closer to pinion gear. If backlash is too low, move ring gear away
from pinion gear.
3) To change backlash readings, move shims from one side of
differential case to other. When backlash adjustment is completed,
check tooth contact pattern. See GEAR TOOTH CONTACT PATTERNS in this
section. Pattern should be correct if assembly and adjustments have
been done properly.
4) When differential is complete and correctly adjusted,
install new cover gasket and cover. Tighten cover bolts to 30-40 ft.
lbs. (41-54 N.m). Fill assembly with hypoid lubricant.
AXLE ASSEMBLY SPECIFICATIONS TABLE
\
\
\
\
\
\
Application Specifications In. (mm)
Pinion Gear Depth (Nominal Dimension)
Model 44 ................................. 2.625 (66.68)
Model 60 & 61 ............................ 3.125 (79.38)
Model 70 & 80 ............................ 3.500 (88.90)
Ring Gear Backlash ................... .004-.009 (.10-.23)
Side Bearing Preload .......................... .015 (.38)
INCH lbs. (N.m)
Pinion Bearing Preload
New Bearings ........................... 20-40 (2.3-4.5)
Used Bearings .......................... 10-20 (1.1-2.3)
\
\
\
\
\
\
TORQUE SPECIFICATIONS
TORQUE SPECIFICATIONS TABLE \
\
\
\
\
\
Applications Ft. Lbs. (N.m)
Axle Flange-to-Hub Bolt
Model 44 ...................................... 35 (48)
Models 60 & 61 ................................ 55 (75)
Model 70 & 80 ................................ 85 (115)
Pinion Shaft Flange Nut
Models 44 & 70 .............................. 210 (285)
Models 60 & 61 .............................. 270 (367)
Model 80 ............................ 440-500 (597-678)
Ring Gear-to-Case Bolt
Model 44 ...................................... 55 (75)
Models 60, 61, & 70 ......................... 110 (149)
Model 80 ............................ 145-165 (196-223)
Side Bearing Cap Bolt ........................... 80 (108)
Front Axle
Cherokee, Comanche, & Wagoneer
Axle Shaft Nut ............................. 175 (237)
Disconnect Housing Bolt ...................... 10 (14)
Hub-to-Knuckle Bolt ......................... 75 (102)
Lower Control Arm Bolt ..................... 133 (180)
Lower Shock Mount Bolt ....................... 14 (19)
Drive Shaft Bolt ............................. 14 (19)
Stabilizer Bar Link Bolt ..................... 70 (95)
Tie Rod Nut ............................ 25-45 (34-61)
Upper Control Arm Bolt ....................... 37 (50)
Wheel Lug Nut ............................... 75 (102)
Grand Wagoneer
Leaf Spring "U" Bolt Nut ................... 100 (136)
Lower Shock Mount Bolt ....................... 45 (61)
Page 636 of 1378
CYLINDER BLOCK
* PLEASE READ THIS FIRST *
NOTE: Always refer to appropriate engine overhaul article in the
ENGINES section for complete overhaul procedures and
specifications for the vehicle being repaired.
BLOCK CLEANING
Only cast cylinder blocks should be hot tank cleaned.
Aluminum cylinder blocks should be cleaned using cold tank method.
Cylinder block is cleaned in order to remove carbon deposits, gasket
residue and water jacket scale. Remove oil galley plugs, freeze plugs
and cam bearings prior to block cleaning.
BLOCK INSPECTION
Visually inspect the block. Check suspected areas for cracks
using the Dye Penetrant inspection method. Block may be checked for
cracks using the Magnaflux method.
Cracks are most commonly found at the bottom of the
cylinders, the main bearing saddles, near expansion plugs and between
the cylinders and water jackets. Inspect lifter bores for damage.
Inspect all head bolt holes for damaged threads. Threads should be
cleaned using tap to ensure proper head bolt torque. Consult machine
shop concerning possible welding and machining (if required).
CYLINDER BORE INSPECTION
Inspect the bore for scuffing or roughness. Cylinder bore
is dimensionally checked for out-of-round and taper using dial bore
gauge. For determining out-of-round, measure cylinder parallel and
perpendicular to the block centerline. Difference in the 2 readings
is the bore out-of-round. Cylinder bore must be checked at top, middle
and bottom of piston travel area.
Bore taper is obtained by measuring bore at the top and
bottom. If wear has exceeded allowable limits, block must be honed
or bored to next available oversize piston dimension.
CYLINDER HONING
Cylinder must be properly honed to allow new piston rings to
properly seat. Cross-hatching at correct angle and depth is critical
to lubrication of cylinder walls and pistons.
A flexible drive hone and power drill are commonly used.
Drive hone must be lubricated during operation. Mix equal parts of
kerosene and SAE 20w engine oil for lubrication.
Apply lubrication to cylinder wall. Operate cylinder hone
from top to bottom of cylinder using even strokes to produce 45 degree
cross-hatch pattern on the cylinder wall. DO NOT allow cylinder hone
to extend below cylinder during operation.
Recheck bore dimension after final honing. Wash cylinder
wall with hot soapy water to remove abrasive particles. Blow dry with
compressed air. Coat cleaned cylinder walls with lubricating oil.
DECK WARPAGE
Check deck for damage or warped head sealing surface. Place
a straightedge across gasket surface of the deck. Using feeler gauge,
measure clearance at center of straightedge. Measure across width and
Page 914 of 1378
Command-Trac .............................. 2.2 Pts. (1.0L)
Drive Axles (3)
Front ....................................... 2.5 Pts. (1.2L)
Front (Disconnect Housing) ( 4) ............. 5.0 Ozs. (0.15L)
Rear ........................................ 2.5 Pts. (1.2L)
Rear (Trac-Lok) ( 5) ......................... 2.5 Pts. (1.2L)
( 1) - Capacities are recommended or calculated levels. Always use
dipstick (if available) to measure level.
( 2) - Includes 2.3 Qts. for coolant recovery bottle.
( 3) - Fill to bottom of filler plug hole.
( 4) - Add 5 Ozs. of gear lubricant through indicator switch hole.
( 5) - Add 2 Ozs. of Limited-Slip differential lubricant additive
first, then add new fluid.
\
\
\
\
\
\
\
WHEEL & TIRE SPECIFICATIONS
WHEEL & TIRE SPECIFICATIONS TABLE\
\
\
\
\
\
Wheel Size Tire Size
Cherokee
15x6 & 15x7 (Aluminum Or Steel) ............. P195/75R15
15x6 & 15x7 (Aluminum Or Steel) ............. P205/75R15
15x6 & 15x7 (Aluminum Or Steel) ............. P215/75R15
15x6 & 15x7 (Aluminum Or Steel) ............. P225/75R15
Wagoneer
15x6 (Aluminum/Steel) ....................... P205/75R15
All Models
16-Inch Wheels ...................... Compact Spare Tire
\
\
\
\
\
\
TIRE REPLACEMENT
CAUTION: Always ensure all 4 tires on the vehicle are the same size,
except when using the temporary spare. The use of
mismatched tires may cause unpredictable handling.
Replacing original tires with tires of a different size may
result in false speedometer and odometer indications.
TIRE INFLATION
The tire specification decal is located in the glove box.
WHEEL TIGHTENING
Tighten the lug nuts firmly in a crisscross pattern as shown
in Fig. 11 . Tighten to 95 ft. lbs (129 N.m). Always position wheel
locking nut opposite valve stem in position indicated. See Fig. 11.
Fig. 11: Wheel Locking Nut Location
Courtesy of American Motors Corp.
Page 969 of 1378
![JEEP CHEROKEE 1988 Service Repair Manual Lube Front Axle Drive Joint and Pivot Bearings (4WD)
\b\
\
\
\
\
\](/manual-img/16/57037/w960_57037-968.png "JEEP CHEROKEE 1988 Service Repair Manual Lube Front Axle Drive Joint and Pivot Bearings (4WD)
\b\
\
\
\
\
\")
Lube Front Axle Drive Joint and Pivot Bearings (4WD)
\b\
\
\
\
\
\
\
Suspension Bushings, Springs, Arms & Rear Jounce Bumpers
\b\
\
\
\
\
\
\
Parking Brake System
\b\
\
\
\
\
\
\
Lubricate Body Components
\b\
\
\
\
\
\
\
Inspect Shocks for Leakage
\b\
\
\
\
\
\
\
Inspect Tire Wear Pattern
\b\
\
\
\
\
\
\
Rotate Tires and Adjust Air Pressure (Including Spare)
\
\
\
\
\
\
\
Replace
\
\
\
\
\
\
\
Engine Oil
\b\
\
\
\
\
\
\
Oil Filter
\b\
\
\
\
\
\
\
Spark Plugs
\b\
\
\
\
\
\
\
Air Filter Element
\b\
\
\
\
\
\
\
PCV Filter
\b\
\
\
\
\
\
\
Fuel Filter
\
\
\
\
\
\
\
Lubrication Specifications
\
\
\
\
\
\
\
Application Specification
Automatic Transmission .......................... Dexron-IIE ATF
Brake Master Cylinder .......... DOT 3 (SAE J-1703F) Brake Fluid
Engine Coolant ........... Alugard 340-2 & Water (50/50 Mixture)
Engine Oil (
1)
Gasoline Engine
Temperature Range
Above 30
F (-1
C) ........ SAE 20W-40 Or 20W-50 API SH/CD
Above 0
F (-18
C) ......... SAE 10W-30 Or 10W-40 API SH/CD
Less Than 60
F (16
C) ............... SAE 5W-30 API SH/CD
Drive Axles ................................ SAE 75W-90 API GL-5
Drive Axles (Trac-Lok) (
2) ................ SAE 80W-140 API GL-5
Drive Axles (Trailer Towing) .............. SAE 80W-140 API GL-5
Hydraulic Clutch ............... DOT 3 (SAE J-1703F) Brake Fluid
Manual Transmission ........................ SAE 75W-90 API GL-5
Parking Brake Cable Guides ................. NLGI Grade 2, GC-LB
Door & Hood Hinges ............................ Light Engine Oil
Manual Steering Box ............... Multi-Purpose NLGI Grade 2EP
Power Steering Pump ....................... Power Steering Fluid
Transfer Case ................................... Dexron-IIE ATF
Brake Caliper Bushings ........ GE 661 or DOW 111 Silicone Grease
Caliper Slide Pins ........... GE 661 or DOW 111 Silicone Grease
Wheel Bearings .................. Multi-Purpose NLGI Grade GC-LB
Drive Shaft U-Joints .............. Multi-Purpose NLGI Grade 2EP
Steering Linkage (
4)( 5) .................... NLGI Grade 2, GC-LB
Ball Joints (
4)( 6) ......................... NLGI Grade 2, GC-LB
Weatherstrip .......................... Silicone Spray Lubricant
Wheel Lug Nut Torque ...................... 95 ft. lbs. (129 N.m)
(
1) - SAE 10W-30 SH/CD is preferred.
(
2) - Add 4 ozs. (118 ml) of Limited-Slip differential lubricant
additive when changing fluid.
Page 974 of 1378
![JEEP CHEROKEE 1988 Service Repair Manual \b\
\
\
\
\
\
\
Check/Lube Manual Steering Gear](/manual-img/16/57037/w960_57037-973.png "JEEP CHEROKEE 1988 Service Repair Manual \b\
\
\
\
\
\
\
Check/Lube Manual Steering Gear")
\b\
\
\
\
\
\
\
Check/Lube Manual Steering Gear
\b\
\
\
\
\
\
\
Check Drive Shaft Seals
\b\
\
\
\
\
\
\
Lubricate Ball Joints, Steering Linkage & Suspension
\b\
\
\
\
\
\
\
Lube Drive Shaft U-Joints and Slip Splines
\b\
\
\
\
\
\
\
Lube Front Axle Drive Joint and Pivot Bearings (4WD)
\b\
\
\
\
\
\
\
Lube Parking Brake Ratio Lever Pivot
\b\
\
\
\
\
\
\
Lube Manual Gearshift Control (4WD Transfer Case)
\b\
\
\
\
\
\
\
Inspect/Repack Front Wheel Bearings (2WD Models)
\b\
\
\
\
\
\
\
Inspect Front Brake Pads & Rotors
\b\
\
\
\
\
\
\
Lubricate Caliper Slide Rails
\b\
\
\
\
\
\
\
Inspect Rear Brake Linings & Drums
\b\
\
\
\
\
\
\
Inspect Brake System Hoses & Lines
\b\
\
\
\
\
\
\
Inspect Shocks for Leakage
\b\
\
\
\
\
\
\
Inspect Tire Wear Pattern
\b\
\
\
\
\
\
\
Lubricate Weatherstripping with Silicone
\b\
\
\
\
\
\
\
Lubricate Door Hinges
\b\
\
\
\
\
\
\
Lubricate Door Locks
\b\
\
\
\
\
\
\
Check Body Drain Holes
\b\
\
\
\
\
\
\
Rotate Tires and Adjust Air Pressure
\
\
\
\
\
\
\
Replace
\
\
\
\
\
\
\
Engine Oil
\b\
\
\
\
\
\
\
Oil Filter
\b\
\
\
\
\
\
\
Automatic Transmission Fluid, Filter and Adjust Bands
\b\
\
\
\
\
\
\
Flush and Fill Engine Coolant, if not done in last 36 months
\
\
\
\
\
\
\
Lubrication Specifications
\
\
\
\
\
\
\
Application Specification
Automatic Transmission .......................... Dexron-IIE ATF
Brake Master Cylinder .......... DOT 3 (SAE J-1703F) Brake Fluid
Engine Coolant ........... Alugard 340-2 & Water (50/50 Mixture)
Engine Oil (
1)
Gasoline Engine
Temperature Range
Above 30
F (-1
C) ........ SAE 20W-40 Or 20W-50 API SH/CD
Above 0
F (-18
C) ......... SAE 10W-30 Or 10W-40 API SH/CD
Less Than 60
F (16
C) ............... SAE 5W-30 API SH/CD
Drive Axles ................................ SAE 75W-90 API GL-5
Page 979 of 1378
![JEEP CHEROKEE 1988 Service Repair Manual Choke Linkage
\b\
\
\
\
\
\](/manual-img/16/57037/w960_57037-978.png "JEEP CHEROKEE 1988 Service Repair Manual Choke Linkage
\b\
\
\
\
\
\")
Choke Linkage
\b\
\
\
\
\
\
\
Ignition Timing
\b\
\
\
\
\
\
\
Lubricate Manifold Heat Control Valve (if equipped)
\b\
\
\
\
\
\
\
Clean PCV Breather (if equipped)
\b\
\
\
\
\
\
\
Clean EGR Passages (if equipped)
\b\
\
\
\
\
\
\
Inspect C/V Joint boots (4WD)
\b\
\
\
\
\
\
\
Inspect Underside of Vehicle (Bolts & Threaded Fasteners)
\b\
\
\
\
\
\
\
Check/Lube Manual Steering Gear
\b\
\
\
\
\
\
\
Check Drive Shaft Seals
\b\
\
\
\
\
\
\
Lubricate Ball Joints, Steering Linkage & Suspension
\b\
\
\
\
\
\
\
Lube Drive Shaft U-Joints and Slip Splines
\b\
\
\
\
\
\
\
Lube Front Axle Drive Joint and Pivot Bearings (4WD)
\b\
\
\
\
\
\
\
Inspect Front Wheel Bearings (4WD)
\b\
\
\
\
\
\
\
Suspension Bushings, Springs, Arms & Rear Jounce Bumpers
\b\
\
\
\
\
\
\
Parking Brake System
\b\
\
\
\
\
\
\
Inspect Shocks for Leakage
\b\
\
\
\
\
\
\
Inspect Tire Wear Pattern
\b\
\
\
\
\
\
\
Rotate Tires and Adjust Air Pressure (Including Spare)
\
\
\
\
\
\
\
Replace
\
\
\
\
\
\
\
Engine Oil
\b\
\
\
\
\
\
\
Oil Filter
\b\
\
\
\
\
\
\
Spark Plugs
\b\
\
\
\
\
\
\
Ignition Cables
\b\
\
\
\
\
\
\
Distributor Cap and Rotor
\b\
\
\
\
\
\
\
Air Filter Element
\b\
\
\
\
\
\
\
EGR Valve & Tube (1987-92)
\b\
\
\
\
\
\
\
Vacuum Operated Emission Components (1987-92)
\b\
\
\
\
\
\
\
PCV Valve (
1)
\b\
\
\
\
\
\
\
Drive Belt (V-Type) (
2)
\b\
\
\
\
\
\
\
Flush and Fill Engine Coolant, if not done in last 24 months
\b\
\
\
\
\
\
\
Automatic Transmission Fluid, Filter and Adjust Bands
\b\
\
\
\
\
\
\
Accessory Drive Belts
Page 982 of 1378
![JEEP CHEROKEE 1988 Service Repair Manual \
\
\
\
\
\
\
Service Or Inspect](/manual-img/16/57037/w960_57037-981.png "JEEP CHEROKEE 1988 Service Repair Manual \
\
\
\
\
\
\
Service Or Inspect")
\
\
\
\
\
\
\
Service Or Inspect
\
\
\
\
\
\
\
Verify Last Major Service Was Performed
\b\
\
\
\
\
\
\
Check Fluid Levels
\b\
\
\
\
\
\
\
Check Fuel Lines, Connections
\b\
\
\
\
\
\
\
Check Cooling System Hoses and Clamps
\b\
\
\
\
\
\
\
Check Exhaust System & Heat Shielding
\b\
\
\
\
\
\
\
Inspect C/V Joint boots (4WD)
\b\
\
\
\
\
\
\
Inspect Underside of Vehicle (Bolts & Threaded Fasteners)
\b\
\
\
\
\
\
\
Check/Lube Manual Steering Gear
\b\
\
\
\
\
\
\
Check Drive Shaft Seals
\b\
\
\
\
\
\
\
Lubricate Ball Joints, Steering Linkage & Suspension
\b\
\
\
\
\
\
\
Lube Drive Shaft U-Joints and Slip Splines
\b\
\
\
\
\
\
\
Lube Front Axle Drive Joint and Pivot Bearings (4WD)
\b\
\
\
\
\
\
\
Lube Parking Brake Ratio Lever Pivot
\b\
\
\
\
\
\
\
Lube Manual Gearshift Control (4WD Transfer Case)
\b\
\
\
\
\
\
\
Inspect/Repack Front Wheel Bearings (2WD Models)
\b\
\
\
\
\
\
\
Inspect Front Brake Pads & Rotors
\b\
\
\
\
\
\
\
Lubricate Caliper Slide Rails
\b\
\
\
\
\
\
\
Inspect Rear Brake Linings & Drums
\b\
\
\
\
\
\
\
Inspect Brake System Hoses & Lines
\b\
\
\
\
\
\
\
Inspect Shocks for Leakage
\b\
\
\
\
\
\
\
Inspect Tire Wear Pattern
\b\
\
\
\
\
\
\
Rotate Tires and Adjust Air Pressure (Including Spare)
\
\
\
\
\
\
\
Replace
\
\
\
\
\
\
\
Engine Oil
\b\
\
\
\
\
\
\
Oil Filter, if it has not been changed in the last 12 months
\
\
\
\
\
\
\
Lubrication Specifications
\
\
\
\
\
\
\
Application Specification
Automatic Transmission .......................... Dexron-IIE ATF
Brake Master Cylinder .......... DOT 3 (SAE J-1703F) Brake Fluid
Engine Coolant ........... Alugard 340-2 & Water (50/50 Mixture)
Engine Oil (
1)
Gasoline Engine
Temperature Range
Page 990 of 1378
![JEEP CHEROKEE 1988 Service Repair Manual Lube Parking Brake Ratio Lever Pivot
\b\
\
\
\
\
\](/manual-img/16/57037/w960_57037-989.png "JEEP CHEROKEE 1988 Service Repair Manual Lube Parking Brake Ratio Lever Pivot
\b\
\
\
\
\
\")
Lube Parking Brake Ratio Lever Pivot
\b\
\
\
\
\
\
\
Lube Manual Gearshift Control (4WD Transfer Case)
\b\
\
\
\
\
\
\
Inspect/Repack Front Wheel Bearings (2WD Models)
\b\
\
\
\
\
\
\
Inspect Front Brake Pads & Rotors
\b\
\
\
\
\
\
\
Lubricate Caliper Slide Rails
\b\
\
\
\
\
\
\
Inspect Rear Brake Linings & Drums
\b\
\
\
\
\
\
\
Inspect Brake System Hoses & Lines
\b\
\
\
\
\
\
\
Inspect Shocks for Leakage
\b\
\
\
\
\
\
\
Inspect Tire Wear Pattern
\b\
\
\
\
\
\
\
Lubricate Weatherstripping with Silicone
\b\
\
\
\
\
\
\
Lubricate Door Hinges
\b\
\
\
\
\
\
\
Lubricate Door Locks
\b\
\
\
\
\
\
\
Check Body Drain Holes
\b\
\
\
\
\
\
\
Rotate Tires and Adjust Air Pressure
\
\
\
\
\
\
\
Replace
\
\
\
\
\
\
\
Engine Oil
\b\
\
\
\
\
\
\
Oil Filter
\b\
\
\
\
\
\
\
Air Filter Element
\b\
\
\
\
\
\
\
Fuel Filter
\b\
\
\
\
\
\
\
Spark Plugs
\b\
\
\
\
\
\
\
Automatic Transmission Fluid, Filter and Adjust Bands
\b\
\
\
\
\
\
\
PCV Filter
\b\
\
\
\
\
\
\
PCV Valve (
1) ( 2)
\b\
\
\
\
\
\
\
Drive Belt (V-Type) (
2) ( 3)
\
\
\
\
\
\
\
(
1) - Replacement is recommended by Chrysler at this time, but it
is not required to maintain the warranty on the PCV valve.
(
2) - Not required, if belt or PCV Valve was previously replaced
(
3) - Check and replace as needed.
\
\
\
\
\
\
\
Lubrication Specifications
\
\
\
\
\
\
\
Application Specification
Automatic Transmission .......................... Dexron-IIE ATF
Brake Master Cylinder .......... DOT 3 (SAE J-1703F) Brake Fluid
Engine Coolant ........... Alugard 340-2 & Water (50/50 Mixture)
Engine Oil (
1)
Gasoline Engine
Temperature Range
