1997 FORD WINDSTAR ignition

Instrumentation
25
%*
[IS15502(ALL)07/96]
Electronic Cluster (If equipped)
[IS15503(ALL)07/96]
The Electronic Cluster works only when your ignition is in the
ON position. Each time you start your vehicle, the displays go
through a self-test by lighting up all segments for about one
second and then turning off all segments for about one second,
before displaying actual gauge readings. (The turn signal and
high beam indicators do not light during the self-test. The LOW
OIL light may remain on throughout the self-test and for several
seconds after normal readings are displayed.) This self-test
demonstrates that all of the display segments are working
properly.
[IS15505(ALL)07/96]
The electronic cluster has three major functions to provide you
with information about your vehicle's operating status:
[IS15507(ALL)07/96]
n
Warning and Indicator Lights
[IS15509(ALL)07/96]
n
Electronic Gauges
[IS15511(ALL)07/96]
n
The Fuel Computer
[IS15513(ALL)07/96]
The electronic cluster uses the same warning and indicator
lights as the mechanical cluster. However, the electronic cluster
contains some additional warning and indicator lights as
described here.
% [IS15515(ALL)07/96]
Oil Pressure Light
[IS15517(ALL)07/96]
6 pica art:0050150-B
The oil pressure light
File:03wniss.ex
Update:Thu Jul 18 10:55:19 1996

26
[IS15519(ALL)07/96]
This light indicates the engine's oil pressure, not the oil level.
However, if your engine's oil level is low, it could affect the oil
pressure. The light will come on briefly during the display
self-test every time you turn your key to the ON position. The
light will go off when the key is turned to the START position.
The light should stay off when the self-test is done if the engine
is running with normal oil pressure. If the light comes on while
the engine is running, you have lost oil pressure and continued
operation will cause severe engine damage.
*
[IS15521(ALL)07/96]
If you lose engine oil pressure:
*
[IS15523(ALL)07/96]1.
Pull off the road as soon as safely possible.
*
[IS15525(ALL)07/96]2.
Shut off the engine immediately. If you do not stop the
engine as soon as safely possible, severe engine damage
could result.
[IS15527(ALL)07/96]3.
Check the engine's oil level. (See ªChecking and Adding
Engine Oilº in theMaintenance and Carechapter of this
Owner Guide.) If you do not follow these instructions, you
or others could be injured. To ensure an accurate reading,
your vehicle should be on level ground.
[IS15529(ALL)07/96]4.
If the level is low, add only as much oil as necessary before
you start the engine again. Do not overfill. Do not operate
the engine if the light is on regardless of the oil level.
Contact your nearest dealer for further service.
% [IS15531(ALL)07/96]
Low Windshield Washer Fluid Level Warning Light
[IS15533(ALL)07/96]
This light indicates that the level of your washer fluid is low,
and you have to add more fluid. This light comes on briefly
after you turn your ignition key from the START to the ON
position. If the washer fluid is low, a one second chime will
sound and the light will remain on for 60 seconds. If the washer
fluid is not low, the light should turn off a few seconds after
the engine has started. The light and chime also come on if the
washer fluid is low when you use your windshield washers.
File:03wniss.ex
Update:Thu Jul 18 10:55:19 1996

Instrumentation
27
[IS15535(ALL)07/96]
The washer fluid is only checked when the engine is started or
the windshield washers are in operation. The light will not
come on if the fluid level becomes low while you are driving
unless you turn on the windshield washers.
[IS15537(ALL)07/96]
6 pica art:0050062-B
The low windshield washer indicator light
[IS15539(ALL)07/96]
Speed Control Indicator
[IS15541(ALL)07/96]
A SPEED CONTROL light is displayed in the optional electronic
instrument cluster when the speed control system is engaged.
The display will turn off when the brake pedal is pressed or if
speed control is shut off.
*
[IS15543(ALL)07/96]
This display does not indicate any problems with the speed
control, but is simply a convenient way of knowing when it is
active.
[IS15545(ALL)07/96]
6 pica art:0050220-A
The speed control light
% [IS15547(ALL)07/96]
Hazard Flasher Indicator Light
[IS15549(ALL)07/96]
This light flashes when you turn on the hazard flashers. If your
ignition is ON, the turn signal indicator lights in the electronic
cluster will flash in time with the hazard flashers.
File:03wniss.ex
Update:Thu Jul 18 10:55:19 1996

28
[IS15551(ALL)07/96]
6 pica art:0050237-A[IS15553(ALL)07/96]
Electronic Gauges
%*
[IS15555(ALL)07/96]
Fuel Gauge
[IS15556(ALL)07/96]
The fuel gauge displays approximately how much fuel you have
in the fuel tank. The number of bars illuminated in the display
indicates fuel level. Your ignition must be in the ON position to
read the fuel gauge. Read the fuel level at the top bar that is lit.
When only one bar on the gauge is lit, the fuel pump symbol
on the gauge will flash to warn you of a low fuel level
condition.
[IS15557(ALL)07/96]
If the fuel gauge displays only the top two bars and bottom two
bars, or if the Distance to Empty function in the fuel computer
displays CO or CS, you must have the fuel indication system
serviced.
[IS15558(ALL)07/96]
Turn your ignition to OFF while fueling to obtain an accurate
fuel gauge indication. If you do not turn your ignition off, the
fuel gauge will not display the new fuel level immediately, but
will slowly increase to the correct value.
File:03wniss.ex
Update:Thu Jul 18 10:55:19 1996

Instrumentation
33
[IS16600(ALL)01/96]
Fuel Computer Buttons
[IS16700(ALL)01/96]
The fuel computer functions are controlled by the three buttons
located to the right of the electronic cluster:
[IS16800(ALL)01/96]
7-1/2 pica art:0050049-A
The fuel computer buttons
% [IS16900(ALL)01/96]
SELECT Ð The SELECT button lets you choose the function
displayed by the fuel computer. Each time you press the
SELECT button, the fuel computer points to the next choice on
the menu. After it reaches the last choice, it returns to the top
of the menu.
% [IS17000(ALL)01/96]
E/M Ð The E/M button lets you switch the fuel computer
functions and the speedometer and odometer displays between
English and metric units. The displays remain in the chosen
units until you switch them again, even after you turn off the
vehicle and restart it.
% [IS17100(ALL)01/96]
RESET Ð The RESET button lets you reset or initialize the fuel
computer function that is displayed. Only TRIP DISTANCE,
AVERAGE ECONOMY, and AVERAGE SPEED can be reset.
[IS17200(ALL)01/96]
Any time one of the fuel computer buttons is pressed, a short
chime will sound.
[IS17300(ALL)01/96]
The Fuel Computer Functions
[IS17400(ALL)01/96]
The complete fuel computer menu is displayed for about five
seconds after the cluster self-test (when the ignition is turned to
ON) and after the SELECT button is pressed. After five seconds,
only the selected function is displayed.
File:03wniss.ex
Update:Thu Jul 18 10:55:19 1996

36
[IS18700(ALL)01/96]
The fuel computer will automatically warn you when your
distance to empty is low. When your distance to empty reaches
50 miles (80 km), 25 miles (40 km) and 10 miles (20 km), the
fuel computer will automatically select DISTANCE TO EMPTY,
flash the number for five seconds, and sound a one second
chime.
[IS18800(ALL)01/96]
If the Distance to Empty function displays CO or CS, you must
have the fuel indication system serviced.
[IS18900(ALL)01/96]
Turn your ignition to OFF while fueling to obtain an accurate
distance to empty reading. If you do not turn your ignition off,
the fuel computer will not display the new distance to empty
immediately, but will slowly increase to the correct value.
[IS19000(ALL)01/96]
AVERAGE SPEED
[IS19100(ALL)01/96]
Your average speed is the average speed your vehicle has
traveled while the ignition was ON since the last reset. To
display your average speed, press SELECT until the pointer is at
AVERAGE SPEED. Press the RESET button when AVERAGE
SPEED is selected to reset the average speed. You may want to
use this feature to see what your average speed is during daily
driving or on a long trip.
File:03wniss.ex
Update:Thu Jul 18 10:55:19 1996

Instrumentation
39
% [IS20400(ALL)01/96]
Anti-Theft Active Indicator Light
[IS20500(ALL)07/96]
This indicator is used in the optional Anti-Theft System. See
ªAnti-Theft Systemº in theControls and Featureschapter of this
Owner Guide.
[IS20600(ALL)01/96]
6 pica art:0050123-B
The anti-theft active indicator light
[IS20700(ALL)01/96]
Air Suspension Warning Light
[IS20800(ALL)01/96]
6 pica art:0050227-A
The air suspension warning light
[IS20900(ALL)01/96]
The warning light for the Air Suspension indicates one of two
things:
[IS21000(ALL)01/96]1.
The service switch (located in the jack storage area) is in the
ªoffº position.
[IS21100(ALL)01/96]2.
A system malfunction has occurred electronically disabling
Air Suspension function.
[IS21200(ALL)01/96]
NOTE: If the switch is returned to or in the ªONº position
and the light does not go out after recycling the
ignition switch OFF/ON, the Air Suspension should
be checked by a qualified service technician.
File:03wniss.ex
Update:Thu Jul 18 10:55:19 1996

42
%*
[AS01175(ALL)10/95]
Compact Disc Radio
*
[AS01250(ALL)10/95]
The Compact Disc Radio combines the Electronic Stereo Radio
with the Ford Compact Disc Player.
*
[AS01300(ALL)08/95]
Using the Controls on Your New Radio/CD Player
*
[AS01400(ALL)04/92]
Most of the features of this unit work for both radio and CD
operation, depending on which mode the unit is in. Also, some
of the buttons control several different functions, so be sure to
read all of the operating instructions carefully.
*
[AS01500(ALL)03/96]
How to turn the radio on and off
*
[AS01600(ALL)10/95]
Press the ªPOWERº button to turn the radio on. Press it again
to turn it off.
*
[AS01625(ALL)03/96]
How to adjust the volume
*
[AS01650(ALL)03/96]
Press the (R/S) side of the ªVOLº button to increase/decrease
the volume. Bars illuminate in the display to show the relative
volume level.
*
[AS01675(ALL)02/96]
NOTE: If the volume level is set above a certain listening
level when the ignition switch is turned off, when the
ignition switch is turned back on, the volume will
come back to a ªnominalº listening level. However, if
the radio power is turned off, the volume will remain
in the position it was set at when radio power was
switched off.
*
[AS01700(ALL)03/96]
Selecting the AM or FM frequency band
*
[AS01800(ALL)10/95]
Push the ªAM/FMº button to select the desired frequency band.
When in the radio mode, pushing the button more than once
will alternate between AM, FM1 and FM2. These functions are
used with the station memory buttons described underHow to
tune radio stations.
File:04wnass.ex
Update:Mon Jul 8 14:13:42 1996
