Mini fuses
Fuse Amps Circuits protected
6 15 amp Generator/voltage
regulator
7 20 amp Not used
8 15 amp Foglamp relay,
daytime running lamp
module
9 - Not used
10 - Not used
11 20 amp HEGO system
Relays
Relays are located in the power
distribution box.
Relays receive signals from
components or systems and
transfer these signals to activate or
deactivate other components or
systems.
Mercury recommends that relays
be replaced by a qualified
technician.
6
5
3
2
14 21
Roadside emergencies
127
Relay number Circuits connected
1 Wiper run relay
2 Horn relay
3 Wiper HI/LO relay
4 WOT A/C relay
5 PCM power relay
6 Fuel pump relay
Diode number Circuits connected
1 ABS diode
2 PCM diode
CHANGING TIRES
Tire change procedure
1. Park on a level surface.
2. Activate the hazard flashers.
3. Set the parking brake.
4. Place the gearshift in P (Park).
5. Block the diagonally opposite
wheel.
6. Remove the jack and lug
wrench.
Roadside emergencies
128
Parts (see Motorcraft Parts) ...185
Power door locks ........................38
Power steering
fluid, checking and adding ....148
Rear climate control system ......45
Refill capacities for fluids ........185
Relays .................................127,128
Remote entry system
arming and disarming the
anti-theft system .................52,54
locking/unlocking doors ...........53
panic alarm ...............................53
replacement/additional
transmitters ...............................55
replacing the batteries .............54
Repairing paint chips ...............181
Reporting safety defects ..........192
Safety chains, when towing a
trailer .........................................113
Safety defects, reporting ..........192
Safety restraints ..........................63
adjusting the safety belts .........67
automatic locking mode
(retractor) .................................66
center rear lap belt ..................68
cleaning the safety belts ..........71
extension assembly ..................71
lap and shoulder belts .............64
maintenance ..............................69
proper use .................................64
replacement ..............................70
warning light and chime ..........69
Seats
adjusting the seat, manual .......59
adjusting the seats, power .......60
folding rear seats ......................62
head restraints ..........................62
Servicing your vehicle ..............136
precautions when
servicing ...........................136,138
servicing when you tow .........115
Shift-lock system ......................101Spare tire .....................................48
Speed control ..............................23
Speedometer .................................6
Starting your vehicle .............89,91
preparing to start your
vehicle ..................................89,91
starting a warm engine ............92
Steering wheel
tilting .........................................27
Tachometer ...................................6
Tail lamps
bulb replacement ....................174
Tilt steering wheel ......................27
Tire types ..................................163
Tires
changing ..................................128
checking the pressure ............160
replacing ...........................162,163
rotating .............................161,162
snow tires and chains ............163
treadwear ................................159
Towing your vehicle .................135
Trailer towing ..............110,113,114
calculating maximum trailer
weight ......................................111
tips ...........................................115
trailer brakes ...........................113
trailer lamps ............................114
Transfer case
fluid checking .........................152
Trip odometer ...............................7
Turn signal .........................174,176
Vehicle dimensions ...................190
Vehicle Identification Number
(VIN) ..........................................191
Ventilating your vehicle (see
Climate control) ..........................21
Washer fluid ..............................144
rear window reservoir ............145
Windows
power windows,
operating .........................35,36,37
