1997 FORD CONTOUR mirror controls

Controls and Features
51
[CF04300(ALL)12/95]
Passenger Compartment Air Filter (if equipped)
[CF04400(ALL)04/96]
Your vehicle may have an air filter that removes pollen and
road dust from outside air before it is directed to the interior of
the vehicle. For maintenance of this filter, see theMaintenance
and Carechapter.
% [CF04500(ALL)03/96]
Rear Window Defroster (If equipped)
[CF04600(ALL)04/96]
The defroster for the rear window clears frost, fog, or thin ice
from both the inside and outside of the rear window.
[CF04700(ALL)12/95]
The button for the rear window defroster is on the instrument
panel, to the right of the steering wheel.
[CF04800(ALL)12/95]
6 pica art:0001180-C
The rear window defroster and heated side view mirrors
[CF04900(ALL)12/95]
Clear away any snow that is on the rear window before using
the defroster. With the engine running, push the defroster
button.
*
[CF05000(ALL)01/96]
After approximately 10 minutes, the defroster will turn off. If
the window is still not clear, turn the defroster on again.
*
[CF05100(ALL)01/96]
The defroster will turn off when the ignition key is turned to
the OFF or START position.
File:05cdcfo.ex
Update:Fri Sep 13 08:48:17 1996

74
[CF24100(ALL)12/95]
Rear window lockout
[CF24200(ALL)12/95]
To lock out the rear window switches with the master controls,
slide the lockout switch to the left. To restore individual control,
slide the switch to the right.
%*
[CF24300(ALL)03/96]
Mirrors
%*
[CF24400(ALL)01/96]
Side View Mirrors
[CF24500(ALL)12/95]
The standard side view mirrors are manually adjusted by using
the remote knobs. The knob on each door adjusts the mirror on
that side of the vehicle. Move the control knob in the direction
you want to move the mirror.
[CF24600(ALL)12/95]
10-1/2 pica
art:0000463-B
The left side mirror control (right side similar)
% [CF24700(ALL)12/95]
Dual electric remote control mirrors (if equipped)
[CF24800(ALL)12/95]
The control for adjusting the electric side view mirrors is on the
instrument panel, to the left of the steering wheel.
File:05cdcfo.ex
Update:Fri Sep 13 08:48:17 1996

Controls and Features
75
[CF24900(ALL)12/95]
10-1/2 pica
art:0001182-B
Electric remote control mirror knob
[CF25000(ALL)12/95]
Turn the knob back to the middle position to keep the mirror in
place.
*
[CF25100(ALL)12/95]
The side view mirror on the right is a convex mirror. This
mirror gives you a wider view of the lanes on your right and
behind you.
*
[CF25200(ALL)05/96]
RWARNING
The right side view mirror makes objects appear smaller
and farther away than they actually are.
%*
[CF25300(ALL)12/95]
Do not clean the housing or glass of any mirror with harsh
abrasives, fuel or other petroleum-based cleaning products.
File:05cdcfo.ex
Update:Fri Sep 13 08:48:17 1996

275
Index
Cold engine starting.................. 118
Combination lap and shoulder belts............ 89
Compact disc player (see Electronic sound system)..... 24
Compact disc radio (see Electronic sound system)..... 24
Console, description................... 76
Controls, mirrors.................... 74
Convenience kit in cargo area.............. 162
Coolant (see Engine coolant).............. 191
checking and adding................ 191
preparing for storage................ 233
refill capacities................... 230
specifications.................... 231
temperature gauge.................. 19
warnings...................... 191
Cooling fan...................... 178
Crankcase ventilation filter............... 229
Customer Assistance Centre, Ford of Canada....... 244
D
Daytime running light system.............. 53
Defects, reporting................... 235
Defrost, rear window.................. 51
Dipstick....................... 185
automatic transaxle fluid............... 195
engine oil..................... 185
power steering fluid................. 194
Disabled vehicle (see Towing).............. 174
Doors......................... 71
lubricant specifications................ 231
Driving under special conditions............ 145
bad weather.................... 145
heavy load..................... 139
high water..................... 147
slippery roads................... 145
tips for safe driving................. 145
towing a trailer................... 141
File:cdixo.ex
Update:Thu Sep 12 11:12:35 1996
