two third page art:0032122-AThe rear lamps
[SV43800(ALL)04/93]
5. Install the bulb by pushing it into the socket
and turning it clockwise.
[SV43900(ALL)04/93]
6. Install the socket by pushing it into its
housing and turning it clockwise. The arrow
on the socket must align with the arrow on
the housing when installed.
[SV44000(ALL)04/93]
7. Replace the rear lens and rear lens cover.
File:prsvp.ex
Update:Fri Jun 23 19:33:26 1995

261
*
[SV47200(ALL)03/95]
Bulb Specifications
[SV47300(ALL)05/93]
sixteen pica chart:0030275-G*
[SV47600(ALL)03/95]
Emission Control System
*
[SV47700(ALL)05/95]
Your vehicle is equipped with a catalytic
converter which enables your vehicle to comply
with applicable exhaust emission requirements.
*
[SV47750(ALL)05/95]
RWARNING
Exhaust leaks may result in the entry of
harmful and potentially lethal fumes into
the passenger compartment. Under
extreme conditions excessive exhaust
temperatures could damage the fuel
system, the interior floor covering, or
other vehicle components, possibly
causing a fire.
File:prsvp.ex
Update:Fri Jun 23 19:33:26 1995

262
*
[SV47800(ALL)05/95]
To make sure that the catalytic converter and the
other emission control parts continue to work
properly:
*
[SV47900(ALL)01/95]
q
Use only unleaded fuel.
*
[SV48000(ALL)01/95]
q
Avoid running out of fuel.
*
[SV48100(ALL)01/95]
q
Do not turn off the ignition while your
vehicle is moving, especially at high speeds.
*
[SV48150(ALL)01/95]
q
Do not push start your vehicle.
*
[SV48200(ALL)03/95]
q
Have the services listed in yourMaintenance
Schedule and Recordbooklet performed
according to the specified schedule.
*
[SV48300(ALL)05/95]
RWARNING
Do not park, idle, or drive your vehicle in
dry grass or other dry ground cover. The
emission system heats up the engine
compartment and exhaust system, which
can start a fire.
*
[SV48400(ALL)05/95]
Watch for fluid leaks, strange odors, smoke, loss
of oil pressure, the charge warning light, the
check engine light, or the temperature warning
light. These sometimes indicate that the emission
system is not working properly.
*
[SV48500(ALL)01/95]
Do not make any unauthorized changes to your
vehicle or engine. Changes that cause more
unburned fuel to reach the exhaust system can
increase the temperature of the engine or
exhaust system.
%*
[SV48550(ALL)05/95]
In general, maintenance, replacement, or service
of the emission control devices or systems in
your new Ford Motor Company vehicle or
engine may be performed at your expense by
any automotive repair establishment or
individual using automotive parts equivalent to
those with which your vehicle or engine was
File:prsvp.ex
Update:Fri Jun 23 19:33:26 1995

263
originally equipped. If other than Ford or
Motorcraft or Ford authorized remanufactured
parts are used for maintenance, replacement, or
for the service of components affecting emission
control, the owner should be assured that such
parts are warranted by their manufacturer to be
equivalent to genuine Ford Motor Company
parts in performance and durability. Please
consult your warranty information booklet for
complete warranty information.
*
[SV48600(ALL)01/95]
By law, anyone who manufactures, repairs,
services, sells, leases, trades vehicles, or
supervises a fleet of vehicles is not permitted to
intentionally remove an emission control device
or prevent it from working. In some of the
United States and in Canada, vehicle owners
may be liable if their emission control device is
removed or is prevented from working.
*
[SV48700(ALL)02/92]
Never use a metal exhaust collector when you
service your vehicle. If the metal collector
contacts any of your vehicle's plastic trim or
bumper parts they could melt or deform.
*
[SV48800(ALL)01/95]
Do not drive your vehicle if it does not operate
properly. See your dealer if the engine runs on
for more than five seconds after you shut it off
or if it misfires, surges, stalls, or backfires.
%*
[SV48810(ALL)05/95]
Information about your vehicle's emission
control system is on the Vehicle Emission
Control Information decal located on or near the
engine. This decal identifies engine displacement
and gives some tune-up specifications.
File:prsvp.ex
Update:Fri Jun 23 19:33:26 1995

264 %
*
[SV48820(ALL)06/95]
Readiness for Inspection/Maintenance
Testing
*
[SV48830(ALL)06/95]
In some localities it may become a legal
requirement to pass an
Inspection/Maintenance (I/M) test of the
On-Board Diagnostic (OBD) II system. If the
vehicle's powertrain system or its battery has
just been serviced, the OBD II system is reset to
a not ready for I/M testing condition. To
prepare for I/M testing, the law specifies a
ªneed for additional mixed city and highway
driving to complete the checkº of the OBD II
system. As soon as all of the OBD II system
checks are successfully completed, the OBD II
system is set to the ready condition. The amount
of driving required to reach the ready condition
varies with individual driving patterns. To
complete this requirement in the minimum
amount of time, refer to the OBD II Drive Cycle
defined below. If the vehicle owner cannot or
does not want to do the additional driving
required by law, a service center can perform
this drive cycle as it would any other type of
repair work.
*
[SV48840(ALL)06/95]
OBD II Drive Cycle
*
[SV48845(ALL)06/95]
The following steps must be run in the order
shown. If any steps are interrupted, repeat the
preceding step. Any safe driving mode is
acceptable between steps.
*
[SV48850(ALL)06/95]
Always drive vehicle in safe manner according
to traffic conditions and obey all traffic laws.
File:prsvp.ex
Update:Fri Jun 23 19:33:26 1995

265
*
[SV48860(ALL)06/95]
The engine must be warmed up and at
operating temperature before proceeding with
the drive modes of the following OBD II Drive
Cycle.
*
[SV48870(ALL)06/95]
1. Start the engine. Drive or idle (in neutral)
the vehicle for 4 minutes.
[SV48880(ALL)05/95]
2. Idle the vehicle in drive (neutral for
automatic transaxles) for 40 seconds.
[SV48890(ALL)05/95]
3. Accelerate the vehicle to 45 mph (72 km/h)
(for manual transaxles upshift from 1st to
5th gear, but hold in 2nd for at least 5
seconds) at 1/4 to 1/2 throttle for 10
seconds.
[SV48895(ALL)05/95]
4. Drive the vehicle with a steady throttle at
45 mph (72 km/h) (manual transaxles use
5th gear) for 30 seconds.
[SV48900(ALL)05/95]
5. Idle the vehicle in drive (neutral for manual
transaxles) for 40 seconds.
[SV48910(ALL)05/95]
6. Continue to drive the vehicle in city traffic at
speeds between 25 and 40 mph
(40-64 km/h) (manual transaxles primarily
drive vehicles in 3rd and 4th gear when
possible) for 15 minutes. During the 15
minute drive cycle the following modes must
be achieved:
*
[SV48920(ALL)06/95]
a. at least 5 stop and idle modes at 10
seconds each
*
[SV48930(ALL)06/95]
b. acceleration from idles at 1/4 to 1/2
throttle position, and
*
[SV48940(ALL)06/95]
c. choose 3 different speeds to do 1.5
minute steady state throttle drives.
[SV48950(ALL)05/95]
7. Accelerate the vehicle up to between 45 and
60 mph (72-97 km/h) (manual transaxles
upshift to 5th gear). This should take
approximately 5 minutes.
File:prsvp.ex
Update:Fri Jun 23 19:33:26 1995

266 [SV48960(ALL)05/95]8. Drive vehicle and hold the throttle steady at
the selected speed between 45 and 60 mph
(72-97 km/h) (manual transaxles use 5th
gear) for approximately 5 minutes.
[SV48970(ALL)05/95]
9. Drive the vehicle for 5 minutes at varying
speeds between 45 and 60 mph
(72-97 km/h) (manual transaxles use 5th
gear).
[SV48980(ALL)05/95]
10. Bring the vehicle back to idle. Idle in drive
(manual transaxles use 5th gear) for 40
seconds.
[SV48990(ALL)05/95]
11. OBD drive cycle has been completed. Vehicle
can be turned off when convenient.
File:prsvp.ex
Update:Fri Jun 23 19:33:26 1995

267
*
[SV49000(ALL)03/95]
Refill Capacities, Motorcraft Parts,
and Lubricant Specifications
*
[SV49100(ALL)01/89]
Refill Capacities (Approximate)
[SV49200(ALL)06/94]
thirty-two pica chart:0030283-KFile:prsvp.ex
