1996 FORD WINDSTAR wheel size

250
*
[DR13700(ALL)01/93]
Vehicle Loading Information
*
[DR13800(ALL)04/95]
Your vehicle's load capacity is designated by weight, not
volume, so you cannot necessarily use all the available space.
Maximum safe vehicle weights as well as tire sizes, rim sizes
and inflation pressures are specified for your vehicle at the
assembly plant on the Safety Compliance Certification Label.
The certification label is located on the pillar in the driver's
door opening.
*
[DR13900(ALL)01/93]
Each additional item of equipment affects how much cargo a
vehicle can carry. If a vehicle is overloaded, performance will
suffer and service concerns may arise.
*
[DR14200(ALL)01/93]
NOTE: The vehicle must not be loaded to both the front and
rear GAWR because the GVWR will be exceeded. The
GAWR of the front and rear axles exceed the GVWR
when added together.
*
[DR14500(ALL)01/93]
Understanding Loading Information
*
[DR14600(ALL)01/93]
There are five terms that are used to describe a vehicle's ability
to carry a load:
*
[DR14700(ALL)01/93]
n
Base Curb Weight
*
[DR14800(ALL)01/93]
n
Payload
*
[DR14900(ALL)01/93]
n
GVW (Gross Vehicle Weight)
*
[DR15000(ALL)01/93]
n
GVWR (Gross Vehicle Weight Rating)
*
[DR15100(ALL)01/93]
n
GAWR (Gross Axle Weight Rating)
*
[DR15200(ALL)06/92]
n
GCWR (Gross Combined Weight Rating)
*
[DR15300(ALL)01/93]
Base Curb Weight
*
[DR15400(ALL)04/95]
The base curb weight is the weight of the vehicle including fuel,
coolants, lubricants, emergency tools and spare wheel and tire.
It also includes any equipment that is standard. It does not
include passengers, cargo or optional equipment installed by
factory, dealer, aftermarket supplier or customer.
File:wndrs.ex
Update:Tue Mar 19 08:18:48 1996

Roadside Emergencies
267
%*
[RE03800(ALL)01/93]
Changing a Flat Tire
*
[RE03900(ALL)01/95]
If you get a flat tire while you are driving, do not apply the
brake heavily. Instead, gradually decrease the speed. Hold the
steering wheel firmly and slowly move to a safe place on the
side of the road. Park on a level spot, turn off the ignition, set
the parking brake, and turn on the hazard flashers.
% [RE04000(ALL)02/95]
Using the Spare Tire
*
[RE04100(ALL)03/94]
Your vehicle has a temporary spare tire (unless you ordered the
optional full-size spare tire). This spare tire is smaller than a
regular tire and is designed for emergency use only. Use it only
when you get a flat tire and replace it as soon as you can. This
spare tire is marked with the words TEMPORARY USE ONLY
so that you can easily identify it.
*
[RE04200(ALL)01/93]
RWARNING
If you use the temporary spare tire continuously or do
not follow these precautions, the tire could fail, causing
you to lose control of the vehicle, possibly injuring
yourself or others.
*
[RE04300(ALL)02/95]
When you drive with the temporary spare tire, DO NOT:
*
[RE04500(ALL)02/95]
n
exceed 50 mph (80 km/h) under any circumstances
*
[RE04600(ALL)01/93]
n
load your vehicle so that it is heavier than the maximum
vehicle load rating listed on the tire decal
*
[RE04700(ALL)01/93]
n
tow a trailer
*
[RE04800(ALL)01/93]
n
use tire chains
*
[RE04900(ALL)01/93]
n
try to repair the temporary spare tire or remove it from its
wheel
File:wnres.ex
Update:Tue Mar 19 08:18:21 1996

330
[SV25100(ALL)03/94]
10-1/2 pica
art:0050224-A
Rotating the tires
*
[SV25300(ALL)01/93]
If your vehicle has the optional full-size spare tire, you may
rotate the spare tire into the rotation pattern.
[SV25500(ALL)11/93]
If your vehicle has aluminum wheels, you may remove the
full-size (if equipped) spare tire from the wheel and remount it
on an aluminum wheel to rotate the spare tire into your
vehicle's rotation pattern.
%*
[SV25600(ALL)04/95]
Replacing the Tires
*
[SV25700(ALL)01/93]
Replace tires that show wear bands. When your tire shows a
wear band, it has only 1/16 of an inch (1.59 mm) of tread left.
*
[SV25800(ALL)11/93]
7-1/2 pica art:0040200-A
A worn-out tire
File:wnsvs.ex
Update:Tue Mar 19 08:16:43 1996

Servicing Your Windstar
331
*
[SV25900(ALL)01/95]
Because your vehicle's tires may wear unevenly, you may need
to replace them before a wear band appears across the entire
tread. Some spots wear more heavily than others.
*
[SV26100(ALL)01/95]
RWARNING
When replacing full size tires, never mix radial,
bias-belted, or bias-type tires. Use only the tire sizes that
are listed on the tire pressure decal. Make sure that all
tires are the same size, speed rating, and load-carrying
capacity. Use only the tire combinations recommended on
the decal. If you do not follow these precautions, your
vehicle may not drive properly and safely.
*
[SV26200(ALL)03/90]
RWARNING
Make sure that all replacement tires are of the same size,
type, load-carrying capacity, and tread design (e.g. ªAll
Terrainº, etc.), as originally offered by Ford.
*
[SV26225(ALL)04/95]
RWARNING
Do not replace your tires with ªhigh performanceº tires
or larger size tires.
*
[SV26250(ALL)05/95]
RWARNING
Use of aftermarket wheel assemblies may damage your
vehicle or cause accidents resulting in serious injuries.
*
[SV26300(ALL)05/95]
RWARNING
Failure to follow these precautions may adversely affect
the handling of the vehicle and make it easier to lose
control and roll over.
File:wnsvs.ex
Update:Tue Mar 19 08:16:43 1996
