48The AUTO temperature displayWhen in AUTOMATIC and weather conditions
require heat, air will be sent to the floor. But, a
feature is included in your EATC to prevent
blowing cold air to the floor if the engine coolant is
not warm enough to allow heating. In 3-1/2
minutes or less, the fan speed will start to increase
and the airflow will change to the floor area.If unusual conditions exist (i.e., window fogging,
etc.), the six manual override buttons allow you to
select special air discharge locations. A thumbwheel
allows you to adjust the fan speed to suit your
needs.
Temperature selectionThe RED and BLUE buttons at the upper left of the
Control are for temperature selection. The RED
Button will increase the set temperature and the
BLUE Button will lower the set temperature.
Pressing a button and releasing it will change the
set temperature one degree. Holding either button
in will rapidly change the temperature setting in
one degree increments to either65ÊF(18ÊC)
(BLUE) or85ÊF(29ÊC)(RED). Then, the set
temperature will jump 5 Ê and stop at either60ÊF
(16ÊC)which is maximum cooling or90ÊF(32ÊC)
which is maximum heating. When you select60ÊF
(16ÊC) or90ÊF(32ÊC), the fanwill go to HI speed
for maximum air flow.
File:05fncfc.ex
Update:Fri Sep 6 14:53:57 1996

213
Preparing Your Vehicle1. Your vehicle has a 12-volt starting system, so
you need to use a 12-volt jumper system. You
will damage your starting motor, ignition
system, and other electrical parts if you connect
them to a 24-volt power supply (either two
12-volt batteries in series or a 24-volt generator
set).
2. Do not disconnect the battery of the disabled
vehicle. You could damage the vehicle's
electrical system.3. Park the booster vehicle close to the hood of
the disabled vehicle.Make sure the vehicles
do not touch each other.Set the parking
brake on both vehicles and stay clear of the
engine cooling fan and other moving parts.
4. Check all battery terminals and remove any
excessive corrosion before you attach the
jumper cables.
5. Turn on the heater fan in both vehicles. Press
the DEFROST button. Turning on the fan helps
protect the electrical system from voltage
surges. Turn off all other switches and gauges.
File:10fnerc.ex
Update:Fri Sep 6 08:49:57 1996

216Jump-Starting1. Make sure that the jumper cables are not in
the way of moving engine parts, then start the
booster vehicle. Run the engine at a moderate
speed.
2. Let the discharged battery charge for a few
minutes and then start the disabled vehicle. It
may take a couple of tries before the vehicle
starts. If the vehicle does not start after several
attempts, there may be a different problem.
3. When both vehicles are running, let them idle
for a few minutes to charge the discharged
battery.Removing jumper cables1.Always remove the jumper cables in the
reverse order.Remove the negative (s) end
of the jumper cable from the metallic surface
on the engine or frame of the disabled vehicle.2. Remove the negative (s) cable from the
booster battery.
3. Remove the positive (+) cable from the booster
battery.
4. Remove the other end of the positive (+) cable
from the discharged battery.
After the vehicle is started, let it idle for a while to
let the engine ªrelearnº its idle conditions. Drive it
around for a while with all electrical accessories
turned off to let the battery recharge. Driveability
may be deteriorated slightly until all drive modes
are ªrelearned.ºYou may need to use a battery
charger to fully recharge the battery.
If you need to replace your battery, seeBatteryin
theMaintenance and Carechapter.
File:10fnerc.ex
Update:Fri Sep 6 08:49:57 1996

311
Electronic sound system (continued)
warranty and service information.... 44
Electronic stereo cassette radio
(see Electronic sound system)..... 27
Electronic stereo radio (see Electronic
sound system)............ 27
Emergencies, roadside
fuel................ 255
jump-starting............ 211
towing............... 217
Emergency brake (parking brake)..... 172
Emission control system......... 258
catalytic converter.......... 258
emissions warranty.........4,258
Engine
does not start.........167, 191
fuel injected engine, starting . . . 165, 166
fuel pump shut-off switch....... 191
preparing to start.......... 165
refill capacities............ 272
service points............ 224
starting............... 166starting after a collision........ 191
storing your vehicle......274, 275
Engine block heater........... 168
Engine coolant............. 231
checking and adding......... 231
disposal............220, 240
preparing for storage......... 275
proper solution........220, 240
recovery reservoir.......224, 231
refill capacities............ 272
specifications............ 273
temperature gauge.......... 17
Engine coolant temperature gauge..... 17
description............. 17
mechanical............. 17
Engine coolant temperature
guage:electronic........... 17
Engine fan............... 221
Engine knocking............ 253
Engine oil............... 226
ªbreak-inº oils............. 5
changing oil and oil filter....227, 228
File:fnixc.ex
Update:Tue Sep 17 08:28:54 1996

315
J
Jack................. 206
operation...........207, 208
positioning..........207, 208
storage............... 206
Jump-starting your vehicle
attaching cables........... 214
disconnecting cables......... 216
K
Keyless entry system
locking and unlocking doors...... 119
programming entry code....... 121
Keys
key in ignition chime......... 63
positions of the ignition........ 62
removing from the ignition...... 63
stuck in lock position........62,63
L
Lamps
autolamp delay system........ 57
checking.............. 261daytime running light system..... 56
flashing the lamps.......... 65
hazard flashers............ 68
headlamps.............. 57
high beams............. 65
interior lamps............ 56
replacing bulbs............ 261
trailer............... 188
Lane change indicator
(see Turn signal)......... 64,65
Lap belts............... 141
Lights, warning and indicator
airbag............... 15
anti-lock brakes (ABS)......... 11
anti-theft.............. 16
brake................ 10
charging system........... 13
engine oil pressure.......... 12
hazard warning light......... 68
high beam............. 15
lowoil............... 12
oil pressure............. 12
File:fnixc.ex
Update:Tue Sep 17 08:28:54 1996
