_wheels_cleaning.01
com_engine_cleaning.01
Maintenance and care
147

²Take care when using a power washer to clean
the engine. The high pressure fluid could
penetrate the sealed parts and cause damage.
²Do not spray with cold water to avoid cracking
the engine block.
²Cover the
highlighted areas to
prevent water
damage when
cleaning the engine.
²Never wash or rinse the engine while it is
running; water in the running engine may cause
internal damage.
Cleaning plastic exterior parts
Use a vinyl cleaner for routine cleaning of plastic.
Clean with a tar remover if necessary. Do not clean
plastic parts with thinners, solvents or
petroleum-based cleaners.
Cleaning the exterior lamps
Wash the exterior
lamps with the same
detergent you used to
wash the exterior of
your vehicle. Use glass
cleaner or tar remover
if necessary.
To avoid scratching the
lamps, do not use a dry paper towel, chemical
solvents or abrasive cleaners to clean the lamps.
com_plastic_exterior.01
com_exterior_lamps.01
com_wiper_cleaning.01
Maintenance and care
148

Cleaning the wiper blades
If the wiper blades do
not wipe properly,
clean both the
windshield and wiper
blades using undiluted
windshield wiper
solution or a mild
detergent. Rinse
thoroughly with clean
water. To avoid
damaging the blades,
do not use fuel,
kerosene, paint thinner
or other solvents.
Cleaning the instrument panel
Clean instrument panel with a damp cloth, then dry
with a dry cloth.
Any cleaner or polish that increases the gloss of the
upper portion of the instrument panel should be
avoided. The dull finish in this area is to help
protect the driver from undesirable windshield
reflection.
Cleaning the interior fabric
Remove dust and loose dirt with a whisk broom or a
vacuum cleaner. Remove fresh spots immediately.
Follow the directions that come with the cleaner.
BASSTREBBALFADEREWFFEJECT1234
56wTAPE SIDETAPE
R-DEFTUNESEEKSCAN AM
FMMH
LO
HIOFF
A/C
MAX
A/CVENTVOL
PUSH-ONwSTFM 12
AMCBLRFEFC HFUEL DOOR>SERVICE
ENGINE
SOONLOW
COOLANTTHEFT102030405060
70
80
90
100
1202060100
140
180P R N D 2 1MPH km/h0000000000P!
BRAKE+ –110CRUISERPMx1000ABSO/D
OFFREAR
LAMP
OUTPREMIUM UNLEADED
FUEL RECOMMENDED0 1234
5
6
78
com_instru-panel_cleaning.01
com_int_fabric_cleaning.01
com_leather_seats_cleaning.01
Maintenance and care
149

MOTORCRAFT PART NUMBERS
3.0L Vulcan engine
Component Part number
Air filter FA-1630
Fuel filter FG-800-A
Battery (standard) BXT-58R
Battery (optional) BXT-36R
Fuel filter FG-800-A
Passenger
compartment air filter
(if equipped)FP-6
Oil filter FL-400-S
PCV valve EV-228
Spark plug* AWSF-32PP**
* Refer to Vehicle Emissions Control Information
(VECI) decal for spark plug and gap information.
** If a spark plug is removed for inspection, it
must be reinstalled in the same cylinder. Cylinders
No. 1, 2 and 3 have a PG suffix. Cylinders No. 4, 5
and 6 have a P suffix. If a spark plug needs to be
replaced, use only spark plugs with the service
part number suffix letter9PP9as shown on the
engine decal.
3.0L Duratec engine
Component Part number
Air filter FA-1630
Fuel filter FG-800-A
Battery BXT-36R
Fuel filter FG-800-A
dno_vulcan-engine-parts
dno_duratec-part-numbers
Capacities and specifications
151

Component Part number
Passenger
compartment air filter
(if equipped)FP-6
Oil filter FL-820-S
PCV valve EV-152
Spark plug AWSF-32F
REFILL CAPACITIES
3.0L Vulcan engine
Fluid Ford Part
NameVehicle
TypeCapacity
Brake
fluidHigh
performance
DOT 3
brake fluidAll Fill to line
in reservoir
Engine
coolantPremium
cooling
system fluidAll 11.0 (11.6)
Engine oil
(with
filter
change)Motocraft
motor oil
5W30 super
premiumAll 4.25 (4.5)
Fuel tank
capacityN/A All 60.6 (16.0
gallons)
Power
steering
fluidMotorcraft
MERCONt
AT FAll Fill to line in
reservoir
Automatic
transaxle
- AX4NMotorcraft
MERCONt
AT FAll 12.8 (13.5)
dno_refill-caps
Capacities and specifications
152

Fluid Ford Part
NameVehicle
TypeCapacity
Automatic
transaxle
- AX4SMotorcraft
MERCONt
AT FAll 11.6 (12.2)
Windshield
washer
fluid -
FrontUltra-clear
windshield
washer
concentrateAll
Wagon2.7 (90 oz.)
2.1 (70 oz.)
3.0L Duratec engine
Fluid Ford Part
NameVehicle
TypeCapacity
Brake
fluidHigh
performance
DOT 3
brake fluidAll Fill to line
in reservoir
Engine
coolantPremium
cooling
system fluidAll 10.0 (10.6)
Engine oil
(with
filter
change)Motocraft
motor oil
5W30 super
premiumAll 5.2 (5.5)
Fuel tank
capacityN/A All 60.6 (16.0
gallons)
Power
steering
fluidMotorcraft
MERCONt
AT FAll Fill to line in
reservoir
Automatic
transaxle
- AX4NMotorcraft
MERCONt
AT FAll 12.7 (13.4)
dno_refill-duratec
Capacities and specifications
153

FluidFord Part
Name or
EquivalentFord
Part
NumberFord
Specification
Automatic
transaxleXT-2-QDX Motorcraft
MERCONt
AT FMERCONt
Engine oil
(Gasoline
engines)XO-
5W30-QSPMotorcraft
5W30
super
premiumWSS-
M2C153-F and
API
Certification
Mark
Constant
velocity
jointsE43Z-
19590-ACV joint
grease -
high
temp.ESP-
M1C207-A
Engine
coolantE2FZ-
19549-AAFord
premium
cooling
system
fluidESE-
M97B44-A
Power
steering
pump
reservoirXT-2-QDX Motorcraft
MERCONt
AT FMERCONt
ENGINE DATA
Engine data
Engine 3.0L SOHC V6 3.0L DOHC V6
Cubic inches 182 183
Horsepower 145 @ 5250 rpm 200 @ 5750 rpm
Torque 170 @ 3250 rpm 200 @ 4500 rpm
Required fuel
grade87 octane 87 octane
Firing order 1-4-2-5-3-6 1-4-2-5-3-6
sab_engine-info
Capacities and specifications
155

Engine data
Spark plug gap 1.07-1.17 mm
(0.042-0.046
inch)1.07-1.17 mm
(0.042-0.046
inch)
Ignition system DIS DIS
Valve clearance
cold inlet
exhaust0: Maintenance
free0: Maintenance
free
VEHICLE DIMENSIONS
Vehicle
dimensions
mm (in.)Sedan Wagon
(1) Overall
length5016.5 (197.5) 5069.8 (199.6)
(2) Overall
width1854.2 (73.0) 1854.2 (73.0)
(3) Overall
height1399.5 (55.1) 1463.0 (57.6)
(4) Wheelbase 2755.9 (108.5) 2755.9 (108.5)
(5) Track -
Front1564.6 (61.6) 1564.6 (61.6)
(5) Track -
Rear1559.6 (61.4) 1569.7 (61.8)
dno_vehicle-dimensions
