1996 FORD THUNDERBIRD steering wheel

96
%*
[SC07300( ALL)01/95]
Tilt Steering
*
[SC07400( ALL)05/95]
RWARNING
Never adjust the steering wheel when the
vehicle is moving.
[SC07700(MBC )03/93]
half page art:0010088-B
The lever to tilt the steering wheel
*
[SC08000( ALL)04/95]
To change the position of the steering wheel,
pull the release lever on the column toward you.
Tip the steering wheel to the desired position.
Release the lever to lock the steering wheel in
place.
File:rcscb.ex
Update:Mon Feb 19 10:50:25 1996

98 [SC09300(MBC )08/93]
half page art:0001014-BThe speed control switches on the steering wheel
*
[SC10100( ALL)03/95]
To set the speed control:
*
[SC10300( ALL)03/95]
1. Press and release the ON switch.
*
[SC10400( ALL)04/95]
2. Accelerate to the desired speed above
30 mph (50 km/h) using the accelerator
pedal.
*
[SC10800( ALL)03/95]
3. Press the SET ACCEL switch and release it
immediately to set your speed. If you keep
this switch pressed, your speed will continue
to increase.
*
[SC10900( ALL)03/95]
4. Take your foot off the accelerator pedal.
Your vehicle will maintain the speed you set.
*
[SC11000( ALL)01/95]
If you drive up or down a steep hill, your
vehicle may momentarily slow down or speed
up, even though the speed control is on. This is
normal.
File:rcscb.ex
Update:Mon Feb 19 10:50:25 1996

172 [DR09793( BCGV)01/95]If the Traction Assist
TM
system is cycled
excessively, the system will shut down to
prevent the rear brakes from overheating.
During this shutdown period, the word OFF in
the traction assist switch will be illuminated
showing that the traction assist system is
inoperative. A cooling down period is required
to prevent damage to the rear brakes. This time
period varies and depends on brake usage
during the cooling down period. Anti-Lock
braking is not affected and will function
normally during the cool down period.
[DR09795( BCGV)05/95]
NOTE: Traction-Lok axles are not an available
option on vehicles equipped with
traction assist.
*
[DR09800( ALL)01/95]
Steering Your Vehicle
%*
[DR09900( ALL)01/95]
Your vehicle comes with power steering. Power
steering uses energy from the engine to help
steer your vehicle.
%*
[DR09950( ALL)04/95]
If the amount of effort needed to steer your
vehicle changes at a constant vehicle speed, have
the power steering system checked. If the power
steering system breaks down (or if the engine is
turned off), you can steer the vehicle manually
but it takes more effort.
*
[DR10000( ALL)01/95]
Never hold the steering wheel to the extreme
right or left for more than five seconds if the
engine is running. This can damage the power
steering pump.
[DR10200( BCGV)12/94]
Speed Sensitive Power Steering
(If equipped)
[DR10401( BC )06/94]
The steering system in 4.6L engine vehicles is
speed sensitive. This means that the steering
effort is light for parking and heavier for
highway driving. However, if you have to
swerve around an object or another vehicle, your
steering will have full power assist.
File:rcdrb.ex
Update:Mon Feb 19 10:48:37 1996

173
%*
[DR10500( ALL)03/95]
Brakes
%*
[DR10600( ALL)01/95]
Applying the Brakes
[DR10650( ALL)05/95]
Braking non ABS models
[DR10800( B )03/95]
Your vehicle has standard power front disc
brakes and rear drum brakes, (anti-lock disc
brakes on all four wheels are optional). They
adjust automatically as the brake pads or linings
wear down.
*
[DR11100( ALL)04/95]
Apply the brake pedal gradually. Use the
ªsqueezeº technique Ð push on the brake pedal
with a steadily increasing force. This allows the
wheels to continue to roll while you are slowing
down, which lets you steer properly.
[DR11300( ALL)03/95]
On vehicles without anti-lock brakes, extreme
braking can make the wheels lock and slide,
possibly decreasing your control of the steering.
If you lock the wheels, release the brake pedal
and repeat the ªsqueezeº technique.
[DR11310( ALL)05/95]
Braking with ABS brakes
[DR11400( ALL)03/95]
On vehicles with anti-lock brakes, the wheels
will not lock and slide when you press down
hard on the brake pedal. The anti-lock brakes
automatically start releasing and reapplying the
front brakes independently and the rear brakes
together whenever your wheels start to lock. Do
not ªpumpº the brake pedal on vehicles
equipped with anti-lock brakes. When this
happens, you will feel the brake pedal pulse.
This ªpulseº may be an unfamiliar feeling but it
is normal and indicates the ABS is working as
designed.
*
[DR11650( ALL)05/95]
Do not drive with your foot resting on the brake
pedal; you will wear out the linings and increase
your vehicle's stopping distance. Brake rotor
damage may also eventually occur.
File:rcdrb.ex
Update:Mon Feb 19 10:48:37 1996

176 [DR14400( ALL)07/93]The parking brake system is designed for static
parking only and is not designed to stop a
moving vehicle, but you can use the parking
brake to stop your vehicle in an emergency if
the normal brakes fail. However, since the
parking brake applies only the rear brakes, the
stopping distance will increase greatly and the
handling of your vehicle will be adversely
affected.
*
[DR14500( ALL)01/95]
Driving Under Special Conditions
%*
[DR14600( ALL)01/95]
Tips for Safe Driving
*
[DR14700( ALL)03/95]
As with any new vehicle, yours may drive and
handle differently from your previous vehicle.
Use care until you become accustomed to its
various features and driving characteristics.
*
[DR14800( ALL)03/95]
Operate your vehicle within reasonable limits.
Sudden acceleration, deceleration, turning, or
combinations of these maneuvers can cause a
vehicle to behave differently than anticipated.
%*
[DR15200( ALL)01/95]
Driving in Bad Weather
%*
[DR15300( ALL)01/95]
Slippery roads
*
[DR15400( ALL)03/95]
Drive cautiously on wet or snowy roads:
*
[DR15500( ALL)03/95]
q
Do not quickly move the steering wheel
unless necessary.
*
[DR15600( ALL)01/95]
q
Drive slower than you normally would.
[DR15700( ALL)03/95]
q
Do not use speed control.
*
[DR15800( ALL)01/95]
q
Give your vehicle more distance to stop.
*
[DR15900( ALL)03/92]
q
Pump the brake pedal steadily and evenly to
avoid locking your wheels. (Does not apply
to vehicles with anti-lock brakes.)
*
[DR16000( ALL)02/93]
q
Consider using one of the lower gears.
File:rcdrb.ex
Update:Mon Feb 19 10:48:37 1996

191
%*
[RE03900( ALL)03/95]
Changing a Tire
*
[RE04000( ALL)01/95]
If you get a flat tire while you are driving, do
not apply the brake heavily. Instead, gradually
decrease the speed. Hold the steering wheel
firmly and slowly move to a safe place on the
side of the road. Park on a level spot, turn off
the ignition, set the parking brake, and turn on
the hazard flashers.
%*
[RE04100( ALL)03/95]
The Temporary Spare Tire
[RE04225(MBC )03/94]
You have a high pressure temporary spare tire.
This spare tire is smaller than a regular tire and
is designed for emergency use only. Use it only
when you get a flat tire and replace it as soon
as you can. This spare tire is marked with the
words ªTEMPORARY USE ONLYº so that you
can easily identify it.
*
[RE04250( ALL)01/95]
NOTE: Extended use of other than
conventional spare tires on a
Traction-Lok rear axle could result in a
permanent reduction in effectiveness.
This loss of effectiveness does not
affect normal driving and should not
be noticeable to the driver.
*
[RE04300( ALL)01/93]
RWARNING
If you use the temporary spare tire
continuously or do not follow these
precautions, the tire could fail, causing
you to lose control of the vehicle, possibly
injuring yourself or others.
File:rcreb.ex
Update:Mon Feb 19 10:48:15 1996

261
%*
[SV34800( ALL)03/95]
Power Steering Fluid
*
[SV34900( ALL)01/95]
Check the level of the power steering fluid at
least twice a year (i.e., every Spring and Fall).
%*
[SV35000( ALL)03/95]
Checking and Adding Power Steering
Fluid
[SV35050( BC )10/95]
3.8L SFI engine
*
[SV35100( ALL)02/95]
1. Start the engine and let it run until the
power steering fluid reaches normal
operating temperature. The power steering
fluid will be at the right temperature when
the engine coolant temperature gauge in the
instrument cluster is near the center of the
NORMAL operating temperature range.
*
[SV35200( ALL)01/95]
2. While the engine idles, turn the steering
wheel back and forth several times. Make
sure that the cap assembly is installed at this
time.
*
[SV35300( ALL)05/95]
3. Turn the engine off.
%*
[SV35400(MBC )03/94]
4. Check the fluid level on the dipstick (which
is highlighted in yellow in your vehicle). The
fluid level should be between the arrows in
the FULL HOT range, which is marked on
the side of the dipstick, opposite the side
marked FULL COLD. Do not add fluid if the
level is within the FULL HOT range.
*
[SV35500(MBC )07/94]
5. If the power steering fluid is low, add fluid
in small amounts, continuously checking the
level, until you reach the FULL HOT range.
Do not overfill.
*
[SV35600(MBC )03/95]
6. When you are finished, put the dipstick back
in and make sure that it fits snugly.
File:rcsvb.ex
Update:Mon Feb 19 10:46:54 1996

Index 321
Starting your vehicle (continued)
starting a cold engine.......... 48
starting after a collision......... 53
starting a warm engine......... 48
Steering, power............. 172
Steering wheel
horn.................. 95
locking................ 45
speed controls............. 97
tilting................. 96
Storage compartments
center console............ 127
map pockets............. 128
Storing your vehicle........... 288
Sun visor................ 126
Supplemental air bag readiness light.... 60
Supplemental Restraint System (SRS).... 18
T
Tachometer................ 68
Tail lamps
bulb replacement........... 279
cleaning................ 84
Temperature control (see Climate control) . . 74
Tether anchor installation
(see Child restraints).......... 27
Tilt steering wheel............ 96
Tires
changing............... 191
checking the pressure......... 251
cleaning............... 256
replacing............... 252
rotating............... 251
snow tires and chains......... 255
storing your vehicle.......... 290
tire grades.............. 253
treadwear.............. 254
wear bands............. 252
Towing a trailer (see Trailer towing) . . . 180
Towing your vehicle, with a tow truck . . 201
