1996 FORD RANGER adding oil

66
*
[LG08001(ALL)02/95]3.
Check the engine's oil level, following the instructions on
checking and adding engine oil. Refer toEngine oilin the
Index. If you do not follow these instructions, you or others
could be injured. To assure an accurate reading, your vehicle
should be on level ground.
*
[LG08051(ALL)03/93]4.
If the level is low, add only as much oil as necessary before
you start the engine again. Do not overfill. Do not operate
the engine if the pointer is below the NORMAL band,
regardless of the oil level. Contact your nearest dealer for
further service actions.
[LG08100(R )10/94]
7-1/2 pica art:0020056-E
Engine oil pressure gauge Ð mechanical cluster
[LG08150(ALL)10/94]
7-1/2 pica art:0020540-E
Engine oil pressure gauge Ð mechanical cluster with tachometer
File:05unlgr.ex
Update:Wed May 1 13:45:37 1996

276
%*
[SV13775(ALL)01/95]
Checking and Adding Engine Oil
*
[SV13800(ALL)03/95]
Since the proper amount of engine oil is important for safe
engine operation, check the oil using the dipstick each time you
put fuel in your vehicle. Remember the engine must be off, the
oil must be warm and the vehicle must be parked on level
ground.
%*
[SV13900(ALL)04/95]
Checking the engine oil level:
*
[SV14000(ALL)02/95]1.
Turn the engine off after it has warmed up and allow a few
minutes for the engine oil to drain back into the oil pan.
*
[SV14050(ALL)06/95]2.
Set the parking brake, making sure the gearshift is securely
latched in P (Park) or 1 (manual transmission).
*
[SV14100(ALL)02/95]3.
Open the hood. Protect yourself from engine heat.
*
[SV14200(ALL)03/95]4.
Locate the engine oil dipstick (highlighted in yellow) and
carefully pull it out of the engine.
*
[SV14300(ALL)01/95]5.
Wipe the dipstick clean and put it back into position, making
sure it is fully seated.
[SV14400(ALL)10/94]
7-1/2 pica art:0021256-B
Engine oil dipstick
[SV14500(ALL)10/94]6.
Carefully, pull the dipstick out again. If the oil level is below
the ªADDº line, add engine oil as necessary. If the oil level
is beyond the letter ªFº in Full, engine damage or high oil
consumption may occur and some oil must be removed from
the engine.
*
[SV14600(ALL)01/95]7.
Put the dipstick back in and make sure it is fully seated.
File:15unsvr.ex
Update:Wed May 1 13:56:18 1996

Servicing Your Ranger
277
*
[SV14800(ALL)01/95]
It may be necessary to add some oil between oil changes. Make
sure you use a CERTIFIED engine oil of the preferred viscosity.
Your vehicle's warranty coverage may not apply if engine
damage is caused by the use of improper engine oil.
*
[SV15000(ALL)03/95]
Add engine oil through the oil filler cap highlighted in yellow.
To add oil, remove the filler cap and use a funnel to pour oil
into the opening. Be careful not to overfill the engine. Recheck
the oil level after you finish adding oil.
%*
[SV16300(ALL)06/95]
Changing the Engine Oil and the Oil Filter
[SV16350(ALL)03/95]
Change the engine oil and oil filter per the following, whichever
occurs first:
[SV16375(ALL)03/95]
half page art:0090154-A*
[SV16400(ALL)03/95]
Refer to the Maintenance Schedule and Record Booklet for
additional information.
File:15unsvr.ex
Update:Wed May 1 13:56:18 1996

356
