1997 Mercury Grand Marquis Ignition switch

14
*
[IS07800( ALL)03/96]
This light illuminates every time you turn the
ignition to the ON or START position (engine
off). The light should go off when the engine
starts and the alternator begins to charge.
*
[IS07900( ALL)03/96]
If the light stays on or illuminates when the
engine is running, have the electrical system
checked as soon as possible.
%*
[IS08400( BCGV)03/96]
Overdrive Off Indicator
[IS08600( ALL)04/96]
one inch art:0010730-B
The overdrive off indicator light
*
[IS08700( ALL)04/96]
This light tells you that the Transmission Control
Switch (TCS) has been pushed. When the light is
on, the transmission will not shift into overdrive.
Depressing the button will return the vehicle to
ªoverdrive onº mode. The transmission will be
in the ªoverdrive onº mode when the vehicle is
started even if the O/D OFF mode was selected
when the vehicle was last shut off.
[IS08900( ALL)05/96]
NOTE: If the light does not come on when the
TCS is depressed or if the light flashes
when you are driving, have your
vehicle serviced at the first
opportunity. If this condition persists,
damage could occur to the
transmission.
File:03rcisg.ex
Update:Tue Jun 11 13:54:07 1996

16 [IS10700( GV)01/96]Normally, the light will glow momentarily as
you turn the ignition key to the ON position. If
it glows continuously:
[IS10800( GV)01/96]
1. Safely pull off the road as soon as possible.
Turn the ignition key from ON to OFF and
ON again.
[IS10900( GV)01/96]
2. If the light still glows, check to see if the air
suspension switch is OFF. If it is OFF, push
the switch ON. If it is ON, push the switch
OFF and have the system checked as soon as
possible.
%*
[IS11000(M GV)03/96]
Check Engine Warning Light
%*
[IS11100( ALL)05/96]
This light illuminates when the engine's
Emission Control System requires service. It will
also illuminate when the ignition key is in the
ON position and the engine is off.
[IS11300(M GV)05/96]
one inch art:0010134-B
The check engine warning light
%*
[IS12300( ALL)03/96]
Turn Signal Indicator Lights
*
[IS12400( ALL)03/96]
The turn signal arrow will flash to indicate the
direction in which you are going to be turning.
[IS12500( ALL)04/96]
one inch art:0010525-A
The turn signal indicator light
File:03rcisg.ex
Update:Tue Jun 11 13:54:07 1996

17 %
*
[IS14200( ALL)05/96]
Fuel Gauge
[IS14400( GV)12/95]
one third page art:0010695-A
The fuel gauge
[IS14600( ALL)12/95]
The fuel gauge displays approximately how
much fuel is in the fuel tank only when the
ignition switch is ON. For proper fuel gauge
indication after adding fuel, turn the ignition
switch OFF while refueling the vehicle.
[IS14700( ALL)12/95]
The fuel gauge indicator may vary slightly when
the vehicle is in motion. The most accurate
reading is obtained with the vehicle on level
ground.
*
[IS14800( ALL)01/96]
With ignition switch OFF, the fuel gauge
indicator may drift from the ignition switch ON
position.
[IS15600( GV)12/95]
When you turn the ignition key to the ON or
ACC position, all the display segments will light
up, then go off for a second indicating the gauge
is working. Then the gauge will show you how
much fuel you have in the tank.
%*
[IS15700( ALL)03/96]
Engine Coolant Temperature Gauge
*
[IS15800( ALL)02/96]
This gauge indicates the temperature of the
engine coolant, not the coolant level. If the
coolant is not at its proper level or mixture, the
gauge indication will not be accurate.
File:03rcisg.ex
Update:Tue Jun 11 13:54:07 1996

29 %
*
[IS25171( GV)05/96]
Fuel Gauge
[IS25172( GV)05/96]
one third page art:0010516-B
The fuel gauge
[IS25173( GV)03/96]
The fuel gauge tells you approximately how
many gallons/liters of fuel you have in the tank.
[IS25174( GV)03/96]
When your tank reaches 1/8 or approximately 2
gallons (8 liters), a flashing fuel pump will
appear.
[IS25175( GV)03/96]
Turn the ignition switch off while fueling to
obtain an accurate fuel gauge indication.
[IS25176( GV)03/96]
NOTE: At least 2.5 gallons (9.5 liters) of fuel
must be added for the fuel gauge to
immediately show the new level of
fuel. If less than 2.5 gallons (9.5 liters)
of fuel is added, the gauge will reach
the new level slowly.
[IS25177( GV)03/96]
If the fuel gauge displays only the top two bars
and the bottom two bars, or, if fuel remaining or
distance to empty functions display CO or CS,
then there is a problem. Take your vehicle in for
service.
File:03rcisg.ex
Update:Tue Jun 11 13:54:07 1996

37 [IS31700( GV)12/95]
one inch art:0010530-A
*
[IS31800( GV)05/96]
To reset either trip feature to zero, press the
RESET switch while a trip distance feature (Trip
A or Trip B) is displayed.
[IS31900( GV)12/95]
AVG SPEED Ð Average Speed
[IS32000( GV)12/95]
Select this function to display your average
speed in miles per hour or kilometers per hour.
[IS32100( GV)12/95]
one inch art:0011294-A[IS32200( GV)12/95]
Your vehicle must be moving to calculate your
average speed. When your vehicle is not
moving, the average speed is displayed at 0
miles per hour or 0 kilometers per hour.
[IS32300( GV)05/96]
Check Air Suspension Light (If equipped)
*
[IS32400( GV)05/96]
This light glows momentarily when the ignition
is turned to the ON position. With the ignition
on this light will remain on to indicate that the
air suspension switch (located in the trunk on
the right side) is off or to indicate a possible
system fault.
File:03rcisg.ex
Update:Tue Jun 11 13:54:07 1996

38
*
[IS32500( GV)05/96]
If the light is displayed while driving and the
air suspension switch is not turned off, safely
pull off the road as soon as possible. Turn the
ignition switch from ON to OFF and to ON
again. If the light continues to be displayed turn
the air suspension switch (located in the trunk
on the right side) off and take your vehicle to a
dealership for service as soon as possible.
[IS32600( GV)05/96]
one inch art:0010522-A
The check air suspension light
%*
[IS32700( GV)03/96]
Overdrive Off Indicator
[IS32800( GV)05/96]
one inch art:0010733-B
The overdrive off indicator light
*
[IS32900( GV)04/96]
This light tells you that the Transmission Control
Switch (TCS) has been pushed. When the light is
on, the transmission will not shift into overdrive.
Depressing the button will return the vehicle to
ªoverdrive onº mode. The transmission will be
in the ªoverdrive onº mode when the vehicle is
started even if the O/D OFF mode was selected
when the vehicle was last shut off.
File:03rcisg.ex
Update:Tue Jun 11 13:54:07 1996

55
[AS56240( G )05/95]
Electronic Search Cassette Radio
*
[AS56250( GV)03/96]
Using the Controls on Your New Radio
*
[AS56300( GV)03/96]
How to turn the radio on and off
*
[AS56350( GV)03/96]
Press the ªVOL/PUSH ONº knob to turn the
radio on. Press again to turn it off.
*
[AS56400( GV)03/96]
How to adjust the volume
[AS56450( GV)06/95]
Turn the ªVOL/PUSH ONº knob to the right to
increase the volume and to the left to decrease
the volume. Bars illuminate in the display to
show relative volume level.
*
[AS56460( GV)02/96]
NOTE: If the volume level is set above a
certain listening level when the
ignition switch is turned off, when the
ignition switch is turned back on, the
volume will come back to a ªnominalº
listening level. However, if the radio
power is turned off, the volume will
remain in the position it was set at
when radio power was switched off.
*
[AS56500( GV)03/96]
Selecting the AM or FM frequency band
*
[AS56550( GV)02/95]
Push the ªAM/FMº button to select the desired
frequency band or to stop/store cassette tape
(when in cassette mode). Pushing the button
more than once will alternate between AM, FM1
and FM2. These functions are used with the
station memory buttons described underHow to
tune radio stations.
File:04rcasg.ex
Update:Mon Sep 23 08:30:54 1996

96
%*
[CF31700( ALL)03/96]
Speed Control (If equipped)
[CF31760( GV)03/96]
half page art:0010096-D
The speed control switches on the steering wheel
%*
[CF31800( ALL)05/96]
To Turn Speed Control Off
*
[CF31900( ALL)05/96]
q
Press OFF, OR
*
[CF32000( ALL)05/96]
q
Turn off the vehicle ignition.
*
[CF32100( ALL)05/96]
Once speed control is switched off, the
previously programmed set speed will be erased.
*
[CF32200( ALL)05/96]
To Turn Speed Control On
*
[CF32300( ALL)05/96]
q
Press ON
*
[CF32400( ALL)05/96]
To Set a Speed
*
[CF32500( ALL)05/96]
Press SET ACCEL. For speed control to operate,
the speed control must be ON and the vehicle
speed must be greater than 30 mph (48 km/h).
*
[CF32600( ALL)05/96]
If you drive up or down a steep hill, your
vehicle speed may vary momentarily slower or
faster than the set speed. This is normal.
