Cleaning the Exterior Lamps
*
[IP17500(BEF )05/95]
Do not use dry paper towel, chemical solvents
or abrasive cleaners to clean the lamps, as these
may cause scratches or crack the lamps.
%*
[IP17715( F )04/95]
Fog Lamps (If equipped)
*
[IP17735( F )06/92]
The fog lamps rocker switch is located on the
instrument panel to the right of the steering
column.
*
[IP17755( F )06/92]
quarter page art:0020940-A
Fog lamp switch
*
[IP17760( F )02/93]
The fog lamps act as a supplement to the low
beam headlamps under limited visibility
conditions such as rain, snow, dust or fog and
operate only when the low beam headlamps are
on.
*
[IP17770( F )02/93]
To maximize fog lamp bulb life it is
recommended that the fog lamp switch be
turned off after each use prior to turning off the
headlamps.
*
[IP17780( F )06/94]
q
To turn the fog lamps on, push the ON side
of the rocker switch. An indicator light will
glow when the lamps are on.
*
[IP17790( F )06/94]
q
To turn off, push the OFF side of the switch.
