6. Remove the jack and fully tighten the lug
nuts in the order shown in the following
illustration. As soon as possible, have your
dealer or a qualified service technician check
the lug nuts for proper torque specifications.
% [ER16100( ALL)12/95]
quarter page art:0010350-A
The lug nuts on the wheel
*
[ER16200(MBC )03/96]
7. Place any wheel covers and ornaments in the
trunk.
*
[ER16300(MBC )03/96]
8. Put the tire, jack, and wrench away. Make
sure the jack is securely fastened so it does
not rattle when you drive.
*
[ER16400(MBC )03/96]
9. Unblock the wheels.
% [ER16600(MBC )12/95]
Aluminum Road Wheel Ornaments
(If equipped)
[ER16700(MBC )12/95]
To remove the ornament, stick the tapered end
of the jack handle between the ornament and
wheel and pry off the ornament.
[ER16800(MBC )12/95]
To replace the ornament, stick one side of the
ornament into the center of the wheel and strike
the other side with the palm of your hand.
[ER18300(M GV)12/95]
Remove the base wheelcover from the wheel
using the flanged end of the wheel nut wrench
by inserting the handle and then prying against
the inner wheelcover flange.
[ER18301(MBC )02/97]
Remove the exposed lug nut wheel cover by
using the wheel lug nut wrench to unscrew each
lug nut cover counter-clockwise.
File:10rcerm.ex
Update:Tue Mar 4 10:01:28 1997

289 [AC00910(M )05/94]
NOTE: Use only hook and pad design roof
racks. Follow all manufacturers
recommendations including vehicle
speed, rack loads and tie down
procedures. Also, DO NOT over torque
the hook clamp, as vehicle damage
may occur.
*
[AC01400( ALL)09/95]
NOTE: When adding accessories, equipment,
passengers, and luggage to your
vehicle, do not exceed the total weight
capacity of the vehicle or of the front
or rear axle (GVWR, GAWR as shown
on the Safety Compliance Certification
Label). Consult your dealer for specific
weight information.
[AC01500( ALL)09/95]
NOTE: The Federal Communications
Commission (FCC) or in Canada the
Canadian Radio Telecommunications
Commission (CRTC) regulates the use
of mobile communications systems Ð
such as two-way radios, telephones,
and theft alarms Ð that are equipped
with radio transmitters. Any such
equipment installed in your vehicle
should comply with FCC regulation
and should be installed only by a
qualified technician.
