157
*
[GF08375(FM)05/96]
P (Park)
*
[GF08400(FM)05/96]
Always come to a complete stop before you shift
into P (Park). This position locks the
transmission and prevents the rear wheels from
turning. To securely latch the gearshift in the P
(Park) position, pull it toward you, push it
completely counterclockwise against the stop,
and then push it toward the instrument panel.
*
[GF08425(FM)05/96]
The gearshift is securely latched in P (Park) if
you cannot rotate it in a clockwise direction
without lifting it toward you.
*
[GF08450(FM)05/96]
RWARNING
Always set the parking brake fully and
make sure the gearshift is latched in P
(Park). Turn off the ignition whenever you
leave your vehicle.
[GF08475(F )05/96]
When the transfer case is in the N (Neutral)
position, the engine and transmission are
disconnected from the rest of the driveline.
Therefore, the vehicle is free to roll even if the
automatic transmission is in P (Park) or the
manual transmission is in gear.
*
[GF08500(F )05/96]
RWARNING
Do not leave the vehicle unattended with
the transfer case in the N (Neutral)
position. Always set the parking brake
fully and turn off the ignition when
leaving the vehicle.
*
[GF08525(FM)05/96]
RWARNING
Never leave your vehicle unattended
while it is running.
File:09ltgff.ex
Update:Thu May 30 15:25:49 1996
ProCarManuals.com

170 % [GF17300(F )04/96]Lever Operated System With Manual
Locking Hubs
*
[GF17350(F )01/96]
To shift from 2H to 4H:
*
[GF17400(F )01/96]
Stop the vehicle and engage the manual locking
hubs by turning both hub lock selector knobs
clockwise to the LOCK position. Move the
transfer case shift lever straight back to the 4H
position. After both hubs have been turned to
the LOCK position, shifts between 2H and 4H
(or 4H to 2H) may take place at any speed.
[GF17450(F )04/96]
one third page art:0020146-C
Locking hub positions
[GF17500(F )04/96]
q
Do not drive the vehicle in 4H or 4L with the
manual locking hubs in the FREE position.
[GF17550(F )04/96]
q
Do not drive the vehicle with the left and
right manual locking hubs set to different
positions.
*
[GF17600(F )01/96]
To shift from 4H to 2H:
*
[GF17650(F )03/96]
Move the transfer case shift lever forward to the
2H position. This can be done at any speed.
However, the front driveline will remain
engaged to the front wheels until the manual
locking hubs are disengaged. To disengage the
manual locking hubs, stop the vehicle and rotate
both hub lock selector knobs counterclockwise to
the FREE position.
