Fig. 3: Identifying Rear Wiper Motor Terminals (Montero)
Courtesy of Mitsubishi Motor Sales of America.
Automatic Stop Check (Montero)
1) Start motor operation by connecting battery voltage to one
terminal and grounding another terminal. See
REAR WIPER MOTOR OPERATION CHECK table. See Fig. 3. Disconnect wires
during operation to stop motor in mid-sweep.
2) Jumper terminals No. 2 and 3 together. Connect battery
voltage to remaining terminal and ground wiper motor bracket. Ensure
motor parks wiper arm.
REAR WIPER RELAY
Operation Check (Montero)
Relay is located to right of heater blower assembly. Leave
intermittent relay connected to wiring harness. Operate rear wiper and
check voltage at terminal No. 1. See Fig. 4. There should be 12 volts
when rear wiper stops. Zero volts should be present when rear wiper is
operating.
Fig. 4: Identifying Rear Wiper Relay Terminals
Courtesy of Mitsubishi Motor Sales of America.
REAR WIPER SWITCH
OVERDRIVE SWITCH ................................. 3 (A 8)
PARKING BRAKE SWITCH ............................ 6 (A 21)
POWER TRANSISTOR ................................. 2 (D 4)
POWER WINDOWS .............................. 7 (B-E 24-26)
RADIO (PARTIAL) ............................... 3 (D-E 10)
REAR BLOWER SWITCH .............................. 4 (D 12)
REAR WIPER .................................... 5 (D-E 16)
SEAT BELT WARNING TIMER ......................... 5 (D 18)
STARTER .......................................... 1 (C 3)
STOP LIGHT SWITCH ..................... 4 (E 13), 5 (C 16)
SUB FUSE LINKS ................................... 1 (A 3)
SUNROOF ...................................... 7 (A 24-25)
WIPER SWITCH .................................. 5 (A-B 19)
\
\
\
\
\
\
WIRING DIAGRAMS
