NOTE: Use of a transmission fluid other than
specified could result in transmission
malfunction and/or failure. Refer to
ªAdding automatic transmission fluidº,
ªRefill capacitiesº and ªlubricant
specificationsº for further information.
%*
[SV33651( ALL)02/95]
Checking the Automatic Transmission
Fluid
*
[SV33701( ALL)02/95]
It is preferable to check the transmission fluid
level at normal operating temperature
150ÊF-170ÊF (66ÊC-77ÊC),after approximately 20
miles (32 km) of driving. However, if necessary,
you can check the fluid level without having to
drive 20 miles (32 km) to obtain a normal
operating temperature if outside temperatures
are above50ÊF (10ÊC).
*
[SV33801( ALL)01/95]
NOTE: If the vehicle has been operated for an
extended period at high speeds or in
city traffic during hot weather, or
pulling a trailer, the vehicle should be
turned off for about 30 minutes to
allow the fluid to cool before checking.
*
[SV33910( ALL)12/91]
With the vehicle on a level surface, start the
engine and move the transmission shift selector
through all of the gear ranges allowing sufficient
time for each position to engage. Securely latch
the transmission shift selector in the Park (P)
position, fully set the parking brake and leave
the engine running.
*
[SV33920(B F )06/94]
NOTE: Vehicles equipped with the 4x4 option
must have the 4x4 shift selector in any
position other than neutral.
File:ltsvf.ex
Update:Thu May 9 15:30:19 1996

348
*
[SV35000(B F )03/91]
2. Replace the filler plug in its original
position, making sure it is fully seated.
%
*
[SV35100(B F )02/95]
The Clutch
*
[SV35200(B F )03/91]
The clutch on your vehicle is automatically
self-adjusting and should not require any routine
service.
*
[SV35301(B F )03/91]
During normal operation the fluid level in the
clutch reservoir will slowly rise. If for any
reason the fluid level drops, maintain the fluid
level at the step in the reservoir body.
%*
[SV35400(B F )03/94]
If it becomes necessary to remove the reservoir
cap, thoroughly clean the reservoir cap before
removing it to prevent dirt or water from
entering the reservoir. Remove the internal
diaphragm and then add only a DOT 3 brake
fluid such as Ford High Performance DOT 3
Brake Fluid, meeting Ford specification
ESA-M6C25-A.
*
[SV35600(B F )03/90]
one third page art:0020377-A
Clutch fluid reservoir
File:ltsvf.ex
Update:Thu May 9 15:30:19 1996

349
*
[SV35800( ALL)03/91]
Driveline Universal Joint and
Slip Yoke
*
[SV36000(BEF )06/93]
The universal joints that come standard with
your vehicle do not require lubrication. If your
original equipment universal joints are replaced
with universal joints equipped with grease
fittings, lubrication will be necessary at the
intervals shown in theMaintenance Schedule and
Recordbooklet.
*
[SV36100(B F )06/93]
Your vehicle may be equipped with a constant
velocity or double cardan joint at the transfer
case end of the driveshaft. The front driveshaft
double cardan joint may be fitted with a flush
type grease fitting that requires an adapter to
permit proper lubrication. Lubricate the drive
joint according to the intervals shown in the
Maintenance Schedule and Recordbooklet.
*
[SV36200(B F )05/90]
quarter page art:0020379-A
Double cardan joint
*
[SV36300( ALL)03/95]
Brake Fluid
*
[SV36350( ALL)05/90]
Your vehicle is equipped with a brake fluid level
indicator in the master cylinder which lights the
BRAKE warning light on the instrument panel
when the brake fluid level is low.
*
[SV36400( ALL)04/95]
Under normal circumstances, your vehicle
should not use up brake fluid rapidly. However,
expect the level of the brake fluid to slowly fall
as you put more mileage on your vehicle and
the brake lining wears.
File:ltsvf.ex
Update:Thu May 9 15:30:19 1996

350
*
[SV36500( ALL)10/89]
Check the brake fluid at least once a year. You
can do this by looking at the fluid level in the
plastic reservoir on the master cylinder. The
fluid level should be at or near the MAX mark.
*
[SV36550( ALL)05/95]
RWARNING
Brake fluid is toxic.
*
[SV36560( ALL)05/95]
If brake fluid contacts eyes, flush eyes with
running water for 15 minutes. Get medical
attention if irritation persists. If taken internally,
drink water and induce vomiting. Get medical
attention immediately.
*
[SV36600( ALL)02/95]
If the fluid is low, carefully clean and remove
the filler cap from the reservoir. Fill the
reservoir to the MAX line with Ford High
Performance DOT 3 Brake Fluid C6AZ-19542-AA
or DOT 3 equivalent fluid meeting Ford
specification ESA-M6C25-A.
*
[SV36850( ALL)12/91]
NOTE: If brake fluid is spilled on painted
surfaces, it must be flushed and wiped
away immediately. Brake fluid may
dissolve the paint finish on your
vehicle.
*
[SV36900( ALL)01/95]
RWARNING
If you use a brake fluid that is not DOT
3, you will cause permanent damage to
your brakes.
*
[SV37000( ALL)01/95]
Do not fill the reservoir above the MAX line.
*
[SV37100( ALL)01/95]
If you find that the fluid level is excessively low
Ð below the seam or ridge on the outside of the
plastic reservoir Ð have the brake system
inspected.
File:ltsvf.ex
Update:Thu May 9 15:30:19 1996

351
*
[SV37200( ALL)01/95]
RWARNING
Do not let the reservoir for the master
cylinder run dry. This may cause the
brakes to fail.
*
[SV37400(BEF )01/89]
quarter page art:0020381-A
Brake master cylinder
*
[SV37600( ALL)03/95]
Power Steering Fluid
*
[SV37700( ALL)01/95]
Check the level of the power steering fluid at
least twice a year (i.e., every Spring and Fall).
*
[SV37800( ALL)03/95]
To check the level of your power steering fluid:
*
[SV37900( ALL)02/95]
1. Start the engine and let it run until the
power steering fluid reaches normal
operating temperature. The power steering
fluid will be at the right temperature when
the engine coolant temperature gauge in the
instrument cluster is near the center of the
NORMAL operating temperature range.
*
[SV38000( ALL)01/95]
2. While the engine idles, turn the steering
wheel back and forth several times. Make
sure that the cap assembly is installed at this
time.
*
[SV38100(BEF )05/95]
3. Turn the engine off.
File:ltsvf.ex
Update:Thu May 9 15:30:19 1996
