Driving
129
*
[GF03100(ALL)01/96]
Always check the Brake Warning Light each time you start your
engine. Driving with the parking brake on will cause the brakes
to wear out quickly and will reduce the fuel economy.
%*
[GF03200(ALL)02/96]
Traction Control (If equipped)
[GF03300(ALL)12/95]
The traction control system prevents the wheels from spinning
on slippery roads.
[GF03400(ALL)12/95]
Working with the anti-lock brake system, the traction control
system monitors the speed of the wheels as they roll over the
road surface. When a wheel starts to spin because of slippery
conditions, the traction control system slows the engine by
closing the throttle. At speeds below 35 mph (55 km/h) the
traction control system also applies the brake to the spinning
wheel.
[GF03500(ALL)12/95]
When the traction control system becomes active, the driver
may notice a very slight kick and then a hard resistance in the
accelerator pedal, and a mechanical noise. The traction control
system light on the instrument panel comes on or flashes on
and off during activation.
[GF03600(ALL)12/95]
The traction control system can be turned off manually by
pushing the T/C OFF button on the instrument panel to the left
of the steering wheel. The traction control system light will
remain on as a reminder that the system is turned off.
[GF03700(ALL)12/95]
Each time the vehicle is started, the traction control system will
automatically be on. When the ignition is turned to the ON
position, the traction control system light comes on for
approximately three (3) seconds.
[GF03800(ALL)12/95]
If the light does not come on when the ignition is turned to the
ON position or if it does not come on when the T/C OFF
button is pressed, have the system serviced by your dealer or a
qualified service technician as soon as possible to restore the
benefits of the traction control feature. You do not need to have
the vehicle towed in.
File:09cdgfo.ex
Update:Thu Sep 12 11:04:39 1996

177
Maintenance and Care
%*
[MC00200(ALL)01/96]
Service Made Easy
*
[MC00300(ALL)01/96]
Ford has two goals for servicing your vehicle.
*
[MC00400(ALL)01/96]1.
When we can, we design parts that do not need to be
serviced.
*
[MC00500(ALL)01/96]2.
We want to make servicing your vehicle as easy as possible.
To help you:
*
[MC00600(ALL)01/96]
n
We highlight do-it-yourself items in yellow in the engine
compartment so that you can find them easily.
*
[MC00700(ALL)03/96]
n
When possible, we design parts that can be replaced without
tools.
*
[MC00800(ALL)02/96]
n
We give you a Maintenance Schedule that makes tracking
routine service for your vehicle easy. The maintenance
schedule is located in theMaintenance Schedulebooklet.
*
[MC00900(ALL)01/96]
This chapter tells you about the basic parts that you need to
check and service regularly.
*
[MC01000(ALL)01/96]
If your vehicle needs professional servicing, your dealership can
provide the parts and service required. Check yourWarranty
Information Bookletto find out which parts and services are
covered. Also see theCustomer Assistancechapter of this Owner
Guide.
*
[MC01100(ALL)02/96]
Ford Motor Company recommends that the Owner Maintenance
Checks listed in theMaintenance Schedulebooklet be performed
for the proper operation of your vehicle. In addition to the
conditions listed in theOwner Maintenance Checklist, be alert for
any unusual noise, vibration, or other indication that your
vehicle may need service. If you do notice something unusual,
see that your vehicle is serviced promptly.
*
[MC01200(ALL)01/96]
Use only recommended fuels, lubricants, fluids, and service
parts conforming to Ford specifications. Motorcraft parts are
designed and built to provide the best performance in your
vehicle. Using these parts for replacement is your assurance that
Ford-built quality stays in your vehicle.
File:11cdmco.ex
Update:Thu Sep 12 11:08:18 1996

Maintenance and Care
185
%*
[MC05400(ALL)01/96
]
Checking and Adding Engine Oil
*
[MC05500(ALL)01/96]
Since the proper amount of engine oil is important for safe
engine operation, check the oil using the dipstick each time you
put fuel in your vehicle. Remember the engine must be off, the
oil must be warm and the vehicle must be parked on level
ground.
%*
[MC05600(ALL)01/96
]
Checking the engine oil level:
*
[MC05700(ALL)01/96]1.
Turn the engine off after it has warmed up and allow a few
minutes for the engine oil to drain back into the oil pan.
*
[MC05800(ALL)01/96]2.
Set the parking brake fully and make sure that the gearshift
is securely latched in P (Park) (automatic transaxle) or 1
(First) (manual transaxle).
*
[MC05900(ALL)01/96]3.
Open the hood. Protect yourself from engine heat.
*
[MC06000(ALL)01/96]4.
Locate the engine oil dipstick (highlighted in yellow) and
carefully pull it out of the engine.
*
[MC06100(ALL)01/96]5.
Wipe the dipstick clean and put it back into position, making
sure it is fully seated.
[MC06200(ALL)12/95]
6 pica art:0001305-A
Engine oil dipstick (2.0L engine)
File:11cdmco.ex
Update:Thu Sep 12 11:08:18 1996

186
[MC06300(ALL)12/95]
6 pica art:0001245-A
Engine oil dipstick (2.5L engine)
[MC06400(ALL)12/95]6.
2.0L engine:Carefully, pull the dipstick out again. If the oil
level is below the lower notch, add engine oil as necessary.
If the oil level is beyond the upper notch, engine damage
and/or high oil comsumption may occur and some oil must
be removed from the engine.
[MC06500(ALL)12/95]
2.5L engine:Carefully, pull the dipstick out again. If the oil
level is below the MIN line, add engine oil as necessary. If
the oil level is above the letter M in MAX, engine damage
and/or high oil consumption may occur and some oil must
be removed from the engine.
*
[MC06600(ALL)01/96]7.
Put the dipstick back in and make sure it is fully seated.
*
[MC06700(ALL)01/96]
It may be necessary to add some oil between oil changes. Make
sure you use a CERTIFIED engine oil of the preferred viscosity.
Your vehicle's warranty coverage may not apply if engine
damage is caused by the use of improper engine oil.
*
[MC06800(ALL)01/96]
Add engine oil through the oil filler cap highlighted in yellow.
To add oil, remove the filler cap and use a funnel to pour oil
into the opening. Be careful not to overfill the engine. Recheck
the oil level after you finish adding oil.
[MC06900(O )04/96]
Nearly all engines will consume engine oil. As a result, it may
be necessary to add some oil between oil changes.
File:11cdmco.ex
Update:Thu Sep 12 11:08:18 1996

216
*
[MC29700(ALL)01/96]
n
Underinflated tires
*
[MC29800(ALL)01/96]
n
Heavy loads
*
[MC29900(ALL)01/96]
n
Aftermarket add-ons such as bike, ski or luggage racks, bug
deflectors, etc.
*
[MC30000(ALL)12/95]
Self-Service Pointers
*
[MC30100(ALL)12/95]
If you choose to do your own fueling, you should also perform
a few simple maintenance routines. This extra effort will save
you additional money and contribute to the driving efficiency of
your vehicle.
*
[MC30200(ALL)12/95]
The following procedures require only a tire gauge, a rag, an oil
can spout and windshield washer fluid.
*
[MC30300(ALL)12/95]
n
Check the engine oil at every refueling stop
*
[MC30400(ALL)12/95]
n
Clean the windshield, outside mirrors and headlights
*
[MC30500(ALL)12/95]
n
Check windshield washer fluid
*
[MC30600(ALL)12/95]
n
Check tires for excessive wear or worn edges
*
[MC30700(ALL)12/95]
n
Check the tire pressure at least monthly
%*
[MC30800(ALL)01/96]
Emission Control System
*
[MC30900(ALL)01/96]
Your vehicle is equipped with a catalytic converter which
enables your vehicle to comply with applicable exhaust emission
requirements.
*
[MC31000(ALL)05/96]
RWARNING
Exhaust leaks may result in the entry of harmful and
potentially lethal fumes into the passenger compartment.
Under extreme conditions excessive exhaust temperatures
could damage the fuel system, the interior floor covering,
or other vehicle components, possibly causing a fire.
File:11cdmco.ex
Update:Thu Sep 12 11:08:18 1996

218
*
[MC31700(ALL)01/96]
RWARNING
Do not park, idle, or drive your vehicle in dry grass or
other dry ground cover. The emission system heats up
the engine compartment and exhaust system, which can
start a fire.
*
[MC31800(ALL)01/96]
Watch for fluid leaks, strange odors, smoke, loss of oil pressure,
the charge warning light, the check engine light, or the
temperature warning light. These sometimes indicate that the
emission system is not working properly.
*
[MC31900(ALL)01/96]
Do not make any unauthorized changes to your vehicle or
engine. Changes that cause more unburned fuel to reach the
exhaust system can increase the temperature of the engine or
exhaust system.
*
[MC32000(ALL)01/96]
By law, anyone who manufactures, repairs, services, sells, leases,
trades vehicles, or supervises a fleet of vehicles is not permitted
to intentionally remove an emission control device or prevent it
from working. In some of the United States and in Canada,
vehicle owners may be liable if their emission control device is
removed or is prevented from working.
*
[MC32100(ALL)01/96]
Do not drive your vehicle if it does not operate properly. See
your dealer if the engine runs on for more than five seconds
after you shut it off or if it misfires, surges, stalls, or backfires.
%*
[MC32200(ALL)01/96
]
Information about your vehicle's emission control system is on
the Vehicle Emission Control Information decal located on or
near the engine. This decal identifies engine displacement and
gives some tune-up specifications.
File:11cdmco.ex
Update:Thu Sep 12 11:08:18 1996

Maintenance and Care
219
%*
[MC32300(ALL)03/96
]
How to Prepare Your Vehicle for
Inspection/Maintenance (I/M) Testing
*
[MC32400(ALL)05/96]
In some localities it may become a legal requirement to pass an
Inspection/Maintenance (I/M) test of the On-Board Diagnostic
(OBD) II system. If the vehicle's powertrain system or its battery
has just been serviced, the OBD II system is reset to a not ready
for I/M testing condition. To prepare for I/M testing, the law
specifies that additional mixed city and highway driving is
required to complete the check of the OBD II system.
*
[MC32500(ALL)05/96]
OBD II Drive Cycle
*
[MC32601(ALL)05/96]
The driving modes required to reach the ready condition consist
of a minimum of 30 minutes of city and highway driving as
described below:
*
[MC32701(ALL)05/96]
n
At least twenty minutes driving in stop and go, city type
traffic with at least four idle periods.
*
[MC32801(ALL)05/96]
n
At least ten minutes of driving on an expressway or
highway.
*
[MC32901(ALL)05/96]
Before completing the above driving modes, the engine must be
warmed up and at operating temperature. Once started, the
vehicle must not be turned off during these driving modes.
%*
[MC34300(ALL)03/96]
Lights and Bulb Replacement
*
[MC34400(ALL)01/96]
It is a good idea to check the operation of the following lights
frequently:
*
[MC34500(ALL)01/96]
n
headlamps
*
[MC34600(ALL)01/96]
n
tail lamps
*
[MC34700(ALL)01/96]
n
brakelamps
*
[MC34800(ALL)01/96]
n
high-mount brakelamp
*
[MC34900(ALL)01/96]
n
hazard flasher
File:11cdmco.ex
Update:Thu Sep 12 11:08:18 1996

Index
271
A
ABS warning light (see Anti-lock brake system)...... 21
Accessory position on the ignition............. 56
Additives, engine oil.................. 184
Air bag supplemental restraint system........... 96
and child safety seats................ 102
description.................... 96,98
driver air bag................... 96,98
indicator light..................... 16
operation....................... 98
passenger air bag................... 98
service and information labels............. 98
tone generator................... 100
Air cleaner filter
location...................... 181
specifications.................... 229
Alarm, activating remote personal............. 81
Antenna, radio (see Electronic sound system)........ 44
Antifreeze (see Engine coolant)............. 191
Anti-lock brake system (ABS)
description..................... 126
see also Brakes................... 125
warning light..................... 21
Anti-theft lug nuts and key............... 168
Appeals (see Dispute settlement board)......... 240
Assistance (see Customer assistance)........... 237
Audio system (see Electronic sound system)........ 23
Automatic transaxle
driving with.................... 130
fluid, adding.................... 197
fluid, checking................... 195
fluid, refill capacities................ 230
fluid, specification.................. 231
File:cdixo.ex
Update:Thu Sep 12 11:12:35 1996
