01-9
VAS 5051 vehicle diagnostic, testing
and information system orVAG1551
Scan Tool (ST), connecting and
selecting functions
Test requirements:
Fuses for engine electronics OK
Electrical Wiring Diagrams, Troubleshooting &
Component Locations binder
Fuel Pump (FP) OK, checking Page 24
-
49
.
Battery voltage at least 12.7 V
Ground (GND) connections at engine and
transmission OK
Procedure
Note: - Connect VAS5051 tester to vehicle with VAS5051/1 diagnostic wire.
Alternately, VAG1551 Scan Tool (ST) can also be attached using
VAG1551/3B cable.
