To connect the extender to the seat
belt, insert the tab into the seat belt
buckle so that the PRESSº signs onthe buckle-release buttons of the ex-
tender and the seat belt are both facing
outward as shown.
You will hear a click when the tab locks into the buckle.
When releasing the seat belt, press on the
buckle-release button on the extender, not on the seat belt. This helps prevent
damage to the vehicle interior and extend-er itself.
When not in use, remove the extender
and store in the vehicle for future use.
After inserting the tab, make sure
the tab and buckle are locked and
that the seat belt extender is not twisted.
Do not insert coins, clips, etc. in
the buckle as this may prevent you
from properly latching the tab and buckle.
If the seat belt does not function
normally, i mmediately contact your
Toyota dealer.
CAUTION!
The SRS (Supplemental Restraint Sys-
tem) airbags are designed to provide
further protection to the driver and
front passenger when added to the pri-
mary protection provided by the seatbelts.
In response to a severe frontal impact, the
SRS airbags work together with the seatbelts to prevent or reduce injury by inflat- ing, in order to decrease the likelihood of
the driver's or front passenger's head or
chest directly hitting the steering wheel or dashboard. The passenger airbag is acti- vated even with no passenger in the frontseat. SRS airbags

30
The SRS airbags are not designed to inflate if the vehicle is subjected to a
side or rear impact, if it rolls over, or if
it is involved in a low-speed frontalcollision.The center airbag sensor assembly con-
sists of a safing sensor and center airbag
sensor.
In a severe frontal impact, sensors detect
deceleration and the system triggers the
airbag inflators. Then a chemical reaction
in the inflators momentarily fills the air-
bags with non-toxic nitrogen gas to help
restrain the forward motion of the occu- pants.When the airbags inflate, they produce a fairly
loud noise and release some smoke
along with the nitrogen gas. This is not harmful and does not indicate a fire. Be
sure to wash off any residue as soon as
possible to prevent minor skin irritation.
Deployment of the airbags happen in a
fraction of a second, so the airbags must
inflate with considerable force. While the
system is designed to reduce serious inju-
ries, it may also cause minor burns or
abrasions and swellings.
Parts of the airbag module (steering
wheel hub, dashboard) may be hot for several minutes, but the airbags them-selves w ill not be hot. The airbags are de-
signed to inflate only once.
A crash severe enough to inflate the air-
bags may break the windshield as the ve-
hicle buckles. In vehicles with a passen-ger airbag the windshield may also be
damaged by absorbing some of the force
of the inflating airbag.

32
Do not sit on the edge of the seat or
lean over the dashboard when the
vehicle is in use. The airbags in-
flate with considerable speed and
force; you may be severely injured.
Sit up straight and well back in the seat, and always use your seat belt.Do not allow a child to stand up, or
to kneel on the front passenger seat. The airbag inflates with con-
siderable speed and force; the
child may be severely injured.
Do not hold a child on your lap orin your arms. Use a child restraint
system in the rear seat. For instruc-
tions concerning the installation of
a child restraint system, see Child
restraintº in this chapter. Do not put objects on or in front of
the dashboard or steering wheel
pad that houses the airbag sys-
tem. They might restrict inflation
or cause personal injury as they
are projected rearward.
Do not modify, remove or open any
component or wiring, such as the
steering w heel column cover, front
passenger airbag cover, front pas-
senger airbag, center airbag sen-
sor assembly or front airbag sen-
sors. Doing any of these may cause sudden SRS airbag inflation or disable the system, which could
result in personal injury.
Failure to follow these instructions
can result in severe injuries.

Part 1Car audio system operating tips
65
OPERATION OF INSTRUMENTS AND CONTROLSÐ
Chapter 1-7 Car audio system and Air conditioning system
Car audio system operating tips
AM-FM radio with electronic tuner and cassette tape player
AM-FM radio with electronic
tuner, cassette tape player and Compact Disc player
Automatic air conditioning controls
Dashboard vents
Lower vent
You can listen to the car audio system
when the ignition key is at ONº or
ACCº. However, if the engine is not
running,
the key must be in the ACCº
position.
ILLUMINATION CONTROL LOGIC When the instrument panel lights are on,
the letters on operable buttons of the
mode in current use light up. On some au-
dio-units, the mode selection and eject
buttons also light up.
On some audio-units, when a cassette tape is not in the slot, the letters on the tape mode buttons do not light up, but the
slot lights up for easy access. Once a cas-
sette tape is inserted, the letters on the
tape mode buttons light up, and the slot
stops illuminating. RADIO FM reception tips
Most of us are not aware that a vehicle is
not an ideal place to listen to a radio. Be- cause it moves, reception conditions
change continuously. Buildings, terrain,
signal distance and noise from other ve-
hicles are all working against good recep-
tion. Some FM reception conditions may appear to be problems even though they are normal.
The following characteristics are normal
for a given reception area, and they do not
indicate any problem with the radio itself.
Fading and Drifting: On the average,
the broadcast range of FM stations is limited to about 40 km (25 miles), ex-cept for some high power stations.
If a vehicle is moving away from the
desired station's transmitter, the signal
will tend to fade and/or drift. This phe-
nomenon is more noticeable with FM
than with AM, and is accompanied by distortion.
Fading and drifting can be minimized
to a certain degree by fine tuning, or
you should tune in to a stronger signal.
Static and Fluttering: When the line-
of-sight path between a transmitter
and vehicle is blocked by large build-
ings or the like, static or fluttering may
occur because of the characteristic of
FM. In a similar effect, a fluttering
noise is sometimes heard when driv-
ing along a tree-lined road.
This static and fluttering can be re-
duced by adjusting the tone control for
greater bass response until the distur-
bance has passed.

66
Multipath: Because of the reflection
characteristics of FM, direct and re-
flected signals may reach the antenna
at the same time (a phenomenon
called multipath reception) and cancel
each other out. As a vehicle moves
through these electronic dead spots,
the listener may hear a momentary
flutter or lose reception.
Station swapping: When two FM
stations are close to each other, and
an electronic dead spot, such as is
caused by static or multipath recep-
tion, interrupts the original signal,
sometimes the stronger second si gnal
is picked up automatically until theoriginal one returns. This swapping
can also occur as you drive away from the selected station and approach
another station with a stronger signal.
On models with a power antenna, the an-
tenna automatically extends to its full
height when the radio and ignition are turned on.
To lower the power antenna, turn off the
audio system by pushing PWR VVOLº, or
turn the ignition key to LOCKº.
On some models, the power antenna au-
tomatically retracts when the radio mode
is switched off to turn on the cassette tape
player or compact disc player. Before extending the power antenna,
confirm
that no one is close enough to get
injured by it.
To prevent damage to the antenna,
make sure it is retracted before
running your vehicle through anautomatic car wash.
NOTICE
CASSETTE TAPE PLAYER
Use only undamaged cassette tapes of
good quality. Avoid using tapes with a
total playing time longer than 90 min-utes.
Using damaged tapes will cause trouble with the tape player. Longer tapes are not
recommended because of their thinness.
Before inserting a cassette, make sure
the tape is not slack and that the label
is firmly stuck on the shell.
Wind the tape firmly by turning the hub with a pencil or the like.
Be careful not to touch the exposed tape surface.
When not in use, take the cassette out
of the player, put it back into its case and store it away from dust, magnets
and direct sunlight.
Leaving cassettes on the dashboard in the sun could damage your tapes. Keep the playback head, capstan and pinch roller clean. Remove tape coating residue accumu- lated on the head, capstan and pinch
roll-
er once or twice a month. A cleaning tape is available on the market.
Do not oil any part of the player and
do not insert anything other than
cassette tapes into the slot, or thetape player may be damaged.
NOTICE

67
COMPACT DISC PLAYER
Use only Compact Discs labeled as
shown, having no dirt, damage orwarp.
Never attempt to disassemble or oil
any part of the player unit. Do not in- sert any object other than a Disc into
the slot. Remember there are no user-serviceable
parts inside.
Do not put fingerprints, stickers,
scratches or pen marks on the sur-
faces of the Disc. Hold the Disc only on the edge or center hole.A new Disc may have rough edges on
its inner and outer perimeter. Remove
the rough edges by pressing the side
of a ball-point pen or pencil against
the inner and outer perimeter of theDisc as shown.
If you continue to play a Disc with rough edges, flakes will fall on to the signal side
of the Disc and cause sound skipping or other problems.When not in use, take the Disc out of
the player, put it back into its case and store it away from dust, heat, damp
and direct sunlight.
Leaving Discs on the dashboard in the sun may damage or warp them.
If the Disc gets dirty, wipe it clean with a soft cloth, wiping radially out from
the center.
Do not use a conventional record cleaner or anti-static record preservative.
Compact disc players use invisible
laser beam which could cause haz-
ardous radiation exposure if di-
rected outside the unit. Be sure to
operate the player correctly asinstructed.
CAUTION
!

100BI-LEVEL buttonÐThis button directs
the air flow to face level and the floor. Ex-
cept in ventilation, the air to the floor is
slightly warmer than that to face level.
FLOOR buttonÐThis button directs the
air flow mostly to the floor.
FLOOR/WINDSHIELD buttonÐThis but- ton directs the air flow to the windshield
and front side windows as well as the floor.
WINDSHIELD buttonÐThis button di-
rects the air flow to the windshield and
front side windows.
Pressing this air flow control button turns
on the air conditioning. This is to clear up
the front view more quickly.
Pressing the air conditioning on-off but-
ton in the off mode turns off the air condi- tioning.
If you push the WINDSHIELD button once
again, it returns to the last air flow button used. Do not use the WINDSHIELD button dur-
ing cooling operation in extremely humid
weather.
The difference between the tem-
perature of the outside air and that of the windshield could cause the outer surface
of the windshield to fog up blocking yourvision. If manual fan speed control is de- siredÐ
The fan speed can be fixed at your desired
speed by turning to the appropriate posi-tion of the fan speed control knob. The
higher
the fan speed is, the more air is de-
livered.
(B) WINDSHIELD DEFOGGING AND DEFROSTING
See (A) CLIMATE CONTROLº for details
on each button or lever function.
To remove interior fog on the wind- shieldÐ
1. Turn the temperature control knob for the desired temperature level.
2. Press in the AUTOº button.
3. Set the air intake control button to the OUTSIDE AIR mode.
4. Press in the WINDSHIELD button of the air flow control buttons.
To remove frost or exterior fog on the windshieldÐ
1. Turn the temperature control knob at the maximum temperature.
2. Set the air intake control button to the OUTSIDE AIR mode.
3. Press in the WINDSHIELD button of the air flow control buttons.
4. Turn the fan speed control knob at the
HIº position. 5. Press the air conditioning on-off but- ton in the OFF mode.
(C) OPERATING TIPS
Be sure the air inlet grilles in front of the
windshield are not blocked by leaves or other obstructions.
If air flow control is not satisfactory,
check the dashboard vents. (See
Dashboard ventsº or Lower ventº.)
To help cool down the interior after
parking in the hot sun, drive for the first
few minutes with the windows open.
After the excess heat has blown away,
close the windows.
When driving on dusty roads, close all
windows. If dust thrown up by the ve-
hicle is still drawn into the vehicle after
closing the windows, it is recom-
mended that the air intake control but-ton be set in the OUTSIDE AIR mode.
If following another vehicle on a dusty
road, or driving in windy and dusty con-
ditions, it is recommended that the air
intake control button be temporarily
set to select the RECIRCULATED AIR
mode, which will close off the outside
passage and prevent outside air and
dust from entering the vehicle interior.

101
The dashboard vents may be opened
or closed as shown.The lower vent may be opened or
closed as shown.
Dashboard vents
Lower vent
