1996 FORD MUSTANG fuses

287 %
*
[SV41210( ALL)06/95]
Checking and Replacing Fuses
*
[SV41215( ALL)02/95]
If you need to check a fuse, follow these steps:
[SV41220(M )03/93]
1. Find the fuse panel cover below and to left
of the steering column, in the instrument
panel. Pull outward on the handle below the
word ªfusesº to expose the fuse panel.
Squeeze the two backing tabs and pull to
remove the cover.
[SV41235(M )03/93]
2. On the fuse panel cover, find the number of
the fuse you want to check. The following
fuse panel cover tells you where to locate
the fuse on the panel.
*
[SV41500(M )01/95]
3. Check the fuse to see if it is blown. Look
through the clear side of the fuse to see if
the metal wire inside is separated. If it is,
the fuse should be replaced.
[SV41550( ALL)05/92]
quarter page art:0010416-A
The side view of a fuse
*
[SV41800(M )11/94]
4. Replace the fuse with one that has the right
amperage rating. (See the following chart.)
[SV41900( ALL)07/95]
eight pica chart:0001092-BFile:15rcsvm.ex
Update:Thu Mar 28 14:48:54 1996

288 [SV41910(M GV)01/94]
six pica chart:0001093-B
*
[SV42500( ALL)08/95]
RWARNING
Always replace a fuse with one that has
the specified amperage rating. Using a
fuse with a higher amperage rating can
cause severe wire damage and could start
a fire.
*
[SV42650(M )01/95]
5. Replace the cover.
*
[SV42800( ALL)01/95]
Even after you replace a fuse, it will continue to
blow if you do not find what caused the
overload. If the fuse continues to blow, have
your electrical system checked.
%*
[SV42900( ALL)03/95]
Circuit Breakers
*
[SV43000( ALL)01/95]
If you need to check a circuit breaker that is on
the fuse panel, seeChecking and replacing fusesin
this chapter to find out how to locate the fuse
panel.
[SV43200( ALL)12/94]
Circuit breakers will reset themselves and allow
the electrical parts to work again once the
overload on the circuit is removed. If the circuit
breakers continue to cut off electricity, have your
vehicle's electrical system checked.
*
[SV43250( ALL)02/95]
Diagnostic equipment is needed to check circuit
breakers. Refer to the manufacturer's
instructions.
*
[SV43300( ALL)08/95]
If you replace a circuit breaker, use one with the
same amperage rating. To remove a circuit
breaker mounted in the fuse panel, grip it with
your finger and thumb and pull it straight out
of its socket.
File:15rcsvm.ex
Update:Thu Mar 28 14:48:54 1996

320 Index
C
Canada, customer assistance....... 223
Canada, warranty information....... 4
Canadian Motor Vehicle Arbitration Plan
(CAMVAP).............. 223
Capacities for refilling fluids....... 298
Carbon monoxide in exhaust........ 56
Car seats for children
(see Child safety seats)......... 30
Cassette tape player (see Electronic
sound system)......141, 145, 162, 168
Catalytic converter............ 293
CD player (see Electronic
sound system)........148, 154, 155
Chains, tires.............. 268
Changing a tire............. 205
Charging system gauge.......... 76
Charging system warning light....... 68
Child safety restraints........... 28
child safety belts............ 46
child safety seats............ 30
Child safety seats
and air bags............ 24,30
automatic locking mode
(retractor)....... 14,15,30,32,39
in front seat............ 24,30
in front seat, convertible......... 32
in front seat, coupe........... 39
in rear outboard seat........ 30,39
in rear seat............... 30
Chime
key in ignition............. 51
safety belt............... 66
Circuit breakers
checking and replacing........ 287
see also fuses............. 278
Cleaning your vehicle
CD player and discs........152, 159
chrome and aluminum parts....... 7
File:rcixm.ex
Update:Wed Mar 27 09:41:15 1996

Index 323
Doors................. 103
lubricant specifications........ 300
Driving under special conditions
bad weather............. 190
heavy load.............. 192
high water.............. 191
slippery roads............ 190
tips for safe driving.......... 190
towing a trailer............ 194
E
Electrical system
circuit breakers............ 287
fuses..............278, 286
operating when the engine is off..... 49
power point outlet.......... 130
Electronic sound system
radio reception............ 173
tuning the radio.........142, 163
warranty and service information . . . 175
Electronic stereo cassette radio
(see Electronic sound system)..... 142
Emergencies, roadside
assistance.............. 215
battery acid spills........... 199
fuel................. 245
jump-starting............. 199
towing................ 213
Emergency brake (parking brake) . . . 187±188
Emission control system
catalytic converter.......... 293
emissions warranty......... 4,293
Engine
check engine warning light....... 70
does not start........... 54,57
fuel injected engine, starting..... 51,53
fuel pump shut-off switch........ 57
preparing to start..........51±52
refill capacities............ 298
service points............ 239
File:rcixm.ex
Update:Wed Mar 27 09:41:15 1996

326 Index
Fuel pump shut-off switch
engine does not start.......... 57
starting after a collision......... 57
Fuse panels
engine compartment.......... 282
high current fuse panel........ 283
instrument panel.........278, 286
Fuses
charts..............280, 286
checking and replacing........ 286
circuit breakers............ 287
G
Gas cap (see Fuel cap).......... 242
Gas mileage (see Fuel economy)..... 243
Gasohol................ 244
Gasoline (see Fuel)............ 242
Gauges, Mechanical
engine coolant temperature gauge.... 73
engine oil pressure gauge........ 77
fuel gauge............... 72
odometer................ 75
speedometer.............. 75
tachometer............... 76
trip odometer.............. 75
GAWR (Gross Axle Weight Rating)
calculating.............. 192
definition............... 192
driving with a heavy load....... 192
location............... 192
Gearshift
automatic operation.......... 177
console-mounted........... 179
downshifting............. 185
File:rcixm.ex
Update:Wed Mar 27 09:41:15 1996

Index 331
Mirrors................. 125
rearview............... 125
side view mirrors........... 125
side view mirrors (manual)...... 127
vanity mirror, illuminated....... 128
Motorcraft parts............. 299
N
National Highway Traffic
Safety Administration......... 222
New vehicle break-in........... 5
O
Octane rating............243±244
Odometer
description............... 75
trip odometer............. 75
Oil filter..............251, 299
Oil (see Engine oil)........... 248
Oil viscosity............248±249
On-board diagnostic (OBD II) system . . . 295
Overdrive............... 180
Overseas offices............. 224
P
Panic alarm feature, remote entry system . 111
Parking brake
operation.............. 188
warning light.............. 64
Parts (see Motorcraft Parts)....... 299
PCV valve, specifications........ 299
Power distribution box (see Fuses).... 278
Power door locks............ 103
Power features
door locks.............. 103
lumbar support............ 121
mirrors.............125, 127
seats................. 120
windows............... 114
File:rcixm.ex
Update:Wed Mar 27 09:41:15 1996
