I20456
(1) LOCK switch
(2) UNLOCK switch
(3) Luggage door switch
(4) Disagreement of recognition code or
rolling code.
0.13secs.
0.5secs.
0.13secs. 0.25secs. 0.5secs.
0.5secs. 0.5secs.
OFF ON
OFF ON
OFF ON
OFF ON
While receiving
I04149
- BODY ELECTRICALWIRELESS DOOR LOCK CONTROL SYSTEM
BE-101
2474 Author: Date:
2004 LAND CRUISER (RM1071U)
(c) Diagnosis Mode Check.
HINT:
Check how the taillight lights up when pressing each transmitter
switch.
(1) LOCK switch
(2) UNLOCK switch
(3) Luggage door switch
(4) Disagreement of recognition code or rolling code.
HINT:
If (4) is detected in the Diagnosis Check, conduct the recogni-
tion code registration.
(5) No response from the taillight.
HINT:
Conduct the following checks.
Wireless door lock transmitter.
Wireless door lock receiver.
4. INSPECT WIRELESS DOOR LOCK TRANSMITTER
OPERATION
HINT:
Refer to ºWireless door lock control receiver and transmitter re-
placementº.
(a) Using a screwdriver, remove the screw and cover.
(b) Remove the battery (lithium battery).
(c) Install a new or normal battery (lithium battery).
HINT:
When a new or normal battery can not be obtained, connect 2
new 1.5 V batteries in series, connect the battery (+) to the bat-
tery receptacle side terminal and battery (-) to the bottom termi-
nal, then apply 3 V voltage to the transmitter.
(d) In the location where is approx. 1 M away from driver's
outside handle in the right direction, face the key plate of
the transmitter to the vehicle, and check the transmitter
operation when pressing transmission switch on the side
of the transmitter body.
(e) Install the battery (lithium battery).
(f) Install a cover so that O-ring is not distorted or slipped off.
(g) Using a screwdriver, tighten the screw.
Standard:
Remote control of vehicle door lock can be operated.
LED lights up more than once.
HINT:
The minimum operation distance differs according to op-
erator, the way of holding, and location.
BO1L0-05
H16046
Headrest
Headrest SupportRear Seat Shoulder
Belt CoverRear Seat
Shoulder Belt Guide
Rear Seat Outer Belt
Reclining Adjuster
Release Handle No. 1 Reclining Cover
Corner Pad
Rear No. 1
Seat Adjuster
Seat Adjuster
Control Cable Seatback Cover
Seatback Pad
Seatback Frame No. 1 ProtectorSeatback Board
Protector
Rear No. 1 Seat AdjusterReclining Inner Cover
Corner Pad
No. 1 Reclining Cover
Hinge
CoverSeat Cushion
Cover
Seat Cushion Pad
Seat Cushion FrameReclining Remote
Control Lever Knob
Hinge Cover
Fold Seat
Stopper Band
Armrest Seat Cushion
Under Cover
Lock Striker
Stay Cover
RH No. 1 Leg
StayLH No. 1 Leg Stay Rear Seat
StayRear Seat
Cushion HingeHinge Cover
Hinge CoverNo. 1 Fold Seat
Lock Control Cable
Seat
Lock
CoverRear Seat
Inner Belt
: Specified torque
Non-reusable part Hog Ring
Hog Ring
42 (430, 31)
Armrest Hinge
Hinge Cover
41 (420, 30)
Hinge Cover
Rear Seat Lock
Bracket
Seat Cushion
Under Cover
Sub-Assembly
42 (430, 31)
C
41 (420, 30)
N´m (kgf´cm, ft´lbf) BO-1 18
- BODYREAR NO.1 SEAT (LH)
2692 Author: Date:
2004 LAND CRUISER (RM1071U)
REAR NO.1 SEAT (LH)
COMPONENTS
BO1L5-05
H07958
Headrest
Headrest Support
Seatback Cover Seatback Pad
Seatback Frame No. 1 ProtectorSeatback BoardNo. 1 Reclining Cover
Corner Pad No. 1 Seat Adjuster
Rear No. 1
Seat Inner Belt Reclining
Inner
Cover
Hinge Cover
Reclining Inner CoverReclining
Connecting Wire
No. 1 Seat
Adjuster
Hinge Cover
No. 1
Reclining
Cover Corner Pad
Reclining Adjuster
Release HandleSeat Cushion
Under Cover
Seat Cushion
Under CoverSeat Cushion
Under Cover
Sub-Assembly
Rear Seat
Lock Striker Cover Fold Seat
Stopper Band
No. 1 Seat Leg StaySeat Leg Rear Seat
Lock
No. 2 Fold Seat
Lock Control CableLock Cover
Reclining Remote
Control Lever Knob
: Specified torque
N´m (kgf´cm, ft´lbf)
Non-reusable part
Hog Ring
Hinge Cover
Cushion
Hog Ring
Seat Cushion Cover
Seat Cushion Pad
Seat Cushion Frame
37 (380, 27)
41 (420, 30)
37 (380, 27)
BO-126
- BODYREAR NO.1 SEAT (RH)
2700 Author: Date:
2004 LAND CRUISER (RM1071U)
REAR NO.1 SEAT (RH)
COMPONENTS
H05307
H05308
- BODYREAR NO.1 SEAT (RH)
BO-129
2703 Author: Date:
2004 LAND CRUISER (RM1071U)
7. REMOVE SEATBACK FRAME
(a) Remove the 4 screws and reclining inner cover.
(b) Remove the 2 hog rings.
HINT:
At the time of reassembly, please refer to the following item.
When installing hog rings, take care to prevent wrinkles as little
as possible.
(c) Disengage the hook, then remove the headrest supports.
(d) Remove the seatback frame.
(e) Remove the 2 No. 1 protectors from the seatback frame.
8. REMOVE SEATBACK COVER
Remove the hog rings and seatback cover.
HINT:
At the time of reassembly, please refer to the following item.
When installing hog rings, take care to prevent wrinkles as little
as possible.
9. REMOVE SEAT CUSHION UNDER COVER
Remove the 2 screws and 2 seat cushion under covers.
10. REMOVE SEAT CUSHION COVER WITH PAD
(a) Using a screwdriver, disengage the hooks as shown in the
illustration.
HINT:
Tape the screwdriver tip before use.
(b) Remove the seat cushion cover with pad.
11. REMOVE SEAT CUSHION COVER
Remove the hog rings and seatback cover.
HINT:
At the time of reassembly, please refer to the following item.
When installing hog rings, take care to prevent wrinkles as little
as possible.
12. REMOVE CUSHION
Remove the screw and cushion from the seat cushion under
cover sub-assembly.
13. REMOVE LOCK COVER
Remove the screw and lock cover.
14. REMOVE RECLINING REMOTE CONTROL LEVER
KNOB
Remove the screw and reclining remote control lever knob.
15. REMOTE FOLD SEAT STOPPER BAND
Remove the bolt and fold seat stopper band.
16. REMOVE SEAT CUSHION UNDER COVERS
Remove the 2 screws and 2 seat cushion under covers.
I20456
(1) LOCK switch
(2) UNLOCK switch
(3) Luggage door switch
(4) Disagreement of recognition code or
rolling code.
0.13secs.
0.5secs.
0.13secs. 0.25secs. 0.5secs.
0.5secs. 0.5secs.
OFF ON
OFF ON
OFF ON
OFF ON
While receiving
I04149
- DIAGNOSTICSWIRELESS DOOR LOCK CONTROL SYSTEM
DI-939
1132 Author: Date:
(c) Diagnosis Mode Check.
HINT:
Check how the taillight lights up when pressing each transmitter
switch.
(1) LOCK switch
(2) UNLOCK switch
(3) Luggage door switch
(4) Disagreement of recognition code or rolling code.
HINT:
If (4) is detected in the Diagnosis Check, conduct the recogni-
tion code registration.
(5) No response from the taillight.
HINT:
Conduct the following checks.
Wireless door lock transmitter.
Wireless door lock receiver.
4. INSPECT WIRELESS DOOR LOCK TRANSMITTER
OPERATION
HINT:
Refer to º3. REPLACE TRANSMITTER (LITHIUM) BATTERYº.
(a) Using a screwdriver, remove the 2 screws and cover.
(b) Remove the battery (lithium battery).
(c) Install a new or normal battery (lithium battery).
HINT:
When a new or normal battery can not be obtained, connect 2
new 1.5 V batteries in series, connect the battery (+) to the bat-
tery receptacle side terminal and battery (-) to the bottom termi-
nal, then apply 3 V voltage to the transmitter.
(d) In the location where is approx. 1 m away from driver's
outside handle in the right direction, face the key plate of
the transmitter to the vehicle, and check the transmitter
operation when pressing transmission switch of the trans-
mitter body.
Standard:
Remote control of vehicle door lock can be operated.
LED lights up more than once.
2004 LAND CRUISER (EWD548U)
8B HOW TO USE THIS MANUAL
The ground points circuit diagram shows the connections from all major parts to the respective ground points. When
troubleshooting a faulty ground point, checking the system circuits which use a common ground may help you identify
the problem ground quickly. The relationship between ground points (
EA, IB and IC shown below) can also be
checked this way.
5
5
5
5
4
44
4
4 BA15IB18EA2
ID115
IC33 IA12 E 3
W-BW-B W-B W-B W-B
W-B
W-B
W-B
W-B W-B
W-B
W-B W-B
W-B
W-B W-B W-BW-B W-B W-B W-B
W-B
W-B
W-B
W-B W-B W-B
W-B
BR
W-B
BR BRW-BW-B W-B
W-B
W-B
W-B
W-B W-B W-B
W-B
W-B W-B
W-B
W-B
BR W-B
BR BR
BR W-B (4A-GZE)
W-B W-BI 2
I 2
B 5 I 5 I 5 I 5
B 5
B 5
B 5
I 5
I 5
I 3 I 3 E 3
E 3
E 3
E 2
E 4
E 5
E 4
E 5
E 6 E 4 E 4
B 4
EA I 4
B 4
B 4
I 4 I 8
IB IC 443E5
3E6 3G13 3F3 3D1 3B7W-B
W-B
W-B W-B W-B
W-B
W-B
W-B
W-B
W-B
W-B
W-B
W-B
W-B W-BI 6
I 6
I 2 3C7
10A A A A
A
A
Junction
Connector J 1
W-B
W-B
W-B W-B
BR W-B W-B
W-B
W-B W-B
W-B
I GROUND POINT
FAN MAIN Relay
FAN MAIN Relay
A/C Relay No.2
A/C Relay No.3
Radiator Fan Motor
Headlight Cleaner Relay
Headlight LH
Headlight RH
Front Fog Light LH
Brake Fluid Level SW Front Fog Light RH Front Turn Signal Light RH
Front Clearance Light RH
Front Turn Signal Light LH
Front Clearance Light LH
Door Lock Control SW
Door Courtesy SW RH
Door Lock Motor RH
Door Lock Control Relay
Blower Resistor
Idle-Up SW
A/C Amplifier
Radio and Player
HEATER Relay
Auto Antenna MotorA/C Control Assembly
Blower Motor
Blower SW
Parking Brake SW
Combination Meter
Combination SW
Cruise Control ECU
Remote Control Mirror SW
Turn Signal Flasher
Defogger SW
Unlock Warning SW
Power Window Master SW
Power Window Control
Relay
Door Courtesy SW LH
Door Lock Control SW
Door Lock Motor LH
Fuel Control SW
Woofer Speaker Amplifier
Combination Meter
Combination Meter
Fuel Sender Cigarette Lighter
O/D Main SW
Clock
Combination SW
*The system shown here is an EXAMPLE ONLY. It is different to the actual circuit shown in the SYSTEM CIRCUITS SECTION.
2004 LAND CRUISER (EWD548U)
71 G
Position of Parts in Instrument Panel
J 1 Junction Connector
J 2 Junction Connector
J 3 Junction Connector
J 4 Junction Connector
J 5 Junction Connector
J 6 Junction Connector
J 7 Junction Connector
J 8 Junction Connector
J 9 Junction Connector
J 10 Junction Connector
J 11 Junction Connector
J 12 Junction Connector
J 13 Junction Connector
J 14 Junction Connector
J 15 Junction Connector
J 16 Junction Connector
J 17 Junction Connector
J 18 Junction Connector
J 19 Junction Connector
J 20 Junction Connector
J 21 Junction Connector
K 3 Key Interlock Solenoid
M 5 Multi-Display
M 6 Multi-Display
M 7 Multi-Display
M 9 Multi-Display
P 4 Power Outlet (Front)
P 5 Power Outlet (Rear Console Box)
P 6 Power Quarter Window SW LH
P 7 Power Quarter Window SW RHR 5 Remote Control Mirror SW
R 6 Rheostat
R 7 Room Temp. Sensor (Front)
R 36 Radio and Player
R 37 Radio and Player
R 38 Radio and Player
R 39 Rear Seat Audio Controller
R 40 Roll Sensing of Curtain Shield Airbags Cutoff SW
S 3 Seat Heater SW (Driver's Seat)
S 4 Seat Heater SW (Front Passenger's Seat)
S 5 Stop Light SW
T 4 Telescopic Motor
T 5 Theft Deterrent ECU
T 7 Tilt and Telescopic ECU
T 8 Tilt and Telescopic ECU
T 9 Tilt Motor
T 10 Ignition Key Cylinder Light
Transponder Key Amplifier
T 11 Turn Signal Flasher
T 18 Towing Brake Controller
T 19 Transponder Key Computer
U 1 Unlock Warning SW
V 8 VSC Warning Buzzer
Y 1 Yaw Rate Sensor
Z 1 Option Connector (Glass Breakage Sensor)
2004 LAND CRUISER (EWD548U)
73 G
Position of Parts in Body
P 8 Parking Brake SW
P 9 Power Outlet (Luggage Compartment)
P 10 Power Vent Window Motor LH
P 11 Power Vent Window Motor RH
P 12 Power Window Master SW
P 14 Power Window Motor Front LH
P 15 Power Window Motor Front RH
P 16 Power Window Motor Rear LH
P 17 Power Window Motor Rear RH
P 18 Power Window Control SW Front RH
P 19 Power Window Control SW Rear LH
P 20 Power Window Control SW Rear RH
P 21 Pretensioner LH
P 22 Pretensioner RH
R 8 Rear A/C Control SW
R 9 Rear Air Mix Control Servo Motor
R 10 Rear Combination Light LH
R 11 Rear Combination Light LH
R 12 Rear Combination Light RH
R 13 Rear Combination Light RH
R 14 Rear Cooler Blower Motor
R 15 Rear Cooler Magnetic Valve
R 16 Rear Cooler Power Transistor
R 17 Rear Cooler Relay
R 19 Rear Door Speaker LH
R 20 Rear Door Speaker RH
R 21 Rear Evaporator Temp. Sensor
R 22 Rear Heater Blower Motor
R 25 Rear Heater Power Transistor
R 26 Rear Inlet Air Temp. SensorR 27 Rear Interior Light
R 28 Rear Window Defogger
R 29 Rear Window Defogger
R 30 Rear Wiper Motor
R 31 Rear Wiper Relay
R 32 Remote Control Mirror LH
R 33 Remote Control Mirror RH
R 34 Room Temp. Sensor (Rear)
S 6 Stereo Component Amplifier
S 7 Stereo Component Amplifier
S 11 Side Airbag Sensor Front LH
S 12 Side Airbag Sensor Front RH
S 13 Side Airbag Sensor Rear LH
S 14 Side Airbag Sensor Rear RH
T 12 Trailer Socket
T 13 Tweeter LH
T 14 Tweeter RH
T 15 Towing Converter Relay
T 20 Television Camera
T 21 Television Camera ECU
T 22 Television Camera ECU
T 23 Towing Hitch Relay
V 1 Vapor Pressure Sensor
V 6 Vanity Light LH
V 7 Vanity Light RH
V 10 VSV (Pressure Switching Valve)
W 4 Woofer (Speaker)
