1994 TOYOTA CAMRY key

158
POWER WINDOW
WHEN THE IGNITION SW IS TURNED ON, CURRENT FLOWS THROUGH THE GAUGE FUSE TO TERMINAL 1 OF THE POWER MAIN
RELAY " TERMINAL 2 " TO GROUND. THIS ACTIVATES THE RELAY AND THE CURRENT FLOWING TO TERMINAL 5 OF THE RELAY
FROM POWER FUSE FLOWS TO TERMINAL 3 OF THE RELAY " TERMINAL 7 OR 8 (EX. C/P), 9 (C/P) OF THE POWER WINDOW
MASTER SW " TO TERMINAL 5 OF THE POWER WINDOW SW.
1. MANUAL OPERATION (DRIVER'S WINDOW)
WITH THE IGNITION SW TURNED ON AND WITH THE POWER WINDOW MASTER SW (MANUAL SW) IN UP POSITION. THE CURRENT
FLOWING TO TERMINAL 7 OR 8 (EX. C/P), 9 (C/P) OF THE POWER WINDOW MASTER SW FLOWS TO TERMINAL 6 (EX. C/P), 3 (C/P) OF
THE MASTER SW " TEMINAL 2 OF THE POWER WINDOW MOTOR " TERMINAL 1 " TERMINAL 13 (EX. C/P), 4 (C/P) OF THE MASTER
SW " TERMINAL 2 OR 1 (EX. C/P), 6 (C/P) " TO GROUND AND CAUSES THE POWER WINDOW MOTOR TO ROTATE IN THE UP
DIRECTION. THE WINDOW ASCENDS ONLY WHILE THE SW IS BEING PUSHED. IN DOWN OPERATION, THE FLOW OF CURRENT
FROM TERMINAL 7 OR 8 (EX. C/P), 9 (C/P) OF THE POWER WINDOW MASTER SW TO TERMINAL 13 (EX. C/P), 4 (C/P) OF THE MASTER
SW CAUSES THE FLOW OF CURRENT FROM TERMINAL 1 OF THE MOTOR " TERMINAL 2 " TERMINAL 6 (EX. C/P), 3 (C/P) OF THE
MASTER SW " TERMINAL 2 OR 1 (EX. C/P), 3 (C/P) " TO GROUND, FLOWING IN THE OPPOSITE DIRECTION TO MANUAL UP
OPERATION AND CAUSING THE MOTOR TO ROTATE IN REVERSE LOWERING THE WINDOW.
2. AUTO DOWN OPERATION
WITH THE IGNITION SW ON AND WITH THE AUTO SW OF THE POWER WINDOW MASTER SW IN DOWN POSITION, CURRENT
FLOWING TO TERMINAL 7 OR 8 OF THE MASTER SW FLOWS TO TERMINAL 13 (EX, C/P), 4 (C/P) OF THE MASTER SW " TERMINAL 1
OF THE POWER WINDOW MOTOR " TERMINAL 2 " TERMINAL 6 (EX. C/P), 3 (C/P) OF THE MASTER SW " TERMINAL 2 (EX. C/P), 6
(C/P) " TO GROUND, CAUSING THE MOTOR TO ROTATE TOWARDS THE DOWN SIDE THEN THE SOLENOID IN THE MASTER SW IS
ACTIVATED AND IT LOCKS THE AUTO SW BEING PUSHED, CAUSING THE MOTOR TO CONTINUE TO ROTATE IN AUTO DOWN
OPERATION. WHEN THE WINDOW HAS COMPLETELY DESENDED, THE CURRENT FLOW BETWEEN TERMINAL 6 (EX. C/P), 3 (C/P) OF
THE MASTER SW AND TERMINAL 2 (EX. C/P), 6 (C/P) INCREASES. AS A RESULT, THE SOLENOID STOPS OPERATING, THE AUTO SW
TURNS OFF AND FLOW FROM TERMINAL 7 (EX. C/P), 9 (C/P) OF THE MASTER SW TO TERMINAL 13 (EX. C/P), 4 (C/P) IS CUT OFF,
STOPPING THE MOTOR SO THAT AUTO STOP OCCURS.
3. STOPPING OF AUTO DOWN AT DRIVER'S WINDOW
HEN THE MANUAL SW (DRIVER'S) IS PUSHED TO THE UP SIDE DURING AUTO DOWN OPERATION, A GROUND CIRCUIT OPENS IN
THE MASTER SW AND CURRENT DOES NOT FLOW FROM TERMINAL 6 (EX. C/P), 3 (C/P) OF THE MASTER SW " TO GROUND, SO
THE MOTOR STOPS, CAUSING AUTO DOWN OPERATION TO STOP. IF THE MASTER SW IS PUSHED CONTINUOUSLY, THE MOTOR
ROTATES IN THE UP DIRECTION IN MANUAL UP OPERATION.
4. MANUAL OPERATION BY POWER WINDOW SW (PASSENGER'S WINDOW)
WITH POWER WINDOW SW (PASSENGER'S) PULLED TO THE UP SIDE, CURRENT FLOWING FROM TERMINAL 5 OF THE POWER
WINDOW SW FLOWS TO TERMINAL 1 OF THE POWER WINDOW SW " TERMINAL 2 OF THE POWER WINDOW MOTOR " TERMINAL
1 " TERMINAL 4 OF THE POWER WINDOW SW " TERMINAL 3 " TERMINAL 5 (EX. C/P), 7 (C/P) OF THE MASTER SW " TERMINAL 1
OR 2 (EX. C/P), 6 (C/P) " TO GROUND AND CAUSES THE POWER WINDOW MOTOR (PASSENGER'S) TO ROTATE IN THE UP
DIRECTION. UP OPERATION CONTINUES ONLY WHILE THE POWER WINDOW SW IS PULLED TO THE UP SIDE. WHEN THE WINDOW
DECENDS, THE CURRENT FLOWING TO THE MOTOR FLOWS IN THE OPPOSITE DIRECTION, FROM TERMINAL 1 TO TERMINAL 2,
AND THE MOTOR ROTATES IN REVERSE. WHEN THE WINDOW LOCK SW IS PUSHED TO THE LOCK SIDE, THE GROUND CIRCUIT TO
THE PASSENGER'S WINDOW BECOMES OPEN. AS A RESULT, EVEN IF OPEN/CLOSE OPERATION OF THE PASSENGER'S WINDOW IS
TRIED, THE CURRENT FROM TERMINAL 1 OR 2 (EX. C/P), 6 (C/P) OF THE POWER WINDOW MASTER SW IS NOT GROUNDED AND
THE MOTOR DOES NOT ROTATE, SO THE PASSENGER'S WINDOW CAN NOT BE OPERATED AND WINDOW LOCK OCCURS.
FURTHERMORE REAR LH RH WINDOW OPERATE THE SAME AS THE ABOVE CIRCUIT.
5. KEY OFF POWER WINDOW OPERATION
WITH IGNITION SW TURNED FROM ON TO OFF DOOR LOCK CONTROL RELAY OPERATES AND CURRENT FLOWS FROM POWER
FUSE TO TERMINAL 8 OF THE RELAY " TERMINAL 15 " TERMINAL 1 OF POWER MAIN RELAY " TERMINAL 2 " TO GROUND FOR
ABOUT 60 SECOND. THE SAME AS NORMAL OPERATION, THE CURRENT FLOWS FROM POWER FUSE " TERMINAL 5 OF THE
POWER MAIN RELAY " TERMINAL 3 " TERMINAL 7 OR 8 (EX. C/P), TERMINAL 9 (C/P) OF THE POWER WINDOW MASTER SW AND
TERMINAL 3 OF THE POWER MAIN RELAY " TO TERMINAL 5 OF THE POWER WINDOW SW. AS A RESULT, FOR ABOUT 60 SECOND
AFTER THE IGNITION SW IS TURNED OFF, THE FUNCTIONING OF THIS RELAY MAKES IT POSSIBLE TO RAISE AND LOWER THE
POWER WINDOW. ALSO, BY OPENING THE FRONT DOOR (DOOR OPEN DETECTION SW ON) WITHIN ABOUT 60 SECOND AFTER
TURNING THE IGNITION SW TO OFF, A SIGNAL IS INPUT TO DOOR LOCK CONTROL RELAY. AS A RESULT, THE RELAY TURNS OFF
AND UP AND DOWN MOVEMENT OF THE POWER WINDOW STOPS.
SYSTEM OUTLINE

161
*
5 : W/O POWER WINDOW * 4 : W/ POWER WINDOW, C/P
*
3 : W/ POWER WINDOW *2 : C/P
*
1:S/D,W/G
I22
I22
IU1 5IU115
BY1 8 BY1 3IH2 14 IH219 IH29
IF MM
IT119
IH216 L±B
L±R
W± B W±B W±B
L±R
L±B
L±RL±B L±R L±R
L±B L±R
L±B
L±R
L±B
L±R W±B W±B
JUNCTION
CONNECTOR
DOOR LOCK MOTOR
RE AR RH
DOOR LOCK MOTOR AND
DOOR UNLOCK DETECTION SW
FRONT LH
6
B B 42
B2 13IH2 3 IH2 13 IH210
IH2 4 SEQURITY CONTROL
CIRCUIT
9
G
LGL
L
L±WL W±B
W±B
W±B
W±BL
G
LG
W±B
DOOR LOCK
CONTROL SW LH
DOOR KEY LOCK AND
UNLOCK SW LH
DOOR LOCK
CONTROL RELAY D8
D17 D23
J2
W±B
L±B
L±R L±R3
L±B
W±BL±W
UNLOCK
LOCK
W±B
B2:*3
B1:*4
B18 : * 5
B 1 : EX. C/P
B18 : C/PB2:*3
B1:*4
B18 : * 5 2 A 1
B 6
C 3 A 1
B 4 A 4B 7
A 2B 5
A 3B 6
A 3B 1C 1
A 4B 2C 5
A 8B 9
A (
*2)
(
*1)(
*
5)
(
*4)
(
*3)
(
*3)
(
*4)
(
*5) (
*2)
(
*1)
(
*1) (
*
1)
(
*1) (
*1) (
*1) (
*
1)(
*
1)
B P12 ,AC, D20 , D26
AB

162
DOOR LOCK* 2 : W/O POWER WINDOW EX. C/P *
1 : W/ POWER WINDOW EX. C/P
R±L L±R
JUNCTION
CONNECTOR
1 C
C
2 131 1
5 1
IG IT1 2IT11IT112 IT15IU1 6 II2 6 II2 19
I22I22
I22 13 12 11 10 7 2 14
LG±R
L±W
G
LG
R±L
R±G
R±WR±WR±L R±L
R±G
R±W LGG L±W LG±R
W±B
W±B
W±B W±B
W±BLG
LG
L±W
DOOR KEY LOCK AND
UNLOCK SW RH
L±W
DOOR LOCK
CONTROL S W RH
UNLOCK WA RNING SW
[IGNITION SW]
DOOR COURTESY SW
FRONT LH
DOOR COURTESY SW
FRONT RHLGG
DOOR LOCK
CONTROL RELAY D8
D13 D12 I12 D18
FROM POWER SOURCE SYSTEM(
SEE PAGE 64)
J3
LG
L±WG
LOCK UNLOCKLOCK UNLOCK
II2 4
R±L
B11 : EX. C/P
B27 : C/P
B D19 ,A
A 2A3 B 1B5
A 4
B 3(
*2)
(
*2)(
*1)
(
*1)
1K 810A
GAUGE
1G 21H21K 9 1K 14
1M 11G 4

163
CURRENT ALWAYS FLOWS TO TERMINAL 8 OF THE DOOR LOCK CONTROL RELAY THROUGH THE POWER FUSE.
WHEN THE IGNITION SW IS TURNED ON, THE CURRENT FLOWING THROUGH THE GAUGE FUSE FLOWS THROUGH THE COIL SIDE
OF THE POWER MAIN RELAY TO GROUND, CAUSING THE RELAY TO OPERATE. THE CURRENT FLOWING THROUGH THE POWER
FUSE FLOWS TO THE LH DOOR LOCK CONTROL SW, CAUSING THE INDICATOR LIGHT TO LIGHT UP.
1. MANUAL LOCK OPERATION
WHEN THE DOOR LOCK CONTROL SW AND KEY SW ARE PUSHED TO LOCK POSITION, A LOCK SIGNAL IS INPUT TO TERMINAL 10,
12 OF THE DOOR LOCK CONTROL RELAY AND CAUSES THE RELAY TO FUNCTION. CURRENT FLOWS FROM TERMINAL 8 OF THE
RELAY " TERMINAL 4 " TERMINAL 4 OF THE DOOR LOCK MOTORS, (EX. C/P FRONT DOOR) OR TERMINAL 7 (C/P FRONT DOOR),
OF THE DOOR LOCK MOTOR TERMINAL 2 OF THE BACK DOOR LOCK MOTOR " TERMINAL 2 OF THE DOOR LOCK MOTORS, (EX.
C/P FRONT DOOR) OR TERMINAL 5 (C/P FRONT DOOR) OF THE DOOR LOCK MOTOR TERMINAL 1 OF THE BACK DOOR LOCK
MOTOR " TERMINAL 3 OF THE RELAY " TERMINAL 16 " TO GROUND AND THE DOOR LOCK MOTOR CAUSES THE DOOR TO
LOCK.
2. MANUAL UNLOCK OPERATION
WHEN THE DOOR LOCK CONTROL SW AND KEY SW RH TO UNLOCK POSITION, AN UNLOCK SIGNAL IS INPUT TO TERMINAL 11, 13
OF THE DOOR LOCK RELAY AND CAUSES THE RELAY TO FUNCTION. CURRENT FLOWS FROM TERMINAL 8 OF THE RELAY "
TERMINAL 3 " TERMINAL 2 OF THE DOOR LOCK MOTORS, (EX. C/P FRONT DOOR) OR TERMINAL 5 (C/P FRONT DOOR) OF THE
DOOR LOCK MOTOR TERMINAL 1 OF THE BACK DOOR LOCK MOTOR " TERMINAL 4 OF THE DOOR LOCK MOTORS, (EX. C/P
FRONT DOOR) OR TERMINAL 7 (C/P FRONT DOOR), OF THE DOOR LOCK MOTOR TERMINAL 2 OF THE BACK DOOR LOCK MOTOR "
TERMINAL 4 OF THE RELAY " TERMINAL 16 " TO GROUND AND DOOR LOCK MOTORS CAUSES DOOR TO UNLOCK.
3. DOUBLE OPERATION UNLOCK OPERATION
WHEN THE DOOR LOCK KEY SW (DRIVER'S) IS TURNED TO THE UNLOCK SIDE, ONLY THE DRIVER'S DOOR IS MECHANICALLY
UNLOCKED. TURNING THE DOOR LOCK KEY SW (DRIVER'S) TO THE UNLOCK SIDE CAUSES A SIGNAL TO BE INPUT TO TERMINAL 9
OF THE RELAY, AND IF THE SIGNAL IS INPUT AGAIN WITHIN 3 SECONDS BY TURNING THE SW TO THE UNLOCK SIDE AGAIN,
CURRENT FLOWS TERMINAL 3 " TERMINAL 2 OF DOOR LOCK MOTORS, (EX. C/P FRONT DOOR) OR TERMINAL 5 (C/P FRONT
DOOR) OF THE DOOR LOCK MOTOR TERMINAL 1 OF THE BACK DOOR LOCK MOTOR " TERMINAL 4 OF THE DOOR LOCK MOTORS,
(EX. C/P FRONT DOOR) OR TERMINAL 7 (C/P FRONT DOOR), OF THE DOOR LOCK MOTOR TERMINAL 2 OF THE BACK DOOR LOCK
MOTOR " TERMINAL 4 OF THE RELAY " TERMINAL 16 " GROUND, CAUSING THE DOOR LOCK MOTORS TO OPERATE AND
UNLOCK THE DOORS.
4. IGNITION KEY REMINDER OPERATION
*OPERATING DOOR LOCK KNOB (OPERATION OF DOOR LOCK MOTORS)
WITH IGNITION KEY IN CYLINDER (UNLOCK WARNING SW ON), WHEN THE DOOR IS OPENED AND LOCKED USING DOOR LOCK
KNOB (DOOR LOCK MOTOR), THE DOOR IS LOCKED ONCE BUT EACH DOOR IS UNLOCKED SOON BY THE FUNCTION OF RELAY.
AS A RESULT, THE CURRENT FLOWS FROM TERMINAL 8 OF THE RELAY " TERMINAL 3 " TERMINAL 2 OF THE DOOR LOCK
MOTORS, (EX. C/P FRONT DOOR) OR TERMINAL 5 (C/P FRONT DOOR) OF THE DOOR LOCK MOTOR TERMINAL 2 OF THE BACK
DOOR LOCK MOTOR " TERMINAL 4 OF THE DOOR LOCK MOTORS, (EX. C/P FRONT DOOR) OR TERMINAL 7 (C/P FRONT DOOR),
OF THE DOOR LOCK MOTOR TERMINAL 1 OF THE BACK DOOR LOCK MOTOR " TERMINAL 4 OF THE RELAY " TERMINAL 16 "
TO GROUND AND CAUSES ALL THE DOORS TO UNLOCK.
*OPERATING DOOR LOCK CONTROL SW OR DOOR LOCK KEY SW
WITH IGNITION KEY IN CYLINDER (UNLOCK WARNING SW ON), WHEN THE DOOR IS OPENED AND LOCKED USING DOOR LOCK
CONTROL SW OR KEY SW, THE DOOR IS LOCKED ONCE BUT EACH DOOR IS UNLOCK BY THE FUNCTION OF SW CONTAINED IN
MOTORS, WHICH THE SIGNAL IS INPUT TO TERMINAL 6 (DRIVER'S) OR 5 (PASSENGER'S) OF THE RELAY. ACCORDING TO THIS
INPUT SIGNAL, THE CURRENT IN ECU FLOWS FROM TERMINAL 8 OF THE RELAY " TERMINAL 3 " TERMINAL 2 OF THE DOOR
LOCK MOTORS, (EX. C/P FRONT DOOR) OR TERMINAL 5 (C/P FRONT DOOR) OF THE DOOR LOCK MOTOR TERMINAL 2 OF THE
BACK DOOR LOCK MOTOR " TERMINAL 4 OF THE DOOR LOCK MOTORS, TERMINAL 1 OF THE BACK DOOR LOCK MOTOR "
TERMINAL 4 OF THE RELAY " TERMINAL 16 " TO GROUND AND CAUSES ALL THE DOOR TO UNLOCK.
*IN CASE OF KEY LESS LOCK
WITH IGNITION KEY IN CYLINDER (UNLOCK WARNING SW ON), WHEN THE UNLOCK FUNCTION IS DISTURBED MORE THAN 0.2
SECONDS, FOR EXAMPLE PUSHING THE DOOR LOCK KNOB ETC., THE DOOR HOLDS ON LOCK CONDITION. CLOSING THE DOOR
AFTER, DOOR COURTESY SW INPUTS THE SIGNAL INTO TERMINAL 2 OR 14 OF THE RELAY. BY THIS INPUT SIGNAL, THE ECU
WORKS AND CURRENT FLOWS FROM TERMINAL 8 OF THE RELAY " TERMINAL 3 " TERMINAL 2 OF THE DOOR LOCK MOTORS,
(EX. C/P FRONT DOOR) OR TERMINAL 5 (C/P FRONT DOOR) OF THE DOOR LOCK MOTOR TERMINAL 1 OF THE BACK DOOR LOCK
MOTOR " TERMINAL 4 OF THE DOOR LOCK MOTORS, (EX. C/P FRONT DOOR) OR TERMINAL 7 (C/P FRONT DOOR), OF THE
DOOR LOCK MOTOR TERMINAL 2 OF THE BACK DOOR LOCK MOTOR " TERMINAL 4 OF THE RELAY " TERMINAL 16 " TO
GROUND AND CAUSES ALL THE DOORS TO UNLOCK.
SYSTEM OUTLINE

164
DOOR LOCK
D8 DOOR LOCK CONTROL RELAY
16±GROUND : ALWAYS CONTINUITY
2±GROUND : CONTINUITY WITH DRIVER'S DOOR OPEN
8±GROUND : ALWAYS APPROX. 12 VOLTS
3±GROUND : APPROX. 12 VOLTS 0.2 SECONDS WITH FOLLOWING OPERATION
*DOOR LOCK CONTROL SW UNLOCKED
*DOOR LOCK CONTROL SW LOCKED WITH IGNITION KEY IN CYLINDER AND DRIVER'S DOOR OPEN
(IGNITION KEY REMINDER FUNCTION)
*DOOR LOCK KNOB LOCKED WITH IGNITION KEY IN CYLINDER AND DRIVER'S DOOR OPEN
(IGNITION KEY REMINDER FUNCTION)
*UNLOCKING THE DRIVER'S, PASSENGER'S DOOR CYLINDER WITH KEY
4±GROUND : APPROX. 12 VOLTS 0.2 SECONDS WITH FOLLOWING OPERATION
*DOOR LOCK CONTROL SW LOCKED
*LOCKING THE DRIVER'S, PASSENGER'S DOOR CYLINDER WITH KEY
10±GROUND :0 VOLTS WITH DOOR LOCK CONTROL SW LOCKED
14±GROUND : CONTINUITY WITH PASSENGER'S DOOR OPEN
6±GROUND : CONTINUITY WITH DRIVER'S DOOR LOCK KNOB UNLOCKED
5±GROUND : CONTINUITY WITH PASSENGER'S DOOR LOCK KNOB UNLOCKED
11±GROUND :0 VOLTS WITH DOOR LOCK CONTROL SW UNLOCKED, PASSENGER'S DOOR LOCK CYLINDER UNLOCKED WITH KEY
13±GROUND :0 VOLTS WITH PASSENGER'S DOOR LOCK CYLINDER UNLOCKED WITH KEY
1±GROUND : APPROX. 12 VOLTS WITH IGNITION SW AT ACC POSITION
9±GROUND :0 VOLTS WITH DRIVER'S DOOR LOCK CYLINDER UNLOCKED WITH KEY
12±GROUND :0 VOLTS WITH DRIVER'S, PASSENGER'S DOOR LOCK CYLINDER LOCKED WITH KEY
D12, D13 DOOR COURTESY SW
1±GROUND : CLOSED WITH EACH DOOR OPEN
D17, D18 DOOR KEY LOCK AND UNLOCK SW
3±2 : CLOSED WITH DOOR LOCK CYLINDER LOCKED WITH KEY
1±2 : CLOSED WITH DOOR LOCK CYLINDER UNLOCKED WITH KEY
D20, D21 DOOR LOCK MOTOR AND DOOR UNLOCK DETECTION SW (C/P)
1±3 : CLOSED WITH UNLOCK POSITION
D20, D21 DOOR LOCK MOTOR AND DOOR UNLOCK DETECTION SW (EX. C/P)
6±4 : CLOSED WITH UNLOCK POSITION
I12 UNLOCK WARNING SW [IGNITION SW]
1±5 : CLOSED WITH IGNITION KEY IN CYLINDER
: PARTS LOCATION
CODESEE PAGECODESEE PAGECODESEE PAGE
B 936D19B34 (S/D), 36 (W/G)J 233
D 832D20A34 (S/D), 36 (W/G)J 333
D1234 (S/D), 35 (C/P), 36 (W/G)D20B35 (C/P)A34 (S/D), 36 (W/G)
D1334 (S/D), 35 (C/P), 36 (W/G)D2134 (S/D), 35 (C/P), 36 (W/G)P12B34 (S/D), 35 (C/P), 36 (W/G)
D1734 (S/D), 35 (C/P), 36 (W/G)D2234 (S/D), 35 (C/P), 36 (W/G)
P12
C35 (C/P)
D1834 (S/D), 35 (C/P), 36 (W/G)D2334 (S/D), 35 (C/P), 36 (W/G)
D19A34 (S/D), 36 (W/G)I1233
: JUNCTION BLOCK AND WIRE HARNESS CONNECTOR
CODESEE PAGEJUNCTION BLOCK AND WIRE HARNESS (CONNECTOR LOCATION)
1G20COWL WIRE AND J/B NO. 1 (INSTRUMENT PANEL LEFT)
1H20FLOOR NO. 1 WIRE J/B NO. 1 (INSTRUMENT PANEL LEFT)
1K
1L20COWL WIRE AND J/B NO. 1 (INSTRUMENT PANEL LEFT)
1M
20COWL WIRE AND J/B NO. 1 (INSTRUMENT PANEL LEFT)
: CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS
CODESEE PAGEJOINING WIRE HARNESS AND WIRE HARNESS (CONNECTOR LOCATION)
IG142FLOOR NO. 1 WIRE AND INSTRUMENT PANEL WIRE
IH242FRONT DOOR LH WIRE AND INSTRUMENT PANEL WIRE
II242INSTRUMENT PANEL WIRE AND COWL WIRE
IT144FRONT DOOR RH WIRE AND INSTRUMENT PANEL WIRE
IU144FLOOR NO. 2 WIRE AND INSTRUMENT PANEL WIRE
BW146 (S/D)REAR DOOR LH WIRE AND FLOOR NO 1 WIREBW150 (W/G)REAR DOOR LH WIRE AND FLOOR NO. 1 WIRE
BY146 (S/D)REAR DOOR RH WIRE AND FLOOR NO 2 WIREBY150 (W/G)REAR DOOR RH WIRE AND FLOOR NO. 2 WIRE
Bc150 (W/G)BACK DOOR NO. 1 WIRE AND FLOOR NO. 1 WIRE
Bd350 (W/G)BACK DOOR NO. 1 WIRE AND BACK DOOR NO. 2 WIRE
SERVICE HINTS

171
CURRENT ALWAYS FLOWS TO TERMINAL 1 OF THE INTEGRATION RELAY THROUGH THE DOME FUSE.
1. SEAT BELT WARNING SYSTEM
WHEN THE IGNITION SW IS TURNED ON, CURRENT FLOWS FROM THE GAUGE FUSE TO THE TERMINAL 7 OF THE INTEGRATION
RELAY AT THE SAME TIME, CURRENT FLOWS TO TERMINAL 9 OF THE RELAY FROM THE GAUGE FUSE THROUGH THE SEAT BELT
WARNING LIGHT. THIS CURRENT ACTIVATES THE SEAT BELT WARNING RELAY AND, CURRENT FLOWING THROUGH THE WARNING
LIGHT FLOWS FROM TERMINAL 9 OF THE RELAY" TERMINAL 10 " GROUND, CAUSING THE WARNING LIGHT TO LIGHT UP. AT THE
SAME AS THE WARNING LIGHT LIGHTS UP. A BUCKLE SW OFF SIGNAL IS INPUT TO TERMINAL 8 OF THE RELAY, THE CURRENT
FLOWING TO TERMINAL 1 OF THE RELAY FLOWS FROM TERMINAL 10 " GROUND AND THE SEAT BELT WARNING BUZZER SOUNDS
FOR APPROX. 4±8 SECONDS. HOWEVER, IF SEAT BELT IS PUT ON DURING THIS PERIOD (WHILE THE BUZZER IS SOUNDING),
SIGNAL INPUT TO TERMINAL 8 OF THE RELAY STOPS AND THE CURRENT FLOW FROM TERMINAL 1 OF THE RELAY " TERMINAL 10
" GROUND IS CUT, CAUSING THE BUZZER TO STOP.
2. UNLOCK WARNING SYSTEM
WITH THE IGNITION KEY INSERTED IN THE KEY CYLINDER (UNLOCK WARNING SW ON), THE IGNITION SW STILL OFF AND DOOR
OPEN (DOOR COURTESY SW ON), WHEN A SIGNAL IS INPUT TERMINAL 5 AND 6 OF THE RELAY, THE INTEGRATION RELAY
OPERATES, CURRENT FLOWS FROM TERMINAL 1 OF THE RELAY " TERMINAL 10 " GROUND AND THE UNLOCK WARNING
BUZZER SOUNDS.
B 7, B 8 BUCKLE SW
1±2 : CLOSED WITH DRIVR'S LAP BELT IN USE
D12 DOOR COURTESY SW FRONT LH
1±GROUND : CLOSED WITH FRONT LH DOOR OPEN
INTEGRATION RELAY
10±GROUND : ALWAYS CONTINUITY
6±GROUND : CONTINUITY WITH FRONT LH DOOR OPEN
5±GROUND : CONTINUITY WITH IGNITION KEY IN CYLINDER
8±GROUND : CONTINUITY UNLESS DRIVER'S LAP BELT IN USE
9±GROUND :0 VOLTS WITH IGNITION SW ON AND BUCKLE SW OFF
1±GROUND : ALWAYS APPROX. 12 VOLTS
7±GROUND : APPROX. 12 VOLTS WITH IGNITION SW AT ON POSITION
I12 UNLOCK WARNING SW [IGNITION SW]
1±5 : CLOSED WITH IGNITION KEY IN CYLINDER
: PARTS LOCATION
CODESEE PAGECODESEE PAGECODESEE PAGE
B 732D1234 (S/D), 35 (C/P), 36 (W/G)J 536 (W/G)
B 832I1233
C 932J 133
: JUNCTION BLOCK AND WIRE HARNESS CONNECTOR
CODESEE PAGEJUNCTION BLOCK AND WIRE HARNESS (CONNECTOR LOCATION)
1B
1C20COWL WIRE AND J/B NO. 1 (INSTRUMENT PANEL LEFT)
1G
20COWL WIRE AND J/B NO. 1 (INSTRUMENT PANEL LEFT)
1H20FLOOR NO. 1 WIRE J/B NO. 1 (INSTRUMENT PANEL LEFT)
1M20COWL WIRE AND J/B NO. 1 (INSTRUMENT PANEL LEFT)
2E22ENGINE ROOM MAIN WIRE AND J/B NO. 2 (ENGINE COMPARTMENT LEFT)
: CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS
CODESEE PAGEJOINING WIRE HARNESS AND WIRE HARNESS (CONNECTOR LOCATION)
IO142FLOOR NO. 1 WIRE AND SEAT WIRE
: GROUND POINTS
CODESEE PAGEGROUND POINTS LOCATION
IG42INSTRUMENT PANEL BRACE LH
46 (S/D)
BL48 (C/P)UNDER THE LEFT QUARTER PILLARBL
50 (W/G)
UNDER THE LEFT QUARTER PILLAR
SYSTEM OUTLINE
SERVICE HINTS

182
SHIFT LOCK
A
1 2STOP LIGHT
SW
G±R
G±W
G±W G±WL±R
B±RL±R
13 6
KEY INTERLOCK
SOLENOID
L±B W±B
W±B W±B
5 4SHIFT LOCK ECU
SHIFT LOCK
CONTROL SW
SHIFT LOCK
SOLENOID P1
P
P2
SL±
SL+
L±B
2 1 II2 9 II211
B±RL±R
B
BJUNCTION
CONNECTOR
II2 20
G
G±WG±R
L±R
L±R
II1 3
B
B
IEIFJUNCTION
CONNECTOR ()
J3S10
S5
K3J2B 1 A 2
B 2B1NOIS E FILTER
(
FOR STOP LIGHT) N2 ,N3 A
G±W
G±R
1L 91L21M 3 15A
CIG/RADIO15A
ECU±IG15A
STOP
1L 41M 6
FROM POWER SOURCE SYSTEM SEE PAGE 64

BBB
BB B B BBB
BBB J2 J3
B
(
HINT : SEE PAGE 7)(
HINT : SEE PAGE 7)
12 N3B
13X
45612 S5 S10BLUE12K3
1 2 N2A
183
WHEN THE IGNITION SW IS TURNED TO ACC POSITION THE CURRENT FROM THE CIG/RADIO FUSE FLOWS TO TERMINAL 1 OF THE
SHIFT LOCK ECU. WHEN THE IGNITION SW IS TURNED TO ON POSITION THE CURRENT FROM THE ECU±IG FUSE FLOWS TO
TERMINAL 3 OF THE ECU.
1. SHIFT LOCK MECHANISM
WITH THE IGNITION SW ON, WHEN A SIGNAL THAT THE BRAKE PEDAL IS DEPRESSED (STOP LIGHT SW ON) AND A SIGNAL THAT
THE SHIFT LEVER IS PUT IN ªPº POSITION (CONTINUITY BETWEEN P1 AND P OF THE SHIFT LOCK CONTROL SW) IS INPUT TO THE
ECU, THE ECU OPERATES AND CURRENT FLOWS FROM TERMINAL 3 OF THE ECU " TERMINAL SL+ OF THE SHIFT LOCK
SOLENOID " SOLENOID " TERMINAL SL± " TERMINAL 5 OF THE ECU " GROUND. THIS CAUSES THE SHIFT LOCK SOLENOID TO
TURN ON (PLATE STOPPER DISENGAGES) AND THE SHIFT LEVER CAN SHIFT INTO OTHER POSITION THAN THE ªPº POSITION.
2. KEY INTERLOCK MECHANISM
WITH THE IGNITION SW IN ON OR ACC POSITION, WHEN THE SHIFT LEVER IS PUT IN ªPº POSITION (NO CONTINUITY BETWEEN P2
AND P OF SHIFT LOCK CONTROL SW), THE CURRENT FLOWING FROM TERMINAL 4 OF THE ECU " KEYINTERLOCK SOLENOID IS
CUT OFF. THIS CAUSES THE KEYINTERLOCK SOLENOID TO TURN OFF (LOCK LEVER DISENGAGES FROM LOCK POSITION) AND
THE IGNITION KEY CAN BE TURNED FROM ACC TO LOCK POSITION.
S 5 SHIFT LOCK ECU
1±GROUND : APPROX. 12 VOLTS WITH IGNITION SW AT ACC OR ON POSITION
3±GROUND : APPROX. 12 VOLTS WITH IGNITION SW AT ON POSITION
5±GROUND : ALWAYS CONTINUITY
6±GROUND : APPROX. 12 VOLTS WITH BRAKE PEDAL DEPRESSED
4±GROUND :0 VOLTS WITH IGNITION SW AT ACC POSITION AND SHIFT LEVER POSITION IN P POSITION
6±12 VOLTS WITH SHIFT LEVER POSITION IN EXCEPT P POSITION
: PARTS LOCATION
CODESEE PAGECODESEE PAGECODESEE PAGE
J 233N 2A33S1033
J 333N 3B33
K 333S 533
: JUNCTION BLOCK AND WIRE HARNESS CONNECTOR
CODESEE PAGEJUNCTION BLOCK AND WIRE HARNESS (CONNECTOR LOCATION)
1L20COWL WIRE AND J/B NO 1 (INSTRUMENT PANEL LEFT)1M20COWL WIRE AND J/B NO. 1 (INSTRUMENT PANEL LEFT)
: CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS
CODESEE PAGEJOINING WIRE HARNESS AND WIRE HARNESS (CONNECTOR LOCATION)
II142COWL WIRE AND INSTRUMENT PANEL WIRE
II242INSTRUMENT PANEL WIRE AND COWL WIRE
: GROUND POINTS
CODESEE PAGEGROUND POINTS LOCATION
IE42LEFT KICK PANELIF42LEFT KICK PANEL
SYSTEM OUTLINE
SERVICE HINTS
