1996 NISSAN PATHFINDER oil filter

The following values are approximate capacities. The actual refill capacities may be a little different from them. When refilling, follow the
procedure instructed in the ªDo-it-yourself operationsº section to determine the proper refill capacity.
Capacity (Approximate)
Recommended specifications
US
measureImp
measureLiter
Fuel 21-1/8 gal 17-5/8 gal 80Unleaded gasoline with an octane rating
of at least 87 AKI (RON 91)*1
Engine oil (Refill)
with oil filter 3-7/8 qt 3-1/4 qt 3.7IAPI SG or SH and Energy Conserving
II
*2 *3
IAPI Certification Mark*2 *3without oil filter 3-5/8 qt 3 qt 3.4
Cooling system
(with heater and
reservoir tank)11-1/4 qt 9-3/8 qt 10.6Anti-freeze coolant
(Ethylene glycol base)
*1: For further details, see the ªFuel recommendationº section.
*2: For further details, see recommended SAE viscosity number chart.
*3: For further details, see ªEngine oil and oil filter recommendationº.
CAPACITIES AND
RECOMMENDED
FUEL/LUBRICANTS
9-2
Z01.2.1/R50-DX

ENGINE OIL AND OIL FILTER
RECOMMENDATION
Selecting the correct oil
It is essential to chose the correct quality, and
viscosity oil to ensure satisfactory engine life
and performance. Nissan recommends the
use of a low friction oil (energy conserving oil)
in order to improve fuel economy and con-
serve energy. Oils which do not have the
specified quality label should not be used as
they could cause engine damage.
Only those engine oils with the American Pe-
troleum Institute (API) CERTIFICATIONMARK on the front of the container should be
used. This type of oil supersedes the existing
API SG or SH and Energy Conserving II
categories.
If you cannot find engine oil with the CERTI-
FICATION MARK, an API SG or SH and
Energy Conserving II oil with API Service
Symbol may be used. An oil with a single
designation ªSGº or ªSHº, or in combination
with other categories (for example, ªSG/CCº or
ªSG/CDº) may also be used if one with the API
CERTIFICATION MARK cannot be found.
Mineral based or synthetic type oils may be
used in your NISSAN vehicle. These oils musthowever, meet the API quality and SAE vis-
cosity ratings specified for your vehicle. Do not
mix mineral based and synthetic type oils in
the engine at the same time.
Oil additives
NISSAN does not recommend the use of oil
additives. The use of an oil additive is not
necessary when the proper oil type is used
and maintenance intervals are followed.
Oil which may contain foreign matter or has
been previously used should not be used.
Oil viscosity
The engine oil viscosity or thickness changes
with temperature. Because of this, it is impor-
tant that the engine oil viscosity be selected
based on the temperatures at which the ve-
hicle will be operated before the next oil
change. The chart ªRecommended SAE vis-
cosity numberº shows the recommended oil
viscosities for the expected ambient tempera-
tures. Choosing an oil viscosity other than that
recommended could cause serious engine
damage.STI0077
9-6
Z01.2.1/R50-DX

Selecting the correct oil filter
Your new vehicle is equipped with a high-
quality genuine Nissan oil filter. When replac-
ing, use the genuine oil filter or its equivalent
for the reason described in ªchange intervalsº.
Change intervals
The oil and oil filter change intervals for your
engine are based on the use of the specified
quality oils and filters. Oil and filter other than
the specified quality, or oil and filter change
intervals longer than recommended could re-
duce engine life. Damage to engines caused
by improper maintenance or use of incorrect
oil and filter quality and/or viscosity is not
covered by the new Nissan vehicle warranties.
Your engine was filled with a high quality
engine oil when it was built. You do not have to
change the oil before the first recommended
change interval. Oil and filter change intervals
depend upon how you use your vehicle. Op-
eration under the following conditions may
require more frequent oil and filter changes.
Ð repeated short distance driving at cold out-
side temperatures,
Ð driving in dusty conditions,
Ð extensive idling,Ð towing a trailer.
9-7
Z01.2.1/R50-DX

10 Index
A
Adjustable shock absorber control (If so
equipped) ........................................................ 1-31
Air bag (See ªSupplemental restraint systemº)
Air bag warning light (See ªSupplemental air bag
warning lightº or ªWarningº)
Air cleaner filter ............................................... 7-16
Air conditioner
Air conditioner operation ...................... 3-5, 3-9
Air conditioner specification label.............. 9-15
Heater and air conditioner........................... 3-3
Semiautomatic air conditioner ..................... 3-7
Air conditioning system refrigerant and lubricant
recommendations ............................................. 9-9
Air flow charts ................................................. 3-11
AM-FM radio with cassette player .................. 3-15
AM-FM radio with compact disc player .......... 3-20
Anti-lock brake system ................................... 4-24
Automatic
Automatic transmission fluid ....................... 7-9
Driving with automatic transmission............ 4-6
Semiautomatic air conditioner ..................... 3-7
Avoiding collision and rollover .......................... 4-4
B
Back door locks ................................................ 2-8
Battery............................................................. 7-13Battery replacement.......................................... 2-6
Before starting the engine ................................ 4-6
Belt hook ......................................................... 2-28
Brake
Anti-lock brake system .............................. 4-24
Brake and clutch fluid................................ 7-11
Brake booster ............................................ 7-20
Brake pedal ............................................... 7-19
Brake wear indicators ...................... 1-12, 7-19
Parking brake ................................... 4-12, 7-18
Break-in schedule ........................................... 4-15
C
Capacities and recommended fuel/lubricants... 9-2
CB radio or car phone .................................... 3-24
Center and side vent ........................................ 3-2
Changing
Changing engine coolant ............................ 7-5
Changing engine oil .................................... 7-8
Changing oil filter ........................................ 7-9
Checking coolant level ...................................... 7-4
Checking engine oil level .................................. 7-7
Child restraints for infants and small children .... 2-
30
Child safety ..................................................... 2-24
Child safety rear door lock................................ 2-3
Cigarette lighter and ash trays ....................... 1-21
Cleaning exterior and interior ........................... 6-2
Clearing the programming information ........... 1-33Clock ................................................................. 1-8
Clutch housing................................... 7-30
Clutch pedal .................................................... 7-20
Coin tray ......................................................... 1-22
Cold weather driving cautions ........................ 4-25
Compact disc player operation ....................... 3-22
Compass and outside temperature
display ............................................................... 1-5
Console box .................................................... 1-24
Coolant
Changing engine coolant ............................ 7-5
Checking coolant level ................................ 7-4
Engine coolant temperature gauge ............. 1-4
Corrosion protection ....................................... 4-27
Cruise control.................................................. 4-13
Cup holder ...................................................... 1-23
D
Defogger switch
Rear window defogger switch ................... 1-18
Dimensions and weights ................................. 9-12
Door locks ......................................................... 2-2
Drinking alcohol/drugs and driving ................... 4-4
Drive belts ....................................................... 7-14
Driving
Cold weather driving cautions ................... 4-25
Drinking alcohol/drugs and driving .............. 4-4
Driving safety precautions ......................... 4-20
Driving with automatic transmission............ 4-6
Z01.2.1/R50-DX

Driving with manual transmission ............. 4-10
On-pavement and off-road driving
precautions .................................................. 4-3
Precautions when driving .......................... 4-23
Precautions when starting and driving ........ 4-2
E
Economy hints ................................................ 4-15
Emission control information label .................. 9-14
Emission control system warranty .................. 9-20
Engine ............................................................. 9-10
Before starting the engine ........................... 4-6
Changing engine coolant ............................ 7-5
Changing engine oil .................................... 7-8
Checking engine oil level ............................ 7-7
Engine coolant temperature gauge ............. 1-4
Engine cooling system ................................ 7-4
Engine oil..................................................... 7-7
Engine oil and oil filter
recommendation .......................................... 9-6
Engine serial number ................................ 9-13
Starting the engine .................................... 4-11
Exhaust gas (Carbon monoxide) ...................... 4-2
Explanation of maintenance items.................. 8-10
F
Flat tire .............................................................. 5-2
Fluid
Automatic transmission fluid ....................... 7-9
Brake and clutch fluid................................ 7-11
Power steering fluid................................... 7-11
Window washer fluid ................................. 7-12F.M.V.S.S. certification label........................... 9-14
Front fog light switch ...................................... 1-19
Front seats ...................................................... 2-12
Fuel
Capacities and recommended
fuel/lubricants .............................................. 9-2
Fuel filler cap ............................................. 2-11
Fuel filler lid lock ....................................... 2-10
Fuel gauge .................................................. 1-5
Fuel recommendation.................................. 9-4
Fuses .............................................................. 7-20
G
Gauge
Engine coolant temperature gauge ............. 1-4
Fuel gauge .................................................. 1-5
Meters and gauges ..................................... 1-3
General maintenance ....................................... 8-2
Glasses case .................................................. 1-23
Glove box lock ................................................ 2-10
H
Hazard warning flasher switch........................ 1-19
Head restraint ................................................. 2-15
Headlight and turn signal switch..................... 1-15
Headlights ....................................................... 7-22
Heated seat (If so equipped) .......................... 1-20
Heater and air conditioner ................................ 3-3
Heater operation ........................................ 3-4, 3-8
Hood release .................................................... 2-9I
If your vehicle is ever stolen ........................... 1-33
If your vehicle overheats .................................. 5-9
Ignition switch ................................................... 4-4
Inside mirror .................................................... 2-38
Inspection light ................................................ 1-30
Instrument brightness control ......................... 1-18
Integrated HomeLink
TMtransmitter
(If so equipped)............................................... 1-31
Interior light ..................................................... 1-29
J
Jump starting ........................................... 5-7, 7-13
K
Key .................................................................... 2-2
L
Light
Air bag warning light ................................. 2-22
Cigarette lighter and ash trays .................. 1-21
Front fog light switch ................................. 1-19
Headlight and turn signal switch ............... 1-15
Headlights.................................................. 7-22
Inspection light .......................................... 1-30
Interior light................................................ 1-29
Light bulbs ................................................. 7-22
Other lights ................................................ 7-23
Spot light ................................................... 1-30
Vanity mirror light ...................................... 1-30
10-2
Z01.2.1/R50-DX

Warning/indicator light and buzzer.............. 1-9
Lock
Anti-lock brake system .............................. 4-24
Back door locks ........................................... 2-8
Child safety rear door lock .......................... 2-3
Clock............................................................ 1-8
Door locks ................................................... 2-2
Fuel filler lid lock ....................................... 2-10
Glove box lock........................................... 2-10
Power door lock .......................................... 2-3
Rear window locks ...................................... 2-8
Luggage board and box ................................. 1-25
Luggage hooks ............................................... 2-40
Luggage net .................................................... 2-39
Luggage rack .................................................. 2-41
Luggage side finisher hook ............................ 2-39
M
Maintenance
Explanation of maintenance items ............ 8-10
General maintenance .................................. 8-2
Periodic maintenance .................................. 8-5
Seat belt maintenance .............................. 2-30
Manual antenna .............................................. 3-24
Meters and gauges ........................................... 1-3
Mirror
Inside mirror .............................................. 2-38
Outside mirror control................................ 2-37
Outside mirror defogger (If so
equipped)................................................... 1-18
Outside mirrors .......................................... 2-38
Vanity mirror light ...................................... 1-30Multi-remote control system (If so equipped) ... 2-4
O
Oil
Changing engine oil .................................... 7-8
Changing oil filter ........................................ 7-9
Checking engine oil level ............................ 7-7
Engine oil..................................................... 7-7
Engine oil and oil filter
recommendation .......................................... 9-6
On-pavement and off-road driving precautions .. 4-
3
Operating the transmitter ................................ 1-33
Outside mirror control ..................................... 2-37
Outside mirror defogger (If so equipped) ....... 1-18
Outside mirrors ............................................... 2-38
Overheat
If your vehicle overheats ............................. 5-9
P
Parking ............................................................ 4-22
Parking brake ................................... 4-12, 7-18
Periodic maintenance ....................................... 8-5
Power
Power antenna (If so equipped)................ 3-24
Power door lock .......................................... 2-3
Power socket ............................................. 1-22
Power steering fluid................................... 7-11
Power support seat ................................... 2-13
Power window ........................................... 1-26
Precautions ....................................................... 7-2
Driving safety precautions ......................... 4-20On-pavement and off-road driving
precautions .................................................. 4-3
Precautions on seat belt usage ................ 2-24
Precautions when driving .......................... 4-23
Precautions when starting and driving ........ 4-2
Programming problem diagnosis .................... 1-33
Programming the HomeLink
TM
transmitter ....................................................... 1-32
Protecting against corrosion ............................. 6-5
Push starting ..................................................... 5-8
R
Radio............................................................... 3-14
AM-FM radio with cassette player ............ 3-15
AM-FM radio with compact disc
player ......................................................... 3-20
CB radio or car phone............................... 3-24
Rear seats ...................................................... 2-15
Rear window defogger switch......................... 1-18
Rear window locks ............................................ 2-8
Rear window wiper and washer switch .......... 1-17
Recommended sae viscosity number............... 9-8
Refrigerant recommendation ............................ 9-9
Reporting safety defects (U.S.A.) ................... 9-21
S
Safety
Child safety................................................ 2-24
Child safety rear door lock .......................... 2-3
Driving safety precautions ......................... 4-20
Reporting safety defects (U.S.A.) ............. 9-21
Seat adjustment .............................................. 2-12
10-3
Z01.2.1/R50-DX

Recommended fuel:
Unleaded gasoline, at least 87 AKI number
(RON 91)
For further details such as gasohol or diesel
fuel grade, see ªFuel recommendationº in the
ªTechnical informationº section.
Recommended engine oil:
IAPI SG or SH and Energy Conserving II
IAPI Certification Mark
ISAE 5W-30 viscosity oil is preferred for all
ambient temperatures.
See ªEngine oil and oil filter recommendationº
in the ªTechnical and consumer informationº
section.
Tire cold pressure:
See the tire placard affixed to the glove box.
Recommended new vehicle break-
in procedure:
During the first 1,000 miles (1,600 km) of
vehicle use, follow the recommendations out-
lined in the ªBREAK-IN SCHEDULEº Informa-
tion found in the ªStarting and drivingº section
of this Owner's Manual. Follow these recom-
mendations for the future reliability and
economy of your new vehicle. Failure to follow
these recommendations may result in vehicledamage or shortened engine life. (page)
IIn case of emergency .......................... 5-1
(Flat tire, engine will not start, overheating,
towing)
IHow to start the engine ....................... 4-1
IHow to read the meters and
gauges ................................................. 1-1
IMaintenance schedule......................... 8-1
IDo-it-yourself operations ..................... 7-1
ITechnical information .......................... 9-1
GAS STATION INFORMATION QUICK REFERENCE
Z01.2.1/R50-DX
