1996 FORD F SERIES MOTORHOME AND COMMERCIAL CHASSIS sensor

31 [LG12375( E M)03/93]
quarter page art:0020687-C
Engine coolant temperature gauge
*
[LG12601( ALL)01/95]
Speedometer
*
[LG12700( ALL)01/95]
The speedometer tells you how many miles
(kilometers) per hour your vehicle is moving.
[LG12751( M)05/95]
Your vehicle contains a speedometer which
receives its input from a speed sensor. The
speedometer is also used to provide a speed
signal for correct operation of the vehicle's
Electronic Engine Control (EEC) module,
electronic transmission, and speed control
(if so equipped).
File:ltlgm.ex
Update:Tue Jun 20 16:47:10 1995

47
Driving Your Motorhome
% [DR08700( M)03/93]
Automatic Transmission
Operation (E4OD)
[DR08712( M)03/94]
The E4OD transmission is an electronically
controlled four speed automatic transmission
with overdrive. Transmission operation is
controlled by the Powertrain Control Module
(PCM).
*
[DR08720( ALL)08/94]
The PCM will automatically adjust transmission
operation to make up for varying conditions.
Several sensors located on the engine and
transmission such as Throttle Position, Engine
Speed, Vehicle Speed and Transmission
Temperature are used by the PCM to shift the
transmission into a higher or lower gear when
required for the best performance and fuel
economy. For example, you may notice that the
transmission will upshift to a higher gear more
quickly when the vehicle is first driven and has
not reached normal operating temperature.
*
[DR08730( ALL)07/94]
The PCM also controls the transmission's Torque
Converter Clutch to further raise vehicle
performance and fuel economy. The Torque
Converter Clutch will engage when the
transmission operating temperature and other
conditions determined by the PCM have been
met. Engagement of the clutch may be noted as
a decrease in engine speed after an upshift has
completed or when the driver has depressed the
throttle while driving at a steady road speed.
File:ltdrm.ex
Update:Tue Jun 20 16:46:11 1995

54
*
[DR15985( ALL)05/90]
NOTE: After any severe impact such as
striking large potholes, sliding into
curbs on icy roads, or a collision
involving the front end, observe the
steering wheel alignment. If the spokes
of the steering wheel seem to be in a
different position while going straight
down the road, have the front
suspension and steering checked for
possible damage.
*
[DR21400( ALL)03/95]
Brakes
[DR21410( M)06/90]
Your vehicle is equipped with the following
features:
[DR21420( M)06/90]
q
Front self-adjusting disc brakes.
[DR21430( M)06/90]
q
Rear self-adjusting disc brakes.
[DR21440( M)06/90]
q
Independent front and rear hydraulic brake
circuits with a common fluid reservoir and
fluid level sensor in the master cylinder.
[DR21450( M)06/90]
q
Hydro boost.
[DR21460( M)06/90]
q
Parking brake.
*
[DR21500( ALL)01/93]
Front Disc Brakes
*
[DR21600( ALL)03/94]
The front disc brakes are self-adjusting. They do
not require service other than periodic
lubrication of caliper slide rails and inspection
for pad wear.
*
[DR22035( M)07/93]
Rear Disc Brakes
*
[DR22050( EFM)04/95]
The rear disc brakes are self-adjusting. They do
not require service other than periodic
lubrication of the caliper slide rails and
inspection for pad wear.
File:ltdrm.ex
Update:Tue Jun 20 16:46:11 1995

55
*
[DR22100( ALL)11/89]
Hydraulic Power Brakes
[DR22250( M)06/90]
The hydraulic brake system is made up of two
independent hydraulic circuits. One hydraulic
circuit supplies fluid to the front disc brakes and
the other hydraulic circuit supplies fluid to the
rear disc brakes. These two circuits are supplied
by a common hydraulic brake fluid reservoir,
with a fluid level sensor.
*
[DR22300( ALL)11/89]
The brake light in the instrument cluster will
light for low brake fluid in the common brake
fluid reservoir.
*
[DR22400( ALL)05/95]
RWARNING
An increase in pedal travel will result in
reduced braking capability. The brake
system should be checked immediately.
[DR22430( E M)04/95]
Hydraulic Brake Booster System
(Hydro Boost)
[DR22460( E M)04/95]
The Hydro Boost system receives its source of
power from the power steering system pump.
%*
[DR23000(BE M)12/89]
If Brakes Do Not Grip Well or Pedal is
ªLowº
*
[DR23250( ALL)11/89]
If during normal operation the brake pedal
seems ªlowº, it may indicate the need for a
brake system inspection and/or service. You
should have your brakes checked as soon as
possible.
*
[DR23300( ALL)02/95]
Occasional brake squeal during light to moderate
stops does not affect the function of the brake
system and is normal. However, if the squeal
becomes annoyingly loud or increases
significantly in frequency of occurrence, return
the vehicle to your dealer for inspection.
File:ltdrm.ex
Update:Tue Jun 20 16:46:11 1995
