1996 FORD F150 key

60
*
[ST08210(B F )03/95]
one third page art:0020005-C
Fuel pump shut-off switch location
*
[ST08250( F )02/95]
NOTE: Refer to theMotorhome Class A
Chassis Owner Guidefor information
regarding the fuel pump shut-off
switch for your motorhome chassis.
*
[ST08260( ALL)05/95]
RWARNING
If you see or smell fuel, do not reset the
switch or try to start your vehicle. Have
all the passengers get out of the vehicle
and call the local fire department or a
towing service.
*
[ST08270( ALL)03/95]
If your engine cranks but does not start after a
collision or substantial jolt:
*
[ST08280( ALL)04/95]
1. Turn the ignition key to the OFF position.
*
[ST08290( ALL)03/95]
2. Check under the vehicle for leaking fuel.
*
[ST08300( ALL)03/95]
3. If you do not see or smell fuel, push the red
reset button down. If the button is already
set, you may have a different mechanical
problem.
*
[ST08310(BEF )03/95]
4. Turn the ignition key to the ON position for
a few seconds, then turn it to the OFF
position.
File:ltstf.ex
Update:Thu May 9 15:26:52 1996

66
*
[LG03000( ALL)06/94]
The Mechanical Cluster
*
[LG03100( ALL)06/93]
The following warning lights and gauges are on
the mechanical cluster. All of the warning lights
and gauges alert you to possible problems with
your vehicle. Some of the lights listed are
optional. The following sections detail what each
of these indicators means.
*
[LG03200( ALL)03/95]
Brake System Warning Light
*
[LG03350( EF )06/92]
The red warning light for the brakes can show
three things Ð that either the parking brake is
not fully released, that the brake fluid level is
low in the master cylinder reservoir or the
vacuum pressure is low on diesel engine
vehicles. If the fluid level is low, the brake
system should be checked by a qualified service
technician.
*
[LG03400( ALL)05/94]
This light comes on when you turn the ignition
key to START to verify that the indicator bulb is
working. If the light stays on or comes on after
you have released the parking brake fully, have
the hydraulic brake system serviced.
*
[LG03500( ALL)05/95]
RWARNING
The BRAKE light indicates that the brakes
may not be working properly. Have the
brakes checked immediately.
*
[LG03600( ALL)11/89]
one inch art:0020044-A
Brake warning light symbols
File:ltlgf.ex
Update:Thu May 9 15:22:28 1996

67
*
[LG03800(BEF )02/95]
Anti-Lock Brake System Warning Light
*
[LG03925(BEF )03/03]
To check theamberABS brake warning light
turn the ignition key to ON. The ABS brake
warning light should glow momentarily.
*
[LG03950(BEF )06/94]
NOTE: If it does not glow momentarily, have
your vehicle's electrical system checked
immediately.
*
[LG03985(BEF )07/94]
NOTE: If the ABS brake warning light begins
to flash in a repeatable flash sequence,
check the rear anti-lock system
continuous power fuse and brake lights
for proper operation.
[LG04050(BEF )05/95]
one inch art:0020913-B
Anti-lock warning light symbol
*
[LG04100(BEF )05/95]
RWARNING
If the anti-lock brake system warning
light remains on or comes on while
driving, have the braking system checked
by a qualified service technician as soon
as possible.
*
[LG04125(BEF )05/95]
NOTE: If a fault occurs in the anti-lock
system, and the brake warning light is
not lit, the anti-lock system is disabled
but normal brake function remains
operational.
File:ltlgf.ex
Update:Thu May 9 15:22:28 1996

68
*
[LG04150(BEF )02/95]
Safety Belt Warning Light and Chime
*
[LG04301(BEF )03/95]
This warning light and chime remind you to
fasten your safety belt. The following conditions
will take place:
*
[LG04325(BEF )03/95]
q
If the safety belt is not buckled when the key
is turned to the ON position, the light comes
on for 1 to 2 minutes and the chime sounds
for 4 to 8 seconds.
*
[LG04351(BEF )02/95]
q
If the safety belt is buckled while the light is
on and the chime is sounding, both the light
and chime turn off.
*
[LG04365(BEF )05/95]
q
If the safety belt is buckled before the
ignition is turned to the ON position, neither
the light nor the chime will come on.
*
[LG04400( ALL)10/92]
one inch art:0020046-B
Safety belt warning light symbol
*
[LG04500( ALL)03/95]
Check Engine Warning Light
*
[LG04525( ALL)05/95]
The Powertrain On-Board Diagnostic II (OBD II)
system consists of the hardware and software
necessary to monitor the operation of the
powertrain. The OBD II system is designed to
check the function of the vehicle's powertrain
control system during normal operation. If an
emission problem is detected, the Check Engine
Warning Light (in the cluster) is turned on.
File:ltlgf.ex
Update:Thu May 9 15:22:28 1996

69
*
[LG04550( ALL)05/95]
one inch art:0020048-A
Check engine warning light symbol
*
[LG04575( ALL)05/95]
Modification or additions to the vehicle may
cause incorrect operation of the OBD II system.
Additions such as burglar alarms, cellular
phones, and CB radios must be carefully
installed. Do not install these devices by tapping
into or running wires close to powertrain control
system wires or components.
*
[LG04600( ALL)05/95]
The light comes on briefly when you turn the
ignition key toON, but it should turn off when
the engine starts. If the light does not come on
when you turn the ignition toONor if it comes
on and stays on when you are driving, have
your vehicle serviced as soon as possible. This
indicates a possible problem with one of the
vehicle's emission control systems. You do not
need to have your vehicle towed in.
*
[LG04625( ALL)05/95]
If the light turns on and off at one (1) second
intervals while you are driving the vehicle, it
means that the engine is misfiring. If this
condition persists, damage could occur to the
engine or catalytic convertor. Have your vehicle
serviced at the first opportunity. You do not
need to have your vehicle towed in.
*
[LG04650( ALL)05/95]
If the light turns on and off on rare occasions
while you are driving, it means that a
malfunction occurred and the condition corrected
itself.
File:ltlgf.ex
Update:Thu May 9 15:22:28 1996

72 [LG06320(B F )05/95]
one inch art:0000653-CSupplemental air bag readiness light
*
[LG06400( ALL)05/94]
Battery Voltage Gauge (Voltmeter)
*
[LG06601( ALL)05/94]
This gauge shows you the battery voltage when
the ignition key is in the ON position.
*
[LG06700( ALL)11/89]
If you are running electrical accessories (when
the engine is off, or idling at a low speed), the
pointer may move toward the lower end of the
normal band. If it stays outside the normal band
area, have your vehicle's electrical system
checked as soon as it is safely possible.
*
[LG06701( ALL)05/95]
If the battery is operating under cold weather
conditions, the pointer may indicate in the upper
range of the NORMAL band while the battery is
charging. If you are running electrical accessories
with the engine off or idling at a low speed, or
the battery is not fully charged, the pointer may
move toward the lower end of the NORMAL
band.
*
[LG06750( ALL)05/94]
If it stays outside the NORMAL band, have your
vehicle's electrical system checked as soon as it
is safely possible.
*
[LG06900(B F )03/93]
quarter page art:0020052-D
Battery voltage gauge
File:ltlgf.ex
Update:Thu May 9 15:22:28 1996

78
*
[LG13200(B F )05/95]
Tachometer (If equipped)
*
[LG13300(B F )05/95]
The tachometer will show you the engine's
speed measured in revolutions per minute
(RPM).
*
[LG13400(B F )05/95]
The tachometer may move slightly when the key
is placed in the ACC or ON position, with the
engine off. This is normal and does not affect
the performance of the tachometer when the
engine is running.
*
[LG13525(B F )05/95]
Some vehicles are equipped with an engine
speed (RPM) limiting device contained within
the Powertrain Control Module (PCM). The
purpose of this device is to maintain peak
engine speed (RPM) below a specified limit. This
feature is only evident on automatic transmission
vehicles when shifting manually (1, 2, D) and on
all manual transmission units. (Engine speed
limits may vary based on engine displacement).
*
[LG13550(B F )05/95]
If you are experiencing an ªengine cut-outº
condition at high speeds, it may be the result of
this limiting device. It is a normal condition and
can be avoided by reducing vehicle/engine
speed.
*
[LG13665(B F )05/95]
one third page art:0020869-C
Tachometer
File:ltlgf.ex
Update:Thu May 9 15:22:28 1996

81
*
[IP00500(BEF )01/95]
The Climate Control Systems
*
[IP00601(BEF )12/91]
Your vehicle is equipped with a control
assembly designed to handle either a
combination A/C-Heater System or a
Heater-Only System.
*
[IP00801(BEF )10/93]
Instrument Panel Registers
*
[IP00950(B F )04/95]
There are four registers in the instrument panel.
Each of these registers contain a louver assembly
which can be manually adjusted to direct airflow
up, down, left, right, and positive shut-off. An
illustration of the register locations follows.
*
[IP01300(B F )03/93]
quarter page art:0020101-C
Instrument panel registers
*
[IP01400(B F )02/95]
Air Conditioner and Heater (If equipped)
*
[IP01450(B F )02/95]
The control for your air conditioning and heater
system is located at the center of the instrument
panel below the radio and will operate only
when the ignition key is turned to the ON
position. Your air conditioner and heater will
heat and/or cool your vehicle interior depending
on the function position and temperature you
select. The function selector control knob allows
you to select heating or cooling and determine
where the air will be directed. The temperature
control knob setting determines the temperature
of the air that flows into the vehicle.
File:ltipf.ex
Update:Thu May 9 15:21:29 1996
