1996 FORD TAURUS tow

108
*
[IP25636(ALL)09/95]
NOTE: The high beam indicator will not turn
on in the flash-to-pass mode during
nighttime driving.
[IP25637(ALL)01/95]
You may notice that the lights flicker when the
vehicle is turned on or off. This is a normal
condition.
*
[IP25638(ALL)05/95]
RWARNING
The Daytime Running Light (DRL) system
will not illuminate the tail lamps and
parking lamps. Turn on your headlamps
at dusk. Failure to do so may result in a
collision.
%*
[IP25640(ALL)08/95]
Cleaning the Exterior Lamps
*
[IP25650(ALL)08/95]
Do not use dry paper towel, chemical solvents
or abrasive cleaners to clean the lamps, as these
may cause scratches or crack the lamps.
%*
[IP26600(ALL)02/95]
Setting the Autolamp Delay System
(If equipped)
*
[IP26700(ALL)02/95]
The autolamp sets the headlamps to turn on and
off automatically. You can use the autolamp to:
*
[IP26800(ALL)01/95]
q
turn on the lamps automatically at night
*
[IP26900(ALL)01/95]
q
turn off the lamps automatically during
daylight
[IP27000(ALL)11/94]
q
keep the lamps on for up to three minutes
after you turn the ignition to the OFF
position.
File:06fcipt.ex
Update:Tue Jan 23 08:13:16 1996
ProCarManuals.com

110
*
[IP28500(ALL)01/95]
You can set the autolamp so the headlamps stay
on for up to three minutes after you turn your
vehicle off.
*
[IP28600(ALL)01/95]
To keep the lamps on after you leave your
vehicle:
*
[IP28650(ALL)01/95]
q
Turn the thumbwheel as far into the MAX
range as you want.
*
[IP28750(ALL)01/95]
q
The further you move the thumbwheel into
the DELAY area (toward the MAX position),
the longer the lamps will stay on after you
leave your vehicle. Similarly, if you move the
thumbwheel only slightly into the DELAY
area, your lamps will stay on only for a
moment after you turn your vehicle off.
%*
[IP29800(ALL)01/95]
Lighting Up the Interior and Instrument
Panel
*
[IP30000(ALL)05/95]
With the light knob in the parking lamps or the
headlamps position, you can brighten or dim the
lights in the instrument panel. To do this, use
the thumbwheel to the left of the steering wheel.
This wheel also turns on the interior lights with
the light knob on or off.
% [IP30300(ALL)02/95]
one third page art:0000692-C
The thumbwheel that controls the light on the instrument
panel
File:06fcipt.ex
Update:Tue Jan 23 08:13:16 1996
ProCarManuals.com

116
*
[SC03200(ALL)05/95]
To turn off the high beams, pull the lever
toward you until it latches. The high beam
indicator light turns off.
%*
[SC03300(ALL)08/95]
Flashing the Lights
*
[SC03400(ALL)06/95]
To flash the headlamps, pull the lever toward
you for a moment and then release it. The
headlamps will flash whether the headlamp
knob is in the on or off position.
[SC03450(ALL)04/95]
one third page art:0001411-B
The turn signal lever
%*
[SC03500(ALL)08/95]
Windshield Wipers and Washer
*
[SC03600(ALL)03/95]
To turn on the windshield wipers, the ignition
key must be turned to the ON or ACC position.
[SC03900(ALL)05/94]
Turn the knob on the end of the turn signal
lever away from you to activate the wipers. The
first seven detents are interval wipe positions,
the eighth detent is the LO position, and the
ninth detent is the HI position.
*
[SC04000(ALL)01/95]
To turn the wipers off, turn the knob toward
you to the OFF position.
File:07fcsct.ex
Update:Mon Jan 22 15:52:32 1996
ProCarManuals.com

117 %
*
[SC04100(ALL)08/95]
Variable Interval Wipers
*
[SC04300(ALL)01/95]
In addition to two speed wipers, your vehicle
has wipers that you can set to operate at
varying intervals. For example, you can set the
interval so they wipe less often when it drizzles
or more often in heavier rain.
[SC04500(ALL)04/95]
one third page art:0001412-B
The variable interval wiper on the turn signal lever
*
[SC04925(ALL)03/94]
To set the interval wipers, turn the knob at the
end of the turn signal lever toward or away
from you until the wipers are going at the
desired interval.
*
[SC04950(ALL)08/95]
Windshield Washer
[SC05000(ALL)05/94]
To clean the windshield, push in the end of the
wiper switch knob. For a constant spray, keep
the knob pushed in. After you release the knob,
the wipers operate for two to three cycles before
turning off (if the wipers were off) or returning
to HI, LO, or the interval setting selected.
[SC05050(ALL)04/95]
For information about the rear washer on the
wagon, seeWindshield washer fluid and wipersin
the Index.
File:07fcsct.ex
Update:Mon Jan 22 15:52:32 1996
ProCarManuals.com

120 [SC06650(ALL)11/94]
one third page art:0000658-BThe lever to tilt the steering wheel
*
[SC06800(ALL)04/95]
To change the position of the steering
column/wheel, pull the release lever on the
column toward you. Tip the steering wheel to
the desired position. Release the lever to lock the
steering wheel in place.
%
*
[SC07400(ALL)03/91]
Cruise Control (If equipped)
*
[SC07500(ALL)06/95]
If your vehicle has cruise control, you can
automatically maintain a constant speed at or
above 30 mph (50 km/h).
*
[SC07550(ALL)09/95]
NOTE: Do not shift to N (Neutral) when using
the cruise control. This will cause the
engine to overspeed.
*
[SC07600(ALL)06/95]
Use of radio transmitting equipment that is not
Federal Communications Commission (FCC) or
in Canada the Canadian Radio and
Telecommunications Commission (CRTC)
approved may cause the speed control to
malfunction. Therefore, use only properly
installed FCC (CRTC in Canada) approved radio
transmitting equipment in your vehicle.
File:07fcsct.ex
Update:Mon Jan 22 15:52:32 1996
ProCarManuals.com

127 [FV04010(ALL)04/95]
Central Locking
[FV04020(ALL)04/95]
When you are unlocking the driver or front
passenger door with the key, turn it once
toward the front of the vehicle to unlock that
door only. Turn the key a second time to unlock
all doors. Turn the key once toward the rear of
the vehicle to lock all doors.
[FV04050(ALL)04/95]
Lock Disable
[FV04075(ALL)03/95]
The lock disable feature helps prevent you from
locking the keys in your vehicle. With the key in
the ignition (in any switch position) and the
driver's door open, the driver's door cannot be
locked using the front door power lock switch.
[FV04100(ALL)02/95]
Your vehicle can still be locked, while the key is
in the ignition, by manually pressing down the
lock button.
[FV04125(ALL)02/95]
Power liftgate lock Ð wagon (If equipped)
[FV04150(ALL)02/95]
The power liftgate lock is on the right inside
trim panel in the cargo area. When this lock is
pressed, all doors and the liftgate lock.
[FV04175(ALL)02/95]
one inch art:0001407-A
The power liftgate lock
File:08fcfvt.ex
Update:Mon Jan 22 15:57:12 1996
ProCarManuals.com

137
*
[FV08551(ALL)02/95]
NOTE: The operating range of the remote
entry system can also be affected by
weather conditions (such as very cold
temperatures) or structures around the
vehicle (buildings, other vehicles, radio
and TV towers, etc.). Typical operating
range will allow you to be up to 33
feet (10 meters) away from your
vehicle.
*
[FV08600(ALL)02/95]
The transmitter can be snapped apart to replace
the batteries by twisting a thin coin between the
two halves of the transmitter. DO NOT TAKE
THE FRONT PART OF THE TRANSMITTER
APART. When installing the new batteries, be
sure to place the positive (+) side down as
marked. Snap the two halves back together.
[FV08651(ALL)02/95]
quarter page art:0020790-A
Replacing the batteries
%*
[FV08700(ALL)02/95]
Replacing lost transmitters
*
[FV08751(ALL)06/95]
In the event a transmitter is lost, you should
take all your vehicle's transmitters to your
dealer to have the remote entry system
deprogrammed for the lost transmitter. This is
necessary to prevent further unauthorized use of
the lost transmitter.
*
[FV08800(ALL)02/95]
You can also purchase additional transmitters
(up to 4 transmitters can be used) from your
dealer. You will need to take all your
transmitters to the dealer so they can program
them to the remote entry system all at the same
time.
File:08fcfvt.ex
Update:Mon Jan 22 15:57:12 1996
ProCarManuals.com

145
*
[FV12000(ALL)07/95]
To close from vent position, press and hold the
rear portion of the switch.
*
[FV12100(ALL)01/95]
RWARNING
Do not let children play with the moon
roof. They may seriously hurt themselves.
*
[FV12200(ALL)01/95]
Occasionally wiping the outside guide rail covers
of the moon roof with a clean cloth will help
keep the moon roof working properly.
[FV12300(ALL)11/94]
quarter page art:0000420-B
The moon roof
*
[FV12400(ALL)01/95]
Sliding Shade
*
[FV12500(ALL)01/95]
The moon roof has a sliding shade that you can
manually open or close to block the sun when
the glass panel is shut.
*
[FV12600(ALL)05/95]
To close the sliding shade, pull the shade toward
the front of the vehicle. The shade automatically
opens and locks when the moon roof is opened.
%
*
[FV12700(ALL)01/95]
Seats
%*
[FV12702(ALL)04/95]
Head Restraints
*
[FV12704(ALL)02/95]
If you use them properly, head restraints are
intended to help protect your head and neck in
a collision.
*
[FV12705(ALL)05/95]
A head restraint helps protect you best if you
position it behind your head and not behind
your neck.
File:08fcfvt.ex
Update:Mon Jan 22 15:57:12 1996
ProCarManuals.com
