1997 Mercury Sable headlamp

when beam direction appears to be incorrect or a
level surface can not be verified.
The horizontal aim must be adjusted first. You will
need one 7 mm box wrench or open end wrench.
The following procedure assumes that the vehicle's
front structure is properly aligned. If the vehicle has
been in an accident requiring the front end of the
vehicle to be repaired, the horizontal indicator
should be recalibrated by the service facility.
Horizontal aim adjustment
1. With the hood open,
locate the horizontal
indicator and adjusting
screw.
2.Usea7mmwrench to turn the horizontal
adjusting screw until the reference mark on the
reflector extension aligns with the ª0º reference
mark on the horizontal indicator when viewed
directly from above.
3. When the horizontal aim has been adjusted, close
the headlamp access panel.
Adjusting the vertical aim
The numbers shown on the vial indicate beam
direction in degrees up or down.
1. Do not adjust the vertical aim until after adjusting
the horizontal aim.
R L
O
dno_aiming-headlamps
dno_aiming
Maintenance and care
145

2. With the hood open,
locate the bubble level
vertical aim indicator.
It is visible when
viewed from the above
rear of the headlamp.
3.Usea7mmwrench to turn the vertical adjusting
screw until the reference mark on the reflector
extension aligns with the ª0º reference mark on the
vertical indicator when viewed directly from above.
4. Close the hood.
CLEANING AND CARING FOR YOUR VEHICLE
Refer to the ªCustomer Assistance Guideº for a list
of Ford-approved cleaners, polishes and waxes.
Washing your vehicle
Wash your vehicle regularly
with cold or lukewarm
water. Never use strong
detergents or soap. If your
vehicle is particularly dirty,
use a quality car wash
detergent. Always use a
clean sponge, washing glove
or similar device and plenty of water for best results.
To avoid spots, avoid washing when the hood is still
warm, immediately after or during exposure to
strong sunlight.
During winter months, it is especially important to
wash the vehicle on a regular basis. Large quantities
of dirt and road salt are difficult to remove, and they
also cause damage to the vehicle. Remove anyR L
O
com_cleaning_caring.01
com_washing_vehicle.01
Maintenance and care
146
