1997 Mercury Mercury Cougar steering

68 %
*
[CF16800( ALL)03/96]
Turning On the Exterior Lights
*
[CF17100( BCGV)05/96]
To turn on the headlamps, parking lamps, side
markers, license plate lamps and tail lamps, use
the rotary control that is to the left of the
steering wheel.
[CF17300( BC )05/96]
half page art:0010195-E
The knob that controls the headlamps and parking lamps
(shown with autolamp feature Ð other models similar)
[CF17501( ALL)04/96]
To turn on the parking lamps, license plate
lamps, tail lamps and marker lamps, move the
knob to the first position.
[CF17550( ALL)04/96]
To turn on the headlamps, parking lamps,
license plate lamps, tail lamps and marker
lamps, move the knob to the second position.
*
[CF17600( ALL)04/96]
For more information about how the high beams
work, see the high beam section later in this
chapter.
File:05rccfc.ex
Update:Fri Jun 7 13:58:04 1996

71 %
*
[CF20000( ALL)01/96]
Lighting Up the Interior and Instrument
Panel
[CF20100( BC )12/95]
Manual operation
*
[CF20200( BC )05/96]
With the light control in the parking lamps or
the headlamps position, you can brighten or dim
the lights in the instrument panel. To do this,
use the thumbwheel to the left of the steering
wheel. This wheel also turns on the interior
lights with the light control on or off.
[CF20205( BC )05/96]
Turn the thumbwheel down to dim the
instrument panel light and up to brighten. Turn
thumbwheel fully upward to turn on interior
lights.
[CF20500( BC )05/96]
half page art:0010206-D
The thumbwheel controls the light on the instrument panel
and the interior light
File:05rccfc.ex
Update:Fri Jun 7 13:58:04 1996

73
*
[CF24100( ALL)01/96]
Ignition
%*
[CF24200( ALL)01/96]
Understanding the Positions of the Ignition
[CF24300( ALL)12/95]
quarter page art:0010035-B
The positions of the key in the ignition
*
[CF24500( BCGV)04/96]
ACC allows some of your vehicle's electrical
accessories such as the radio and the windshield
wipers to operate while the engine is not
running.
% [CF24600( ALL)12/95]
LOCK locks the steering wheel. It also locks the
automatic transmission gearshift lever.
*
[CF24700( ALL)01/96]
LOCK is the only position that allows you to
remove the key. The LOCK feature helps to
protect your vehicle from theft.
*
[CF24800( ALL)01/96]
OFF allows you to shut off the engine and all
accessories without locking the steering wheel or
the automatic transmission gearshift lever.
*
[CF24900( ALL)01/96]
ON allows you to test your vehicle's warning
lights (except the brake system warning light) to
make sure they work before you start the
engine. The key returns to the ON position once
the engine is started and remains in this position
while the engine runs.
*
[CF25000( ALL)01/96]
START cranks the engine. Release the key once
the engine starts so that you do not damage the
starter. The key should return to ON when you
release it. The START position also allows you
to test the brake warning light.
File:05rccfc.ex
Update:Fri Jun 7 13:58:04 1996

74 %
*
[CF25100( ALL)03/96]
Removing the Key From the Ignition
*
[CF25200( BCGV)03/96]
1. Put the gearshift in P (Park).
*
[CF25400( ALL)01/96]
2. Set the parking brake fully.
*
[CF25500( BCGV)03/96]
3. Turn the ignition key to LOCK.
*
[CF25700( BCGV)03/96]
4. Remove the key.
[CF26300( BCGV)12/95]
NOTE: The automatic transmission gearshift
must be in P (Park) to move the key to
the lock position.
%*
[CF26400( ALL)01/96]
If the key is stuck in the LOCK position, move
the steering wheel left or right until the key
turns freely.
%*
[CF26500( ALL)12/95]
If the driver's door is open while the key is still
in the ignition, a warning chime sounds.
*
[CF26700( BCGV)05/96]
RWARNING
Always set the parking brake fully and
make sure the gearshift is latched in P
(Park). Turn off the ignition whenever you
leave your vehicle.
*
[CF26800( ALL)03/96]
RWARNING
Do not leave children, unreliable adults,
or pets unattended in your vehicle.
%
*
[CF26900( ALL)02/96]
The Turn Signal Lever
*
[CF27000( ALL)02/96]
You can use the turn signal lever on the left side
of the steering column to:
[CF27100( ALL)04/96]
q
operate the turn signals
*
[CF27200( ALL)03/96]
q
turn the high beams on/off
*
[CF27300( ALL)03/96]
q
flash the lamps
*
[CF27400( ALL)03/96]
q
turn the windshield wipers and washer
on/off
File:05rccfc.ex
Update:Fri Jun 7 13:58:04 1996

79
%*
[CF30700( ALL)05/96]
Horn
*
[CF30800( ALL)01/96]
To sound the horn, push the center pad area of
the steering wheel.
[CF30900( BC )12/95]
half page art:0001012-B
The horn on the steering wheel
File:05rccfc.ex
Update:Fri Jun 7 13:58:04 1996

80
%*
[CF31200( ALL)01/96]
Tilt Steering
*
[CF31300( ALL)02/96]
RWARNING
Never adjust the steering wheel when the
vehicle is moving.
[CF31400(MBC )12/95]
half page art:0010088-B
The lever to tilt the steering wheel
*
[CF31600( ALL)01/96]
To change the position of the steering wheel,
pull the release lever on the column toward you.
Tip the steering wheel to the desired position.
Release the lever to lock the steering wheel in
place.
File:05rccfc.ex
Update:Fri Jun 7 13:58:04 1996

81
%*
[CF31700( ALL)03/96]
Speed Control (If equipped)
[CF31730(MBC )03/96]
half page art:0001014-B
The speed control switches on the steering wheel
%*
[CF31800( ALL)05/96]
To Turn Speed Control Off
*
[CF31900( ALL)05/96]
q
Press OFF, OR
*
[CF32000( ALL)05/96]
q
Turn off the vehicle ignition.
*
[CF32100( ALL)05/96]
Once speed control is switched off, the
previously programmed set speed will be erased.
*
[CF32200( ALL)05/96]
To Turn Speed Control On
*
[CF32300( ALL)05/96]
q
Press ON
*
[CF32400( ALL)05/96]
To Set a Speed
*
[CF32500( ALL)05/96]
Press SET ACCEL. For speed control to operate,
the speed control must be ON and the vehicle
speed must be greater than 30 mph (48 km/h).
*
[CF32600( ALL)05/96]
If you drive up or down a steep hill, your
vehicle speed may vary momentarily slower or
faster than the set speed. This is normal.
File:05rccfc.ex
Update:Fri Jun 7 13:58:04 1996

98 [CF55300(MBC )12/95]You can also arm the anti-theft system by
following this sequence:
[CF55400(MBC )12/95]
1. Remove key from ignition.
*
[CF55500(MBC )01/96]
2. Close all of the doors.
[CF55600(MBC )05/96]
3. Press the remote entry transmitter LOCK
control. The alarm indicator will come on for
30 seconds to show the alarm is arming and
then turn off to show that the alarm has
armed.
*
[CF55800(MBC )01/96]
The anti-theft system is designed to work with
the factory installed remote entry system. It may
not work with other remote entry systems.
%*
[CF55900(MBC )03/96]
Disarming an Untriggered Anti-Theft
System
*
[CF56000(MBC )12/95]
You can disarm the system by:
[CF56100(MBC )12/95]
q
unlocking a door with the key (turn the key
all the way to the end of travel or the system
may not disarm.
*
[CF56200(MBC )04/96]
q
using the UNLOCK control on the remote
entry transmitter
[CF56300(MBC )12/95]
q
if remaining in the vehicle, turn the ignition
switch to ON or ACC
*
[CF56400(MBC )03/96]
Triggering the Alarm System
*
[CF56500(MBC )01/96]
The armed system will be triggered if:
[CF56600(MBC )12/95]
q
any door is opened without disarming the
system first (see previous paragraphs)
*
[CF56700(MBC )05/96]
q
the trunk lock cylinder is removed
*
[CF56800(MBC )05/96]
NOTE: You can open the trunk with your key
without setting off the alarm.
[CF57100( BC )12/95]
q
the ignition key lock cylinder is forcibly
removed from the steering column.
File:05rccfc.ex
Update:Fri Jun 7 13:58:04 1996
