1996 HONDA ODYSSEY seats

Seats
Adjust the scat-back before you start driving. The seat-backs should be in
an upright position for you and your
passengers to get the most protec-
tion from the seat belts.
To change the seat-back angle of the front seats, or the second-row seatsin the six passenger model, pull up
on the lever on the outside of the
seat bottom. To adjust the seat-back
angle of the second seat in the seven- passenger model, pull up on the lever
on the side of the seat-back.
Move the seat-back to the desired
position and release the lever. Let
the seat-back latch in the new
position.
Driver's Seat Power Height
Adjustment

U.S. EX model only

The height of your driver's seat is power adjustable. Pull up on the
switch to raise the seat. Push it down
to lower the seat.

Instruments and Controls

Reclining the seat-back can
decrease the protection you get
from your seat belt in a crash.
You can slide under the seatbelt and be seriously injured.
Adjust the seat-back to an upright position and sit well
back in the seat.ProCarManuals.comMain Menu s t Table of Contents

Seats

Head Restraints

KNOB

The head restraints are designed to help reduce the risk of neck injuries.
Your Honda has adjustable head restraints in all the outside seating
positions. Adjust the head restraint so the top is even with the tops of
your ears. The head restraints adjust for height.
You need both hands to adjust the restraint. Do not attempt to adjust it
while driving. To raise it, pull upward.
To lower the restraint, press the release button and push the restraint
down.

To remove a head restraint for cleaning or repair, pull it up as far as
it will go. Push the release buttonand pull the restraint out of the seat-

back.
Third Seat Access

Six-passenger model

To get into or out of the third row seat, walk between the second row

seats.

Instruments and Controls Driving your vehicle without

head restraints can lead to a

serious injury to you and your passengers in a crash.
Make sure the head restraints
are in place and adjusted properly before driving.ProCarManuals.comMain Menu s t Table of Contents

Seats

Seven-passenger model

LOCK RELEASE LEVER

Pull the seat-back angle adjustment
lever on the second row seat to tilt
the seat-back forward. Pull the lock release lever and pivot the seat upout of the way. Move the second seat back into
place by pivoting the seat down.
Make sure it locks to the floor. Pull
the seat-back angle adjustment lever
forward and push the seat-back to
the desired position, then release the
lever. Make sure the seat is securely locked in place. Removing the Second Seats in the
Six-Passenger Model
Both seats can be removed to give
more cargo capacity.
To remove a seat, unlock the seat from the floor by pulling both lock
release levers up at the same timeand pulling up on the rear of the seat.

CONTINUED

Instruments and Controls
LOCK RELEASE LEVERProCarManuals.comMain Menu s t Table of Contents

Seats

Unhook the front of the seat from
the floor by pulling it back slightly,
then pivoting it upward.
Always remove an unlocked seat from the vehicle before driving. Aseat that is not locked in place could
fly around and cause injury in a sudden stop or crash. To reinstall a seat, hook the front of
the seat to the floor, then push the
back into the locks. Make sure both
the front and the back of the seat are securely fastened down before
driving. Folding the Second Seats in the
Seven-Passenger Model
The left and right halves of the second seat can be folded up
separately to create more cargo

space.

Instruments and ControlsProCarManuals.comMain Menu s t Table of Contents

Seats

SEAT-BACK ANGLE

ADJUSTMENT LEVER

LOCK RELEASE LEVER

Pull the seat-back angle adjustment
lever and tilt the seat-back forward.
Then pull the lock release lever and pivot the seat forward.
RIVET

Pull out the fastening strap. Hook
the ring on the fastening strap to the rivet on the side of the seat-back.
Make sure the seat is secure.
Reverse this procedure to return the seat to the upright position. Make
sure you store the fastening strap
properly, and that the seat is locked securely before driving. Reclining the Second Seat
Seven-passenger model only
You can recline the seat-backs on the second seat so they are level with
the seat cushion of the third seat,
making a large, cushioned area. To do this:
1. Remove the head restraints. Store them in the pocket in the left side
panel behind the third seat.

Instruments and Controls
CONTINUED

FASTENING STRAPProCarManuals.comMain Menu s t Table of Contents

Seats

ANGLE ADJUSTMENT LEVER

SLIDE LEVER

2. Lift the lever and slide the seat forward as far as it will go. Pull the
seat-back angle adjustment lever
and pivot the seat-back backward.
Release the lever when the seat-
back is even with the cushion on
the third seat.
Reverse this procedure to return the
second seat to the upright position.
Make sure you install the head
restraints before driving (see page 56). Folding the Third Seat in All
Models
To create more cargo space, you can
fold the third seat into the floor
recess.

To fold the third seat:
1. Remove the head restraints. Store them in the pocket in the left side

panel.
KNOB
2. Unlock the seat-back by turning the knob. Push the seat-back
forward.

Instruments and ControlsProCarManuals.coms t Main Menu Table of Contents

Seats

KNOB

3. Turn the knob on the back of the seat cushion while you pull the
entire seat towards you. Pivot the
seat into the floor recess.
To return the seat to the upright

position:

1. Pull the seat out of the recess by
pulling on the handle. Pivot the

seat forward all the way.
KNOB

2. Turn the knob on the seat-back and pull the seat-back upright.
Make sure the seat is securely
locked in place.
3. Reinstall the head restraints.
Instruments and ControlsProCarManuals.coms t Main Menu Table of Contents

Loading Cargo

The maximum load you can carry in your Honda is 535 kg (1,150 Ibs). It includes the total weight of all
passengers and their belongings, anyaccessories, and the tongue weight
figure is shown as the Vehicle Capacity Weight on the tire infor-
mation label attached to the driver's doorjamb. To figure out how much cargo you
can carry:
Figure the total "occupant weight"
you will be transporting. To. do this. (driver and all passengers) by 70

kg
(150 Ibs).
Subtract this number from the
Vehicle Capacity Weight (535 kg/ 1,150 Ibs).
If you are towing a trailer, subtract
the tongue weight. See Towing a
Trailer on page 128.
This final number is the total weight of cargo you can load in or on the car.
With seven occupants (driver and six passengers), the maximum recom-
mended weight for cargo is 45 kg (100 Ibs).
Where you store this cargo, and how
well you secure it, are just as important as how much it weighs.Make sure you load cargo so it will not shift while driving. Items stored
in the cargo area behind the third
seat should be placed as far forward
as possible. You could store addi-
tional items on the floor behind the
roll under the front seat and
interfere with the pedals.
For greater cargo capacity, the third seat can be folded into the floor and
the second row seats can either be
removed or folded up (depending on
model). Passengers should never sit in the open cargo area while the car
is moving. They should sit in one of
the seats and wear their seat belts.
If you must carry large objects that
prevent you from closing the tailgate
be aware that exhaust gas can enter
the interior. See Carbon Monoxide
Hazard on page 29 .
