Starting Your Villager
63
*
[ST09000(ALL)01/93]
For best results, plug the heater in at least three hours before
you start your vehicle. Using the heater for longer than three
hours will not damage the engine, so you can leave it plugged
in all night to start your vehicle the following morning.
%*
[ST09005(ALL)02/95]
What To Do If The Engine Does Not Start
%*
[ST09010(ALL)02/95]
Fuel Pump Shut-Off Switch
*
[ST09015(ALL)03/95]
If the engine cranks but does not start or does not start after a
collision, the fuel pump shut-off switch may have been
triggered. The shut-off switch is a device intended to stop the
fuel pump when your vehicle has been involved in a substantial
jolt.
*
[ST09020(ALL)03/95]
Once the shut-off switch is triggered, you must reset the switch
by hand before you can start your vehicle.
[ST09025(ALL)02/95]
The fuel pump shut-off switch reset button is located below the
hood release handle.
[ST09030(ALL)02/95]
10-1/2 pica
art:0040048-C
Fuel pump shut-off switch reset button location
File:04vxstn.ex
Update:Mon Jun 3 08:20:06 1996

Electronic Sound Systems
215
[AS11000(ALL)06/95]2.
Rewinding the tape
[AS11100(ALL)06/95]
To rewind the tape, press the ªREWº button. The ª
Xº
display blinks while the tape rewinds. The radio will
automatically begin playing until rewind is manually
stopped (by pushing the ªREWº button) or the beginning of
the tape is reached.
[AS11200(ALL)05/94]3.
Using the ªSEEKº function with a cassette tape
[AS11300(ALL)06/95]
While in the tape mode, push the right (
a) side of the
ªSEEKº button to seek forward to the next selection on the
tape. Push the left (
b) side of the ªSEEKº button to seek
the previous tape selection. The ªTAPEº display blinks.
*
[AS11400(ALL)11/93]
NOTE: If you want to restart a currently playing tape
selection, press the left (
b) side of the ªSEEKº button
after three seconds into the current selection.
[AS11500(ALL)06/95]4.
Using the ªSCANº button to scan cassette selections
[AS11600(ALL)06/95]
Press the ªSCANº button to enter the scan mode (display
blinks ªSCº) to begin the forward scan mode on the tape
currently playing, stopping on each tape selection for a
five-second sampling.
[AS11650(ALL)06/95]
The scan mode continues to the other side of the tape after
one side of the tape has been played completely.
[AS11800(ALL)06/95]
To stop the scan mode on the presently sampled tape
selection, press the ªSCANº button again, or press ªTAPE,º
ªCDº (if equipped), ªTUNE,º or ªSEEK.º
[AS11900(ALL)03/93]
Reversing the direction
[AS12000(ALL)06/95]
The alternate track of the tape can be selected anytime by
pressing the ªSIDE 1-2º button.
File:10vxasn.ex
Update:Mon Jun 3 14:57:29 1996

Driving Your Villager
253
*
[DR21300(ALL)01/93]
Allow more room for stopping with a trailer attached. Trailer
brakes should be applied first, whether manually or
automatically controlled, when approaching a stop.
*
[DR21400(ALL)01/93]
For an easy-to-operate vehicle/trailer combination, the trailer
tongue load should be approximately 10-15% of the loaded
trailer weight.
*
[DR21500(ALL)02/94]
Make a thorough check of your equipment before starting out
on the road. After you have traveled about 50 miles (80 km),
stop in a protected area and double-check your hitch and
electrical connections. Also check trailer wheel lug nuts for
tightness.
[DR21600(ALL)01/93]
When stopped in traffic for long periods of time in hot weather,
place the gearshift selector lever in Park (P) to increase the
engine idle speed. This aids in engine cooling and air
conditioner efficiency. If the engine overheats, press the air
intake button to select the fresh air position to stop the air
conditioner compressor. Increase the engine speed for a short
time.
*
[DR21700(ALL)01/93]
Vehicles with trailers should not be parked on a grade.
However, if you must park on a grade, place wheel chocks
under the trailer's wheels as follows:
[DR21800(ALL)04/94]1.
Apply the main brake pedal with your foot and hold it.
*
[DR21900(ALL)11/93]2.
Have another person place the wheel chocks under the
trailer wheels.
[DR22000(ALL)04/94]3.
With the chocks in place, release the brake pedal, making
sure the chocks are holding.
[DR22100(ALL)04/94]4.
Apply the parking brake by pressing the main brake pedal
down firmly with your right foot while depressing the
parking brake pedal with your left foot.
*
[DR22200(ALL)06/95]5.
Shift the gearshift lever into P (Park).
File:11vxdrn.ex
Update:Tue Jun 4 11:42:50 1996
