1997 FORD PROBE buttons

41
*
[AS25896(ALL)02/96]
q
Using the Automatic Music Search (ªAMSº)
function with cassette tape player
*
[AS25897(ALL)03/96]
Press and hold the ªAMSº button (ªAMSº will
appear in the display). Then, push the left
h
button to rewind to the beginning of the current
selection or press the right
gbutton to fast
forward to the beginning of the next selection.
*
[AS25900(ALL)09/95]
q
Fast forwarding the tape
*
[AS26000(ALL)04/96]
Push the right
gbutton to fast forward
the tape.
*
[AS26100(ALL)08/95]
q
Rewinding the tape
*
[AS26200(ALL)04/96]
Push the left
hbutton to rewind the tape.
*
[AS26900(ALL)08/95]
q
How to change the side of the tape being
played
*
[AS27000(ALL)09/95]
The alternate track (other side) of the tape
can be selected at any time by pushing both
fast-wind buttons (
hand
g) at the
same time. The number in the display will
alternate between 1 and 2.
*
[AS27100(ALL)08/95]
How to eject the tape
*
[AS27250(ALL)04/96]
To stop the tape and eject the cassette, press the
eject (i) button. The radio will resume playing.
*
[AS27300(ALL)02/96]
Using the DolbyHB noise reduction feature
*
[AS27400(ALL)09/95]
NOTE: Noise reduction system manufactured
under license from Dolby Labs
Licensing Corporation. ªDolbyº and
double-D symbol are trademarks of
Dolby Laboratories Licensing
Corporation.
*
[AS27550(ALL)05/95]
Push station memory button 3 to activate DolbyH
B Noise Reduction.
File:04prasp.ex
Update:Mon Jun 3 10:03:33 1996

57 [CF10120(ALL)05/96]
Rear Window Wiper and Washer
[CF10140(ALL)05/96]
The rear window wiper and washer buttons are
located on the instrument panel below the
climate control panel.
[CF10160(ALL)05/96]
one inch art:0032069-D[CF10180(ALL)05/96]
To operate the rear wiper, push the rear window
wiper button. Push the button a second time to
turn the wiper off. To operate the rear washer,
push and hold the rear window washer button
in. The washer will spray until the button is
released.
%*
[CF10182(ALL)05/96]
Fog Lamps (If equipped)
[CF10184(ALL)05/96]
The fog lamps only operate when the headlamps
are on low beam. To activate fog lamps, push
the button on the control panel below the
climate controls. An indicator light on the button
will illuminate. Push the button again to turn
the fog lamps off.
[CF10186(ALL)05/96]
quarter page art:0032079-E
Fog lamp button
File:05prcfp.ex
Update:Tue Jun 11 11:03:33 1996

59 [CF11000(ALL)01/96]
half page art:0030286-L
Interior/map lamp control panel
[CF11100(ALL)01/96]
Map lamps (if equipped)
[CF11200(ALL)01/96]
The map lamps can be turned on by using the
interior/map lamp control panel located between
the sun visors.
[CF11300(ALL)01/96]
There are two map lamps, one for the driver
and one for the passenger. To turn on the map
lamp, push the button that is next to the lamp.
Push the buttons again to turn the map lamps
off.
File:05prcfp.ex
Update:Tue Jun 11 11:03:33 1996
