205 [DR17650(ALL)11/94]
ABS has self-check capabilities. As described
above, the system turns on the ABS light each
time you start your engine. After the engine is
started and the ABS light turns off, the system
performs another test the first time the vehicle
reaches 4-9 mph (6-15 km/h). The system turns
on the ABS pump motor for approximately 1/2
second. At this time, a mechanical noise may be
heard. This is a normal part of the self-check
feature. If a malfunction is found during this
check the ABS light will come on.
[DR17675(ALL)02/95]
Vehicles with ABS are identified with a label on
the front door pillar.
*
[DR17700(ALL)12/93]
Ford Motor Company has not found any
negative effects of mobile radio transmitting
equipment installed on vehicles with the ABS
system providing that the radio is installed
according to the radio manufacturer's
instructions. However, if you have had a mobile
radio transmitter installed and the check ABS
light comes on (at any time other than
immediately after turning the key to the ON
position) have your mobile radio dealer inspect
the radio installation. Also, if the ABS system is
activated other than during maximum braking,
have your mobile radio installation checked.
%*
[DR17800(ALL)03/95]
Parking Brake
*
[DR17900(ALL)01/95]
The parking brake should be used whenever
you park your vehicle.
[DR18000(ALL)01/95]
This brake is suspended just below the bottom
of the instrument panel to the left of the brake
pedal.
File:fcdrs.ex
Update:Wed Dec 20 09:31:15 1995

207
*
[DR19000(ALL)01/95]
The parking brake is not designed to stop a
moving vehicle, but you can use the parking
brake to stop your vehicle in an emergency if
the normal brakes fail. However, since the
parking brake applies only the rear brakes, the
stopping distance will increase greatly and the
handling of your vehicle will be adversely
affected.
*
[DR19050(ALL)03/95]
Always check the Brake Warning Light each
time you start your engine. Driving with the
parking brake on will cause the brakes to wear
out quickly and will reduce the fuel economy.
*
[DR19100(ALL)01/95]
Driving Under Special Conditions
%*
[DR19200(ALL)01/95]
Tips for Safe Driving
*
[DR19300(ALL)03/95]
As with any new vehicle, yours may drive and
handle differently from your previous vehicle.
Use care until you become accustomed to its
various features and driving characteristics.
*
[DR19400(ALL)03/95]
Operate your vehicle within reasonable limits.
Sudden acceleration, deceleration, turning, or
combinations of these maneuvers can cause a
vehicle to behave differently than anticipated.
*
[DR19750(ALL)01/95]
Driving in Bad Weather
%*
[DR19800(ALL)01/95]
Slippery roads
*
[DR19900(ALL)03/95]
On some slippery road surfaces, front-wheel
drive may provide better acceleration than
rear-wheel drive. However, this does not mean
that your vehicle can stop any faster or any
better than a vehicle with rear-wheel drive.
Exercise the same caution while driving on
slippery roads with your front-wheel drive
vehicle as you would with a rear-wheel drive
vehicle.
*
[DR20100(ALL)03/95]
q
Do not quickly move the steering wheel
unless necessary.
File:fcdrs.ex
Update:Wed Dec 20 09:31:15 1995

219
*
[RE01200(ALL)03/95]
2. Do not disconnect the battery of the disabled
vehicle. You could damage the vehicle's
electrical system.
*
[RE01300(ALL)04/95]
3. Park the booster vehicle close to the hood of
the disabled vehicle.Make sure the vehicles
do not touch each other.Set the parking
brake on both vehicles and stay clear of the
engine cooling fan and other moving parts.
*
[RE01400(ALL)03/95]
4. Check all battery terminals and remove any
excessive corrosion before you attach the
jumper cables.
[RE01500(ALL)04/95]
5. Turn on the heater fan in both vehicles. If
you have electronic climate control, press the
VF-DEF button. Turn off all other switches
and lights.
%*
[RE01700(ALL)08/95]
Connecting the jumper cables
*
[RE02500(ALL)03/95]
1. Connect one end of the first jumper cable to
the positive (+) terminal of the discharged
battery. (You can connect either jumper cable
to the positive (+) terminal, as long as you
use the same cable for both positive
terminals.) Most jumper cables have a red
cable and a black cable. The red cable is
generally used for the positive terminals and
the black for the negative ones.
*
[RE02600(ALL)04/95]
2. Connect the other end of the first cable to
the positive (+) terminal of the booster
battery.
*
[RE02700(ALL)03/95]
3. Connect one end of the second cable to the
negative (s) terminal of the booster battery
Ð NOT to the discharged battery.
*
[RE02800(ALL)04/95]
4. Connect the other end of the second cable to
a good metallic surface on the engine or
frame of the disabled vehicle.
File:fcres.ex
Update:Tue Aug 8 11:02:29 1995

255
Servicing Your Sable
%*
[SV00300(ALL)03/95]
Service Made Easy
*
[SV00400(ALL)01/95]
Ford has two goals for servicing your vehicle.
*
[SV00500(ALL)01/95]
1. When we can, we design parts that do not
need to be serviced.
*
[SV00600(ALL)01/95]
2. We want to make servicing your vehicle as
easy as possible. To help you:
*
[SV00700(ALL)01/95]
q
We highlight do-it-yourself items in yellow in
the engine compartment so that you can find
them easily.
*
[SV00800(ALL)01/95]
q
When possible, we design parts Ð such as
the headlamp bulbs Ð that can be replaced
without tools.
*
[SV00900(ALL)05/94]
q
We give you a Maintenance Schedule that
makes tracking routine service for your
vehicle easy. The maintenance schedule is
located in theMaintenance Schedule and Record
booklet.
*
[SV01000(ALL)01/95]
This chapter tells you about the basic parts that
you need to check and service regularly.
*
[SV01100(ALL)03/95]
If your vehicle needs professional servicing, see
theCustomer Assistancechapter.
*
[SV01200(ALL)03/95]
Check yourWarranty Information Bookletto find
out which parts are covered.
*
[SV01250(ALL)03/95]
Ford Motor Company recommends that you
perform the Owner Maintenance Checks listed in
theMaintenance Schedule and Recordbooklet.
These services are important for the proper
operation of your vehicle. In addition to the
conditions listed in the Owner Maintenance
File:fcsvs.ex
Update:Wed Dec 20 09:36:55 1995

272
*
[SV13564(ALL)02/95]
The following decrease fuel economy:
*
[SV13568(ALL)02/95]
q
Lack of regular, scheduled maintenance
*
[SV13572(ALL)02/95]
q
Excessive speed
*
[SV13576(ALL)02/95]
q
Rapid acceleration
*
[SV13581(ALL)02/95]
q
Driving with your foot on the brake
*
[SV13584(ALL)02/95]
q
Sudden stops
*
[SV13589(ALL)02/95]
q
Extended engine idling
*
[SV13591(ALL)02/95]
q
Using speed control in hilly terrain
*
[SV13593(ALL)02/95]
q
Extended use of the A/C, defroster, rear
window defroster and other accessories
*
[SV13596(ALL)02/95]
q
Underinflated tires
*
[SV13598(ALL)02/95]
q
Heavy loads
*
[SV13599(ALL)02/95]
q
Aftermarket add-ons such as bike, ski or
luggage racks, bug deflectors, etc.
*
[SV13605(ALL)02/95]
Self-Service Pointers
*
[SV13611(ALL)01/95]
If you choose to do your own fueling, you
should also perform a few simple maintenance
routines. This extra effort will save you
additional money and contribute to the driving
efficiency of your vehicle.
*
[SV13615(ALL)01/95]
The following procedures require only a tire
gauge, a rag, an oil can spout and windshield
washer fluid.
*
[SV13620(ALL)01/95]
q
Check the engine oil at every refueling stop
*
[SV13625(ALL)01/95]
q
Clean the windshield, outside mirrors and
headlights
*
[SV13630(ALL)01/95]
q
Check windshield washer fluid
*
[SV13633(ALL)02/95]
q
Check tires for excessive wear or worn edges
*
[SV13636(ALL)01/95]
q
Check the tire pressure at least monthly
File:fcsvs.ex
Update:Wed Dec 20 09:36:55 1995

274 %
*
[SV13775(ALL)01/95]
Checking and Adding Engine Oil
*
[SV13800(ALL)03/95]
Since the proper amount of engine oil is
important for safe engine operation, check the oil
using the dipstick each time you put fuel in
your vehicle. Remember the engine must be off,
the oil must be warm and the vehicle must be
parked on level ground.
%*
[SV13900(ALL)04/95]
Checking the engine oil level:
*
[SV14000(ALL)02/95]
1. Turn the engine off after it has warmed up
and allow a few minutes for the engine oil
to drain back into the oil pan.
*
[SV14025(ALL)03/95]
2. Set the parking brake, making sure the
gearshift is securely latched in P (Park).
*
[SV14100(ALL)02/95]
3. Open the hood. Protect yourself from engine
heat.
*
[SV14200(ALL)03/95]
4. Locate the engine oil dipstick (highlighted in
yellow) and carefully pull it out of the
engine.
*
[SV14300(ALL)01/95]
5. Wipe the dipstick clean and put it back into
position, making sure it is fully seated.
[SV14400(ALL)02/95]
one inch art:0001397-A
Engine oil dipstick (3.0L Vulcan)
[SV14475(ALL)08/95]
one inch art:0001398-B
Engine oil dipstick (3.0L Duratec)
File:fcsvs.ex
Update:Wed Dec 20 09:36:55 1995

275
*
[SV14500(ALL)03/95]
6. Carefully, pull the dipstick out again. If the
oil level is below the ªADD 1 QTº line, add
engine oil as necessary. If the oil level is
beyond the letter ªFº in Full, engine damage
or high oil consumption may occur and
some oil must be removed from the engine.
*
[SV14600(ALL)01/95]
7. Put the dipstick back in and make sure it is
fully seated.
%*
[SV14700(ALL)03/95]
Adding engine oil
*
[SV14800(ALL)01/95]
It may be necessary to add some oil between oil
changes. Make sure you use a CERTIFIED
engine oil of the preferred viscosity. Your
vehicle's warranty coverage may not apply if
engine damage is caused by the use of improper
engine oil.
*
[SV15000(ALL)03/95]
Add engine oil through the oil filler cap
highlighted in yellow. To add oil, remove the
filler cap and use a funnel to pour oil into the
opening. Be careful not to overfill the engine.
Recheck the oil level after you finish adding oil.
%*
[SV16300(ALL)01/95]
Changing the Engine Oil and the Oil Filter
[SV16400(ALL)04/95]
Change the engine oil and oil filter per the
following, whichever occurs first.
[SV16500(ALL)04/95]
one third page art:0060618-CFile:fcsvs.ex
Update:Wed Dec 20 09:36:55 1995

277
reservoir located in the engine compartment. To
locate the reservoir, see the diagram of your
vehicle's engine underEngine Type, in this
chapter.
*
[SV17650(ALL)08/95]
The coolant additives also protect the entire
cooling system from internal passageway
corrosion and these additives lubricate the water
pump. The coolant should be serviced as noted
in theMaintenance Schedule and Recordbooklet.
[SV17700(ALL)04/95]
one third page art:0000305-E
The engine coolant reservoir (3.0L Vulcan shown Ð 3.0L
Duratec similar)
[SV17750(ALL)04/95]
The coolant level in the reservoir should be
maintained within the cold fill range.
[SV17900(ALL)02/95]
There may be a low coolant warning light in the
instrument cluster which will light when the
coolant level is low.
%*
[SV18000(ALL)11/94]
Checking hoses
*
[SV18050(ALL)11/94]
Inspect all engine and heater system hoses and
hose connections for deterioration, leaks, and
loose hose clamps as specified in theMaintenance
Schedule and Recordbooklet. Repair or replace
with Motorcraft hoses or equivalent as necessary.
File:fcsvs.ex
Update:Wed Dec 20 09:36:55 1995
