1996 FORD ASPIRE engine coolant

195
*
[SV21400(ALL)02/95]
Engine coolant refill procedure
*
[SV21500(ALL)03/95]
When the entire engine cooling system is to be
drained and refilled, use the following
procedure:
*
[SV21600(ALL)01/89]
1. Remove the radiator cap.
*
[SV21700(ALL)06/89]
2. With the engine off and cool, add a 50/50
mixture of recommended engine cooling
system fluid and water until the radiator is
full.
*
[SV21800(ALL)07/93]
3. Replace and fully tighten the radiator cap,
then unscrew the cap to the first stop.
*
[SV21900(ALL)06/89]
4. Start and idle the engine until the radiator
upper hose is warm (this indicates the
thermostat is open and engine coolant is
flowing through the entire system).
[SV22000(ALL)03/94]
5. When you are done, stop the engine and
tighten the cap completely.
%*
[SV22100(ALL)11/94]
Checking hoses
*
[SV22200(ALL)01/89]
Check all engine and heater system hoses and
hose connections for deterioration, leaks, and
loose hose clamps as specified in the
maintenance schedule. Repair or replace with
Motorcraft hoses or equivalent as necessary.
*
[SV22300(ALL)03/95]
Windshield Washer Fluid and
Wipers
*
[SV22350(ALL)03/95]
Washer Fluid
*
[SV22500(ALL)01/95]
Check the level of the windshield washer fluid
every time you stop for fuel. The reservoir for
the windshield washer fluid is located in the
engine compartment.
[SV22600(ALL)05/93]
To check the washer fluid level, place your
finger over the hole in the reservoir cap and pull
out the dipstick.
File:15icsvf.ex
Update:Wed Jan 24 14:56:41 1996

196 % [SV22800(ALL)07/95]
two third page art:0032217-CFront windshield washer fluid reservoir
*
[SV23000(ALL)05/95]
RWARNING
Do not put windshield washer fluid in the
container for the engine coolant.
%*
[SV23100(ALL)01/95]
Use specially formulated windshield washer
fluid rather than plain water, because specially
formulated washer fluids contain additives that
dissolve road grime. For safety reasons, washer
fluids containing an appropriate antifreeze such
as methanol should be used in freezing weather
(temperatures below32ÊF [0ÊC]).State or local
regulations on Volatile Organic Compounds
File:15icsvf.ex
Update:Wed Jan 24 14:56:41 1996

214
*
[SV32700(ALL)01/95]
RWARNING
Do not let the reservoir for the master
cylinder run dry. This may cause the
brakes to fail.
*
[SV32800(ALL)03/95]
Power Steering Fluid
*
[SV32900(ALL)01/95]
Check the level of the power steering fluid at
least twice a year (i.e., every Spring and Fall).
*
[SV33000(ALL)03/95]
Checking and Adding Power Steering
Fluid
*
[SV33100(ALL)02/95]
1. Start the engine and let it run until the
power steering fluid reaches normal
operating temperature. The power steering
fluid will be at the right temperature when
the engine coolant temperature gauge in the
instrument cluster is near the center of the
NORMAL operating temperature range.
*
[SV33200(ALL)01/95]
2. While the engine idles, turn the steering
wheel back and forth several times. Make
sure that the cap assembly is installed at this
time.
*
[SV33300(ALL)05/95]
3. Turn the engine off.
[SV33400(ALL)07/93]
4. Check the fluid level on the reservoir. The
fluid level should be at the F (Full) line on
the reservoir.
