GAUGES, METERS AND SERVICE REMINDER INDICATORS
30
CAUTION
It is dangerous to continue driving normally when the
brake fluid level is low.
If the brake fluid level is correct ...
Have the warning system checked by your Lexus dealer.
(b) Brake Pad Wear Limit Warning Light
This light warns that the brake pads are worn to the extent that
replacement is required. If it comes on while you are driving,
have the brake pads checked and replaced by your Lexus
dealer as soon as possible.
(c) Seat Belt Reminder Light and Buzzer
Once the ignition key is turned to “ON” or “START”, the
reminder light and buzzer come on if the driver’s seat belt is not
fastened. Unless the driver fastens the belt, the light stays on
and the buzzer stops after about 4 to 8 seconds.
(d) SRS Airbag Warning Light
This indicator comes on when the ignition key is turned to
the “ACC” or “ON” position. It goes off after about 6
seconds. This means the SRS airbags are operating
properly.
The SRS airbag warning light system monitors the airbag
sensor assembly, inflators, warning light, interconnecting
wiring and power sources.
If either of the following conditions occurs, this indicates a
malfunction somewhere in the parts monitored by the warning
light system. Contact your Lexus dealer as soon as possible
to service the vehicle.
The light does not come on as described above or remains
on.
The light comes on while driving.
(e) Discharge Warning Light
This light warns that the battery is being discharged.
If it comes on while you are driving, stop the vehicle, turn off the
engine, and check for the cause. Look first at the engine drive
belt.
If it is loose or broken, the generator will not charge the
battery properly.
If the bolt is O.K., there is a problem somewhere in the
charging system.
